The OSJ VHF/Marine does NOT require a ground plane.
Ideal for mounting:
• In an attic
• On a roof vent pipe
• On a wooden (or Metal) pole
• On Fiberglass or Plastic Vehicles
(Motorhomes, Trucks, Boats)
Mount it just about anywhere.
SO-239 Feed Connector
Covers 152 - 162 MHz with a VSWR of less than 1.5:1.
Omni-Directional
The OSJ is a Heavy Duty Antenna. The elements are made
from 3/8" solid aluminum with a heavy duty angle mounting
bracket.
Nothing to tune. Nothing to adjust.
Covers 150 – 162 MHz.
Guarantee
No hassle refund
If you are not completely satisfied with
any ARROW ANTENNA Product it
can be returned for a FULL refund less
shipping and handling within 90 DAYS
of purchase date.
SIMPLY THE BEST
ArrowAntennas.com
Simply the Best
We don't invent antennas.
We simply build them better.
(307) 222-4712
info@arrowantennas.com
54"
5"
Model
OSJ VHF & Marine
Open Stub J-Pole
18"
Page 1
