4. Press the UP and
COLOR).
5. Press the SET button to store the parameter for the basic setting. The procedure is now over,
and the new basic setting is shown in the display.
To prevent your settings from accidentally being changed, you can activate the keylock function
(LOCK). With the exception of the SET button, all other buttons (including the Power button) are
locked. If one of those buttons is pressed,
Activating LOCK
1. Press the SET button to get to the menu.
2. Press the DOWN button twice to get to LOCK.
3. Press the SET button again to get to the LOCK submenu. The display shows LOCOFF
4. Press the UP and
LOC ON.
5. Press the SET button to activate the keylock function. The procedure is now over, and the basic
settings are shown in the display again.
Deactivating LOCK
1. Press the SET button. LOC ON is shown in the display.
2. Press the UP or
3. Press the SET button confirm, hence deactivating the keylock function. The procedure is now
over, and the basic settings are shown in the display again.
The ULR2000 lets you work with 4 presets, each with 8 channels.
Factory presets (Presets 2, 3 and 4)
In the ULR2000, there are 3 factory presets (each with 8 interference-free channels). That means that
all 8 channels of one preset can run simultaneously with 8 different transmitters and receivers
without causing mutual interference.
The channels in the 3 factory presets are all assigned to different frequencies. This way, you can
always select a frequency range that assures the best signal transmission.
The following table shows which frequencies are stored in the factory presets.
CHANNEL
1
2
3
4
5
6
7
8
Table 2.1: Factory preset frequencies (presets 2,3 and 4)
User preset (Preset 1)
Preset 1 is meant for the user. Frequencies of your own choice can be stored in the 8 storage slots
of this preset.
If you have not stored any of your own frequencies, the frequencies stored in the user preset
(Preset 1) are identical to the frequencies stored in Preset 3.
Loading a preset
1. Press the SET button to get to the menu.
2. Press the DOWN button once to get to PRESET.
DOWN buttons to set one of the 3 parameters (FREQU, CHANNL or

2.2.6 LOCK

" "
LOCKED
DOWN buttons once to activate the keylock function. The display shows
DOWN button once to select LOCOFF.

2.2.7 PRESET

PRESET 2 PRESET 3
798,700 MHz 798,400 MHz
799,950 MHz 798,950 MHz
800,650 MHz 799,800 MHz
801,050 MHz 801,450 MHz
802,850 MHz 803,250 MHz
804,500 MHz 803,650 MHz
805,350 MHz 804,350 MHz
805,900 MHz 805,600 MHz
2. ULR2000 RECEIVER
ULTRALINK UL2000B
is shown in the display.
PRESET 4
798,100 MHz
798,650 MHz
799,500 MHz
801,150 MHz
802,950 MHz
803,350 MHz
804,050 MHz
805,300 MHz
.
11
