User Manual MN040024EN
PowerXL DX-NET-ETHERNET2-2
fieldbus connection EtherNet/IP for
variable frequency drive DE1/DC1
Effective November 2016
New information

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerXL DX-NET-ETHERNET2-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eaton PowerXL DX-NET-ETHERNET2-2

Summary of Contents for Eaton PowerXL DX-NET-ETHERNET2-2

  • Page 1 Effective November 2016 User Manual MN040024EN New information PowerXL DX-NET-ETHERNET2-2 fieldbus connection EtherNet/IP for variable frequency drive DE1/DC1...
  • Page 3 OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability, or otherwise for any special, indirect, incidental, or consequential...
  • Page 4 We are dedicated to providing fast, friendly, and accurate assistance. That is why we offer you so many ways to get the support you need. Whether it is by phone, fax, or email, you can access Eaton’s support information 24 hours a day, seven days a week.
  • Page 5 • Measures should be taken to ensure the proper restart of programs interrupted after a voltage dip or failure. This should not cause dangerous operating states even for a short time. If necessary, emergency-stop devices should be implemented. EATON www.eaton.com...

  • Page 6: Table Of Contents

    Install EDS files for Eaton products into RSLogix5000 ....... . .

  • Page 7: Powerxl Series Overview

    However, it is important to note that the variable frequency drive must always be operated with its housing placed properly, as well as with all required safety-relevant parts. All the specifications in this manual refer to the hardware and software versions documented in it. EATON www.eaton.com...

  • Page 8: Device Series

    The packaging must contain the following part: An EIP interface card DX-NET-EtherNet2-2 • Key to part numbers The catalog number selection and the part nunber of the DX-NET-… interface card have the following structure. Figure 1. Catalog number selection General rated operational data EATON www.eaton.com...

  • Page 9: Designation At Dx-Net-Ethernet2-2

    See the drive manual for further information inverter built-in RJ45 port supports the Modbus RTU protocol and on this port. For additional details see the Modbus Serial therefore allows a direct network connection without an additional Communication Manual (MN040018_EN). EATON www.eaton.com...

  • Page 10: Proper Use

    DE1/DC1 series variable frequency drives to be integrated as I/O devices into EtherNet/IP fieldbus systems. Service and warranty Contact your local sales partner if you have a problem with your Eaton fieldbus connection. When you call, have following data ready: The exact part no. (DX-NET-ETHERNET-2) •...

  • Page 11: Engineering

    Network Status Indicator – 0.25 sec RED, 0.25 sec Green • Module Status Indicator – 0.25 sec RED, 0.25 sec Green • COMM – 0.5 sec Yellow, 0.5 sec Off • ERROR – 0.5 sec Off, 0.5 sec RED • EATON www.eaton.com...

  • Page 12: Installation

    With parallel cable routing, the clearances between control, signal and fieldbus cables and energy-carrying mains and motor cables must be greater than 30 cm. Cables should always intersect at right angles. Figure 7. Installing the fieldbus—parallel routing EATON www.eaton.com...

  • Page 13: Commissioning

    DC1/DE1 variable frequency drive into an EtherNet/IP 2 Head controller (I/O controller) network. 3 Switch The EDS file, named “DX-NET-ETHERNET2-2“ , can be found 4 EtherNet/IP cable on the Internet at: www.eaton.com/drives DC1 or DE1  Downloads 5 DE1/DC-1 variable frequency drives 6 Motor Engineering the module   Switch the device on (turn on the power supply!).

  • Page 14: Addressing

    The Static function will be enabled by default with an IP Address classes and instances of 192.168.1.254, subnet mask 255.255.255.0 from Eaton. 0x06 Connection manager Used to manage internal resources for I/O...
  • Page 15 Gateway to the desired value and click “Set” . The Webserver contains 4 pages: Module Configuration • Module Identity (Class 0x01) • Network Settings (Class 0xF5) • Drive Identity (Class 0x01) • ote: All data is fixed. ote: All data is fixed. EATON www.eaton.com...
  • Page 16 Data accepted and stored new IP Address...’ Data is read from the Drive. If the Drive does not support this functionality, then the following data is required: Vendor Name: ‘Unknown Modbus Device’ • Product Code: Empty • Version Number: Empty • EATON www.eaton.com...

  • Page 17: Web Server

    CIP Vend ID – EIP certified Vendor identifier • CIP Product Name – EIP certified module product name • CIP Product Code – EIP registered product code • CIP Serial Number – EIP protocol serial number for addressing • EATON www.eaton.com...
  • Page 18 • Modbus Vendor Name – defines the vendor of the device connected. • Modbus Product Code – defines the device name connected to the network. • Modbus Version Number – defines the connected device firmware version between • EATON www.eaton.com...

  • Page 19: Operation

    Length Fixed Length Fixed Transfer Format 32 bit Run/Idle Transfer Format 32 bit Run/Idle Size Size Connection Type Point to Point Connection Type Point to Point Length Fixed Length Fixed Transfer Format Pure data Transfer Format Pure data EATON www.eaton.com...
  • Page 20 4 words (INTs). The data layouts are as follows. They’re shown in words. Process data field Master i Slave PDI 3 PDI 4 Slave i Master PDO 3 PDO 4 The length of each data unit is 1 word. Description of data content EATON www.eaton.com...
  • Page 21 The permissible value fall within a range of the drives 0 to 300 sec on DE1 and 0 to 600 sec on DC1 , refer to setting of P-03. Value is scaled with a factor of 0.01 in the application. This input is only active when P-12 is set to a value of 4 in DC1. EATON www.eaton.com...
  • Page 22 Effective November 2016 Output process data field DE1/DC1 Status and Fault Word Information regarding the device status and fault messages is specified in the status and fault word. Fault word Status word DE1 status word DC1 status word Fault word EATON www.eaton.com...
  • Page 23 Instance 6 = Modbus Register Holding Register 6 = PDI2 (2 Byte) Instance 7 = Modbus Register Holding Register 7 = PDI3 (2 Byte) Instance 8 = Modbus Register Holding Register 8 = PDI4 (2 Byte) Instance x = Modbus Register Holding Register x = (2 Byte) EATON www.eaton.com...
  • Page 24 0x19 Access code 0x18 0x19 Function of the control terminals 0x18 0x19 Analog input AI1, signal range 0x18 0x19 Analog input AI1, gain (scaling) 0x18 0x19 Analog input AI1, inversion 0x18 0x19 Digital input DI3, Logic 0x18 0x19 EATON www.eaton.com...
  • Page 25 PDP address 0x18 0x19 Modbus Baud rate 0x18 0x19 Modbus RTU, Timeout 0x18 0x19 Used to restore the device's default settings 0x18 0x19 Password 0x18 0x19 Parameter lock 0x18 0x19 SWD, communication loss 0x18 0x19 Parameter Access 0x18 0x19 EATON www.eaton.com...
  • Page 26 0x50 Access code 0x4E 0x50 Function of the control terminals 0x4E 0x50 Analog input AI1, signal range 0x4E 0x50 Analog input AI1, gain (scaling) 0x4E 0x50 Analog input AI1, inversion 0x4E 0x50 Digital input DI3, Logic 0x4E 0x50 EATON www.eaton.com...
  • Page 27 PDP address 0x4E 0x50 Modbus Baud rate 0x4E 0x50 Modbus RTU, Timeout 0x4E 0x50 Used to restore the device's default settings 0x4E 0x50 Password 0x4E 0x50 Parameter lock 0x4E 0x50 SWD, communication loss 0x4E 0x50 Parameter Access 0x4E 0x50 EATON www.eaton.com...
  • Page 28 0x10 Access code 0x0E 0x10 Function of the control terminals 0x0E 0x10 Analog input AI1, signal range 0x0E 0x10 Analog input AI1, gain (scaling) 0x0E 0x10 Analog input AI1, inversion 0x0E 0x10 Digital input DI3, Logic 0x0E 0x10 EATON www.eaton.com...
  • Page 29 PDP address 0x0E 0x10 Modbus Baud rate 0x0E 0x10 Modbus RTU, Timeout 0x0E 0x10 Used to restore the device's default settings 0x0E 0x10 Password 0x0E 0x10 Parameter lock 0x0E 0x10 SWD, communication loss 0x0E 0x10 Parameter Access 0x0E 0x10 EATON www.eaton.com...
  • Page 30 101) 0x18 0x19 P-15 Function of digital inputs 0x18 0x19 P-16 Analog input 1 (AI1), signal range 0x18 0x19 P-17 Pulse frequency 0x18 0x19 P-18 K1 signal (Relay Output 1) 0x18 0x19 P-19 K1-Limit value (relay) 0x18 0x19 EATON www.eaton.com...
  • Page 31 0x25 P-48 Standby-time 0x25 0x26 P-49 PI controller, feedback wakeup level 0x26 0x27 P-50 CANopen Baud rate 0x27 0x28 P-51 Motor overload protection 0x28 0x29 P-52 Parameter access 0x29 0x30 P-53 Reaction to the communication fault 0x30 0x31 EATON www.eaton.com...
  • Page 32 101) 0x4E 0x50 P-15 Function of digital inputs 0x4E 0x50 P-16 Analog input 1 (AI1), signal range 0x4E 0x50 P-17 Pulse frequency 0x4E 0x50 P-18 K1 signal (Relay Output 1) 0x4E 0x50 P-19 K1-Limit value (relay) 0x4E 0x50 EATON www.eaton.com...
  • Page 33 0x50 P-48 Standby-time 0x4E 0x50 P-49 PI controller, feedback wakeup level 0x4E 0x50 P-50 CANopen Baud rate 0x4E 0x50 P-51 Motor overload protection 0x4E 0x50 P-52 Parameter access 0x4E 0x50 P-53 Reaction to the communication fault 0x4E 0x50 EATON www.eaton.com...
  • Page 34 101) 0x0E 0x10 P-15 Function of digital inputs 0x0E 0x10 P-16 Analog input 1 (AI1), signal range 0x0E 0x10 P-17 Pulse frequency 0x0E 0x10 P-18 K1 signal (Relay Output 1) 0x0E 0x10 P-19 K1-Limit value (relay) 0x0E 0x10 EATON www.eaton.com...
  • Page 35 0x10 P-48 Standby-time 0x0E 0x10 P-49 PI controller, feedback wakeup level 0x0E 0x10 P-50 CANopen Baud rate 0x0E 0x10 P-51 Motor overload protection 0x0E 0x10 P-52 Parameter access 0x0E 0x10 P-53 Reaction to the communication fault 0x0E 0x10 EATON www.eaton.com...

  • Page 36: Appendix A-Rslogix Setup App Note For De1/Dc1

    Version 4 (TCP/IPv4) to highlight it, then select Properties. 6. When finished, select OK and close all the windows used along the way. Your computer’s Ethernet port will now be actively using the IP address and Subnet mask you just entered. EATON www.eaton.com...

  • Page 37: Configuring The Powerxl Dc1/De1 Drive - Ip Address

    The Web Pages for the DC1/DE1 drive will open as follows: Select Network Settings to change the IP Address of the DC1/DE1 drive as follows: As noted above, the IP address for the drive in this example is 192.168.1.254. EATON www.eaton.com...

  • Page 38: Creating A Project In Rslogix5000

    Select OK to create the project. Install EDS files for Eaton products into RSLogix5000 There is an EtherNet/IP EDS file for all Eaton EtherNet/IP products, compatible with RSLogix5000, version 20 or later. These files can be installed into the RSLogix5000 software via the following: 1.

  • Page 39: Creating An Ethernet/Ip Network In Rslogix5000

    Effective November 2016 Creating an EtherNet/IP network in RSLogix5000 On the Controller Organizer on the left portion of the project screen in RSLogix5000, near the bottom, right click on Ethernet and select New Module. The following screen will open: EATON www.eaton.com...
  • Page 40 Select the checkmark to the left of Module Type Vendor Filters to clear all check marks on the right portion of the window. Then select “Eaton Electrical” to check the box to its left and only Eaton products will be displayed below, as follows: Select the DX-NET-ETHERNET2-2 from the list, then select Create.
  • Page 41 The AOI can be used as many times in your program as the number of drives in the system. The AOI for the DC1/DE1 drives as well as for all Eaton EtherNet/IP motor control products can be found on the Eaton website at www.eaton.com.
  • Page 42 The data layouts for the 4 input and output words are described below. Each assembly is 8 bytes, or 4 words (INTs). The data layouts are as follows. They’re shown in words. More info can be found about this in “Cyclic data” on page 13. EATON www.eaton.com...

  • Page 43: Appendix B-Firmware Upgrade

      Once the Transfer of APP_DX-NET-ETHERNET2-2_aaabbbSccc.cfg Webserver. The values should be as follows: is complete, the module return to ‘Normal Running’ conditions Configuration Method = Static •   Firmware upgrade has been applied IP Address: 192.168.1.254 • Network Mask: 255.255.255.0 • EATON www.eaton.com...

  • Page 44: Recovering From A Failed Firmware Upgrade

    COMM Status Indicator – solid Yellow • PBL Error: Error occur – reset and retry Network Status Indicator – 1 Hz flash Amber • Module Status Indicator – 1 Hz flash Amber • Error Status Indicator – solid RED • EATON www.eaton.com...
  • Page 45 DX-NET-ETHERNET2-2 fi eld bus connection User Manual MN040024EN EtherNet/IP for variable frequency drive DE1/DC1 Effective November 2016 EATON www.eaton.com...
  • Page 46 User Manual MN040024EN DX-NET-ETHERNET2-2 fi eld bus connection EtherNet/IP for variable frequency drive DE1/DC1 Effective November 2016 EATON www.eaton.com...
  • Page 47 DX-NET-ETHERNET2-2 fi eld bus connection User Manual MN040024EN EtherNet/IP for variable frequency drive DE1/DC1 Effective November 2016 EATON www.eaton.com...
  • Page 48 At Eaton, we’re energized by We power businesses with the challenge of powering a reliable, effi cient and safe world that demands more. With electrical power management over 100 years experience in solutions. Combined with our electrical power management, personal service, support and...
