3. Press the SET button again to get to the PRESET submenu. The display shows the currently
active preset.
4. Press the UP and
3 or 4).
5. Press the SET button to load up the preset you selected. The procedure is now over, and the
basic setting is shown in the display again.
In this chapter, different control elements of your ULB2000 will be described, explained in detail,
and you will get useful information on how to use them.
POWER
To power the hand-held transmitter on or off, keep the POWER button pressed for at least 2
seconds. Briefly pressing the POWER button confirms your choices when entering values
(refers to later chapters). Additionally, you can check the current transmitter settings (selected
channel and battery condition).
MUTE switch
Engaging the MUTE switch mutes the microphone. Additionally, the ULB2000 can be switched
to programming mode by selecting the digits 9 or 0; or, you can get a readout of a specific unit
setting.
SELECTION SWITCH
Using a screwdriver, you can select different values on the SELECTION SWITCH. For example,
you can select a channel number and the frequency.
STATUS LED
Through repeated blinking, the status LED gives the account of the current settings for all
parameters. We differentiate between 3 different blinking tempos:
The LED flashes slowly when exiting the programming mode, for example.
To give the account of the channel number or individual frequency values, the LED
blinks with medium tempo.
Rapid blinking indicates an error, for example an empty battery or a faulty entry.
The costant glowing of the LED indicates the operational readiness of the transmitter.
The SERIAL NUMBER is located on the transmitter battery compartment. To get to the serial
number, please open the battery compartment (see ch. 1.1.4).
A brief overview with the graphic representation on operating the transmitter is found on the last
page of this user manual (QUICK REFERENCE GUIDE).
1. Press the transmitter's POWER button for 2 seconds.
12
DOWN buttons to select the desired preset. The display shows PSET 1 (2,

3. ULB2000 TRANSMITTER

3.1 Control elements

Fig. 3.1: Controls of the ULB2000

3.2 Operating the Transmitter

3.2.1 Turning the transmitter on

3. ULB2000 TRANSMITTER
