Cabin Creek
Executive Desk
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Cabinet
1 pc.
B.
Stretcher
2 pcs.
C.
Stretcher
1 pc.
D.
Stretcher
1 pc.
Hardware List
Hex Wrench
1 pc.
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
Head Cap Bolt
30 pcs. (+1 extra)
Small
Wood Screw
Hex Wrench
for Drawer
1 pc.
6 pcs. (+1 extra)
Spring Washer
30 pcs. (+1 extra )
Big Flat Washer
Flat Washer
10 pcs. (+1 extra )
20 pcs. (+1 extra )
Tools recommended for assembly : Level
E.
Side Frame
2 pcs.
F.
Drawer
1 pc.
Pull Handle
2 pcs.
Machine Screw
4 pcs.
