Summary of Contents for Eaton PKE-COM-RTU
- Page 1 Manual 03/20 MN034005EN PKE-COM-RTU Modbus RTU Communication interface for PKE12/32/65...
- Page 2 All rights, including those for translation, reserved. No part of this manual may be reproduced or distributed in any form (print, photocopy, microfilm or any other procedure) without the written consent of Eaton Industries GmbH, Bonn, nor may it be processed using electronic systems.
- Page 3 This should not result in dangerous operating states even for a short time. If necessary, emergency switching off devices should be implemented. PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN...
-
Page 4: Table Of Contents
2.7 .7 Type of trip block (TYPE) ...................16 2.7 .8 Setting for time lag (CLASS) and short-circuit release (I >) (CLASS) ......17 2.7/9 Remote tripping, PKE basic device (R-TRIP) ............17 3 TECHNICAL DATA .........................18 PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... -
Page 5: About This Manual
Please follow the installation instructions in the relevant instruction leaflets. All the specifications in this manual refer to the hardware and software versions documented in it. More information on the devices described here can be found online at: www.eaton.eu/documentation PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... -
Page 6: Pke-Com-Rtu, Interface Connection For The Motor Or Circuit Breaker Pke12/32/65
PKE12/32/65 1.1 Introduction The PKE-COM-RTU module is used to control the PKE motor or circuit breaker via a programmable logic controller and to record the information from the PKE. The PKE-COM- RTU is connected directly to the PKE12, PKE32 and PKE65. -
Page 7: Projection
PKE65. The trip blocks used, which can be combined with the PKE basic devices, must be of type PKE-XTUA or PKE-XTUWA. For each PKE-COM-RTU, a PKE with PKE trip block can be connected. The following PKE trip blocks of the type "Extended" can be combined with the PKE basic devices PKE12, PKE32 and PKE65. - Page 8 ▶ Set the slave address on the device. Addr. 1 Addr. 2 Addr. 63 ▶ Connect the PKE-COM-RTU to the PKE basic device. ▶ Install the PKE "Extended" type trip block (PKE-XTUA-…). PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN...
-
Page 9: Addressing
All DIP switches set to 0 will reset the device to the factory setting after it has been supplied with power. 1.6 Changing modules DANGER Replacing the module or the PKE is only permissible after the entire Modbus RTU system has been switched off. PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... -
Page 10: Device Status
Continuous light Standard operation mode Flashing (1 Hz) Modbus RTU communication Continuous light PKE tripped Flashing (1 Hz) Communication error 1.8 Parameterization The module is parameterized via the connected Modbus RTU master. PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... -
Page 11: Modbus Rtu
Addressing is performed individually for each PKE via the DIP switches on the respective PKE-COM-RTU module. It is independent of the physical connection (position) in the network. A bus termination resistor is required at the last module on the Modbus line. -
Page 12: Device Plug
Data (N x 1 Byte) CRC (2 Bytes) Figure 4: Data exchange between master and slave The PKE (slave) only sends a response if it has received a request from the master beforehand. PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... -
Page 13: Structure Of The Master Request
The address of the slave (1 to 63) to which the request goes is set via the DIP switches • at the PKE-COM-RTU. Only the PKE with this address can respond to the request. Address 0 is used as a so-called Broadcast (message to all bus users) from the master. -
Page 14: No Slave Response
30001 - 31034 Single coil Output register 44001 - 44005 For some controls (e.g. PLC) it is possible that these contain an offset of +1 in the interface driver for Modbus RTU communication. PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... -
Page 15: Inputs
Arithmetic average value of the relative Always available phase current L2 [%], for PKE-…CP-… only 3 0021 Ar-I-REL-L3 Arithmetic average value of the relative Always available phase current L3 [%], for PKE-…CP-… only PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... - Page 16 3 1031 AppBuild_ver Application build number 100-999 3 1032 ASIC2_ver ASIC2 version number 0xFFEF 3 1033 ASIC2_serialLW Individual ASIC2 serial number, low word 3 1034 ASIC2_serialHW Individual ASIC2 serial number, high word PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN...
-
Page 17: Outputs
(for example PKE-XTUA-4 ￫ Imin = 0.85 × 1 A = 0.85 A). ATTENTION The command "Remote trip PKE basic unit" is supported from the following versions of the PKE trip blocks: PKE-XTUA-1.2/4/12/32 PKE-XTUWA-32 PKE-XTUA-65 Release designation PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... -
Page 18: Set Value (Ir)
40 % compared to when the phase load is symmetrical. The interruption of the main circuits is executed early if the thermal motor image reaches 100 %. PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... -
Page 19: Relative Current Value (I-Rel)
PKE trip blocks: Basic PKE- PKE- PKE- PKE- PKE- PKE- PKE- PKE- device XTUA-1.2 XTUA-4 XTUA-12 XTUA-32 XTUWA-32 XTUACP-36 XTUWACP-36 XTUA-65 PKE12 ✓ ✓ ✓ PKE32 ✓ ✓ ✓ PKE64 ✓ ✓ ✓ PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... -
Page 20: Setting For Time Lag (Class) And Short-Circuit Release (I >) (Class)
= 0.85 × 1 A = 0.85 A). The maximum duration of the tripping process from the time the PKE-RTU receives the trip signal to the actual time of tripping of the PKE basic device is 700 ms. PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... -
Page 21: Technical Data
Maximum input current Connector cross sections single-wire 0.05 - 1.5 (AWG30 - 14) flexible with ferrule 0.05 - 1,5 Stripping length 5 - 6 Tightening torque Nm (lbf in) 0.25 (2.21) PKE-COM-RTU Modbus RTU communication interface for PKE12/32/65 03/20 MN034005EN... - Page 22 Our focus is on delivering the right solution for the application. But decision makers demand more than just innovative products. They turn to Eaton for an unwavering commitment to personal support that makes customer success a top priority. For more information, visit www.eaton.eu.
