Installation Guide
ACW-DI2/868
Atim Cloud Wireless
Digital Input
1.
TECHNICAL FEATURES
Power supply :
Active radio :
Digital input power :
Sleep mode consumption:
Functioning temperature :
Radio power:
Radio frequency:
Range :
Minimum pulse time in counter mode :
Minimum pulse time in change of state:
Notice technique complète sur
FRQIG_ACW-DI
Page1/4
By USB with windows utility
Functioning mode :
Mirror mode
Master
Slave
2,7 – 3,6V
cc
50mA
max
5V
max
8µA
typ
-25°C – 70°C
25mW 14dBm
868MHz
1 Km en extérieur
50ms
250ms
www.atim.com
Advertisement
Table of Contents
Related Manuals for ATIM ACW-DI2/868
Summary of Contents for ATIM ACW-DI2/868
- Page 1 Installation Guide ACW-DI2/868 Atim Cloud Wireless Digital Input Configuration : By USB with windows utility Functioning mode : Mirror mode Master Slave TECHNICAL FEATURES Power supply : 2,7 – 3,6V Active radio : 50mA Digital input power : Sleep mode consumption: 8µA...
- Page 2 Type de câble à utiliser: maximum length 1 meter and recommended diameter 0,9mm, the thread on 9mm. In the few seconds following the implementation of the power supply, a first radio transmission is made (visible by a brief blue blinking of the LED) to allow you to verify functioning of the modem. www.atim.com FRQIG_ACW-DI/868 Page2/4...
- Page 3 CONFIGURATION Download and install the configuration software ‘’setupACW.exe‘’ at this address : http://www.atim.com/produit/atim-cloud-wireless-acw/ Connect the modem to the computer via the USB cable and launch the software. When you connect the modem, the software window changes to allow you to reach the central features.
- Page 4 Number of registers to write 0004 Bytes count 1 octet Number of bytes to write Counter 1 MSB-LSB 4 octets Input 1 counter 00000012 Counter 2 MSB-LSB 4 octets Input 2 counter 00000008 2 octets Error control code XXXX www.atim.com FRQIG_ACW-DI/868 Page4/4...
