911 E. Fox Farm Rd. #2
Cheyenne, WY 82007
The Arrow II line of antennas has been engineered to provide maximum gain and efficiency in
the smallest practical size & weight. ONLY 20 oz.
Aluminum Arrow Shafts are used for elements.
The in-line gamma match is pre-assembled & pre-tuned. BNC connector only.
The boom is ¾" square (with round corners) 48" long.
Boom & elements all have plastic tips for safety.
Guarantee
No hassle refund
If you are not completely
satisfied with any ARROW
ANTENNA Product it can
be returned for a FULL
refund less shipping and
handling within 90 DAYS
of purchase date.
SIMPLY THE BEST
ArrowAntennas.com
Simply the Best
17 1/8"
18 1/4"
3 Piece Boom
(307) 222-4712
info@arrowantennas.com
19 1/4"
20 1/4"
Model
146-4BP
4 Elements for the 2 meter band.
We don't invent antennas.
We simply build them better.
Page 1
Advertisement
Table of Contents
Related Manuals for Arrow Antenna II Series
Summary of Contents for Arrow Antenna II Series
- Page 1 ArrowAntennas.com 911 E. Fox Farm Rd. #2 (307) 222-4712 Cheyenne, WY 82007 info@arrowantennas.com Simply the Best 17 1/8” 18 1/4" 19 1/4" 20 1/4" 3 Piece Boom The Arrow II line of antennas has been engineered to provide maximum gain and efficiency in the smallest practical size &...
- Page 2 Part # Price Model 146-4BP Parts List 14601BP $29.00 Three Piece Boom 3/4" X 48" (each piece aprox. 18" long) 146 19.250 $22.00 146 Driven Element Pair - with End Caps Inserts, & 2 1/2" Stud (19 1/4 ") 146 20.250 $ 8.00 Reflector Element Pair - with End Caps, Inserts, &...
- Page 3 ASSEMBLY CHECKLIST FOR OUR SHIPPING DEPARTMENT. Circle Antenna Being Assembled: 146-4BP ___Split Boom ___4 element holes ___Hole are clear ___End Caps ___2 @ 20 1/4" elements ___2 @ 18 1/4" elements ___1 @ 19 1/4" driven element. ___1 @ 19 1/4" non-driven element ___2 @ 17 1/8"...
