- Page 1 ATIM Cloud Wireless Metering and Monitoring MR2 - ATEX User Guide Concerned models: ACW/SF8-MR2EX ACW/LW8-MR2EX ATIM Radiocommunications Chemin des Guillets www.atim.com [Tapez ici] 38250 Villard de Lans info@atim.com...
-
Page 2: Table Of Contents
ABLE OF ONTENTS Document version history ........................2 Disclaimer ..............................2 Trademarks and copyright........................2 Environmental recommendations ......................3 Explosive atmosphere ......................... 3 Environment ..........................4 Radio ............................5 Product Identification ..........................7 Technical specifications ........................... 7 ACW-MR2-EX operating mode ........................ 8 “Meter reading”... -
Page 3: Document Version History
Trademarks and copyright ATIM radiocommunications®, ACW ATIM Cloud Wireless® and ARM Advanced Radio Modem® are registered trademarks of ATIM SARL in France. The other trademarks mentioned in this document are the property of their respective owners. ATIM_ACW-MR2-EX_UG_EN_V1.1... -
Page 4: Environmental Recommendations
Declaration of compliance All ACW Atim Cloud Wireless® products comply with the regulatory requirements of the R&TTE Directive (1999/5/EC), article 3: 1 SAFETY (Article 3.1a of the 1999/5/EC Directive) NF EN60950-1 Ed. 2006/A1:2010/A11:2009/A12:2011 (health) EN62479: 2010 (power <20mW) or EN62311:2008 (power > 20mW) 2 Electromagnetic compatibility (Article 3.1b of the 1999/5/EC Directive) -
Page 5: B) Environment
b) Environment Respect the temperature ranges for storage and operation of all products. Failing to respect these guidelines could disrupt device operation or damage the equipment. ACW products in IP65 water- and dust-resistant housings may be placed outdoors, but must not, under any circumstances, be submerged. -
Page 6: C) Radio
c) Radio Modems in the ACW line are radio-communication modems that use the ISM (industrial, scientific and medical) bands, which may be used freely (at no cost and with no authorisation required) for industrial, scientific and medical applications. ATIM_ACW-MR2-EX_UG_EN_V1.1... - Page 7 For a safe utilization These devices must be connected to certified intrinsically safe equipment. Associations must be compatible with intrinsic safety. The electrical parameters of these devices must not exceed the values given below. Approval: INTERTEK / ATEX / IECEx / Hazardous Locations Intrinsic safety level II 3 G, Ex ic IIB T4 Gc Spark risk assessment...
-
Page 8: Product Identification
Product Identification The product identifier is visible on the exterior label on the back of the device: Product ID Product reference: Sigfox or LoRaWAN version Hardware version, Application Sigfox ID or DevEUI LoRaWAN software/radio firmware number Datamatrix Serial product number Technical specifications Dimensions 177 x 55 x 55 mm... -
Page 9: Acw-Mr2-Ex Operating Mode
ACW-MR2-EX operating mode This paragraph describes the operating mode of the ACW-MR2-EX, depending on the use case. a) “Meter reading” mode The ACW-MR2-EX sensor have 2 inputs which can be connected to dry pulse measurement contacts. The ACW-MR2-EX device has 2 inputs which can be connected to dry contact pulse transmitters or to an open collector for remote measurement. -
Page 10: Footprint
Footprint Format and template of the fixing holes of the box Opening of the ACW case The box must be opened to access the module configuration switches as well as the connection terminal block. To do this, insert the screwdriver in the slot and tilt down to lift the inner tab (see photo opposite). -
Page 11: Fixing Support
Fixing support In order to meet the requirements of the safety standard, it is important to connect either the wall or the product to the ground. A hole on the attachment has been provided for this use. Fixing on a flat wall (provided): Special condition for safe use The end user will take all necessary precautions to install the equipment in its final environment while maintaining the... -
Page 12: Implementation And Positioning
Implementation and positioning Install the modem at a minimum height of 2m and not glued to the wall, ideally offset by at least 20cm the cables must not exceed 10m in length and must be shielded For optimal results, it is advisable to place it in height and clear of any metallic obstacle in a radius of 1 meter if possible (see figures below). -
Page 13: Product Restart
Product restart A power failure is achievable by positioning a magnet near a magnetic switch placed on the power supply of the modem. This operation can be useful to perform a restart (requires positioning the magnet for about 30 seconds). ATIM_ACW-MR2-EX_UG_EN_V1.1... -
Page 14: Modem Connection
Modem connection ATIM warned the use only of ATEX certified battery for the exact reference ACW-MR2Ex: SAFT - LS14500Ex. The polarity is indicated on the printed circuit board. The + pole is oriented towards the terminal block, the pole - towards the antenna. - Page 15 2 cables connection (pulse emitter without anti-fraud output) Pulse cable Ground cable Please note that in particular cases, pulse and mass cables are undifferentiated. Note Disable the anti-fraud detection, connection the WIRECUT and GND inputs like shown on the diagram. 3 cables connection (pulse emitter with anti-fraud output) Pulse cable Anti-fraud cable...
-
Page 16: B) Connection To 2 Meters
b) Connection to 2 meters The amount of cables and their color depend on the pulse emitter type installed on the meter. Please refer to the emitter guide in order to verify the connection. 2x2 cables Connection Ground cable, meter 1 Pulse cable, meter 1 Pulse cable, meter 2 Ground cable, meter 2... -
Page 17: C) Gas Metering Wire
1 meter and recommended diameter 0,9mm, strip the wire to 9mm. ATIM can provide a cable suitable for CAB / MTRGAZ1 reference gas meters with an M16 IP40 connector, having the following characteristics: 6 AWG shielded 6-wire cable with a length of 2 meters. -
Page 18: Led Lights Meaning
COLOUR SIGNAL Brown Oversight + White GND - Oversight Grey Metering 2 + Blue Metering 1 + Yellow GND - Metering 2 Green GND - Metering 1 LED lights meaning The red status indicator lights when the product is powered. After a few seconds, the green LED flashes, which means that the modem is sending its data to the network. -
Page 19: Configuration
Configuration The configuration can be realized locally thanks to internal switches, or remotely through downlink frames. By default, the product uses the switch configuration until a downlink frames configuration is not done. If a downlink configuration is applied, throughout the next restart, this setting will be used. a) Internal DIP switches configuration The configuration is read at the starting of the device. - Page 20 Radio emission period (METER READING frame): 10 min Radio emission period (METER READING frame): 30 min Radio emission period (METER READING frame): 1 h Radio emission period (METER READING frame): 3 h STANDARD METER READING MODE Radio emission period (METER READING frame): 6 h Radio emission period (METER READING frame): 12 h Radio emission period (METER READING frame): 24 h Radio emission period (METER READING frame): 48 h...
-
Page 21: B) Downlink Frames Configuration
Or superior Downlink operation mode is explained in the ATIM_ACW-DLConfig_UG_FR_v1.1 document, related to version V1.1 of Downlink protocol ATIM. Downlink protocol ATIM V1.1, shared between all ACW Product Line devices, describes how to realize the following actions: • Ask for an ACW products restart •... - Page 22 0x02 = standard meter reading with emission every hour 0x03 = standard meter reading with emission every 3 hours 0x04 = standard meter reading with emission every 30 minutes 0x05 = standard meter reading with emission every 12 hours 0x06 = standard meter reading with emission every 24 hours 0x07 = standard meter reading with emission every 48 hours 0x08 = change of state detection mode with Wirecut polling input 0x09 = change of state detection mode with radio emission on falling...
- Page 23 Command to send Parameter Value (4 octets) C1090Cxxxxxxxxyyyyyyyy Possible values for xxxxxxxx and yyyyyyyy (in hexadecimal): 0x00000000 0xFFFFFFFF Eg : If we want to set up the index of the meter 1 over 1000 and the index of the meter 2 over 5000, you need to send via downlink the command C1090C000003E800001388 (because in hexadecimal 1000 = 3E8 et 5000 = 1388).
-
Page 24: Sigfox - Lorawan Frame Format
Sigfox – LoRaWAN frame format Data varies in function of the emitted frame type and the operating mode (Pulse, Dry contacts). For example: TYPE DESCR. FRAME FORMAT octet 0 octet 0 octet 1 octet 2 octet 3 octet 4 octet 5 octet 6 octet 7 octet 8... -
Page 25: Help
Check that the output of your meter does not exceed 5V in the case of an output push- pull Modem LED is not blinking • Check if the power supply is properly connected to the modem Technical support For any further information or technical issues, you may contact our technical support team on this webpage: https://www.atim.com/en/support-2/technical-support/ ATIM_ACW-MR2-EX_UG_EN_V1.1...
