- Page 1 Hot Water - Gasoline Powered - Diesel/Oil Heated Operator’s Manual Pressure Washer MODELS: PGDC4 - 3500 1.110-049.0 PGDC5 - 3500 1.110-050.0 PGDC5 - 3500 1.110-051.0 PGDC8 - 3000 1.110-072.0 For the Landa Dealer nearest you, consult our web page at www.landa.com 8.916-596.0 - BF 01/15/21...
-
Page 2: Machine Data Label
Machine Data Label Landa PGDC Operator’s Manual 8.916-596.0 - BF... -
Page 3: Table Of Contents
Parts Landa PGDC......26 Power Platform ......30 Control Box . -
Page 4: How To Use This Manual
KIT INSTRUCTIONS which came with the kit. It contains replacement parts numbers needed for ordering future parts. NOTE: The manual part number is located on the lower right corner of the front cover. Landa PGDC Operator’s Manual 8.916-596.0 - BF... -
Page 5: Safety
4. All installations must comply with local codes. serial number. Use only identical replacement Contact your electrician, plumber, utility company parts. or the selling distributor for specific details. This machine is to be used only by trained opera- tors. Landa PGDC Operator’s Manual 8.916-596.0 - BF... - Page 6 IS PERMITTED 4. When in use, do not place machine near flammable objects as the engine is hot. 5. Oil burning appliances shall be installed only in locations where combustible dusts and flammable Landa PGDC Operator’s Manual 8.916-596.0 - BF...
- Page 7 Do not allow children to operate the pressure damage. Follow storage instructions specified in washer. This machine must be attended during this manual. operation. 12. Inlet water must be clean fresh water and no hotter then 90°F. Landa PGDC Operator’s Manual 8.916-596.0 - BF...
- Page 8 1-2 minutes. 18. Machines with shut-off spray gun should not be operated with the spray gun in the off position for extensive periods of time as this may cause damage to the pump. Landa PGDC Operator’s Manual 8.916-596.0 - BF...
-
Page 9: Operations
Detergent Spray Pick Up Tube Detergent Bucket (not included) Nozzle Variable Pressure Control Wand Handle Gasoline Fuel Oil Tank Tank Trigger Engine Switch High Pressure Hose Trigger Burner Safety Latch Pressure Switch Nozzles Landa PGDC Operator’s Manual 8.916-596.0 - BF... -
Page 10: Assembly Instructions
Local purchase of battery will be the responsibility of Black the owner. Automotive type 12 Volt Group 24 battery is recommended for placement within the weather Red + Positive Terminal resistant box. Follow safety and installation instructions furnished with the battery. Landa PGDC Operator’s Manual 8.916-596.0 - BF... -
Page 11: Operation Instructions
Variable Pressure Trigger Control Handle STEP 6: Selection of high or low pressure is accompanied by turning the handle. NOTE: High pressure nozzle must be inserted at end of wand to obtain high pressure. Landa PGDC Operator’s Manual 8.916-596.0 - BF... -
Page 12: Detergents & General Cleaning Techniques
Liquides contenant des solvants (c.-à-d. diluant à detergent to work area. Do not peinture, essence, huiles, etc.) allow detergent to dry on • Produits à base de tripolyphosphate de sodium surface. • Ammoniac ou produits à base d'acide Landa PGDC Operator’s Manual 8.916-596.0 - BF... -
Page 13: Shutting Down And Clean-Up
STEP 6: Disconnect high pressure STEP 4: Squeeze trigger on spray STEP 5: Remove water supply hose from high pressure outlet. gun to relieve remaining pressure. hose. Landa PGDC Operator’s Manual 8.916-596.0 - BF... -
Page 14: Maintenance
Check air inlet to make sure it is not clogged or additives may be added to gasoline in fuel tank of blocked. Wipe off any oil spills and keep equipment the engine, or to gasoline in a storage container. clean and dry. Landa PGDC Operator’s Manual 8.916-596.0 - BF... - Page 15 In alkaline water areas, lime deposits can accumulate The area around the Landa washer should be kept rapidly inside the heating coil. This growth is increased clean and free of combustible materials, gasoline and by the extreme heat build up in the coil.
- Page 16 Consider alternate nozzle configurations from the Landa PGDC Operator’s Manual 8.916-596.0 - BF...
-
Page 17: Burner Air Adjustment
Do not throttle down the engine at any time while the machine is operating. Landa PGDC Operator’s Manual 8.916-596.0 - BF... -
Page 18: Troubleshooting
Bridge rectifier defective Test and replace 12 VDC relay defective Test and replace (continued on next Disconnected or short in electrical All wire contacts should be clean and tight. No page) wiring breaks in wire Landa PGDC Operator’s Manual 8.916-596.0 - BF... - Page 19 Fuel Pressure is too high for clean Reduce fuel pressure PSI/Increase air band set for burn (fuel PSI above 140 and below cleaner without max water heat loss 200) and smokes when burner is off Landa PGDC Operator’s Manual 8.916-596.0 - BF...
- Page 20 Check and replace if necessary. WATER DRIPPING Cracked piston Check and replace if necessary. FROM UNDER PUMP Lower water supply pressure. Do not run with Pump protector spray gun closed longer than 2 minutes. Landa PGDC Operator’s Manual 8.916-596.0 - BF...
- Page 21 BURNER MOTOR Defective control switch Replace switch. WILL NOT RUN Loose wire Check and replace or tighten wiring. Defective burner motor Replace motor. RELIEF VALVE Relief valve defective Replace or repair. LEAKS WATER Landa PGDC Operator’s Manual 8.916-596.0 - BF...
-
Page 22: Preventative Maintenance
Attention to regular preventative maintenance procedures will assist in preserving the performance of your equipment. Contact your Landa dealer for maintenance. Regular preventative maintenance will add many hours to the life of your pressure washer. -
Page 23: Oil Change Record
Check pump oil level before first use of your new Power Washer. Change pump oil after first 50 hours and every year or 500 hours thereafter. Use SAE 10W-40 non-foaming oil. Estimated Operating Estimated Operating Date Oil Changed Date Oil Changed Hours Since Last Oil Hours Since Last Oil Month/Day/Year Month/Day/Year Change Change Landa PGDC Operator’s Manual 8.916-596.0 - BF... - Page 24 8.916-596.0 • Printed in U.S.A.
