- Page 1 User’s manual Version 1.1 August 2006...
- Page 2 ULTRALINK ULM2000 IMPORTANT SAFETY INSTRUCTIONS CAUTION: To reduce the risk of electric shock, do not remove the top cover (or the rear section). No user serviceable parts inside; refer servicing to qualified personnel. This symbol, wherever it appears, WARNING: To reduce the risk of fire or electric...
-
Page 3: Table Of Contents
FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE INFORMATION ..... 13 MICROPHONE QUICK START GUIDE ................14 1. INTRODUCTION Thank you very much for expressing your confidence in us by purchasing the ULTRALINK ULM2000. This Transmitter, coupled to the receiver ULR2000 from BEHRINGER, comprises a modern, high-performance wireless transmission system. -
Page 4: Before You Get Started
To arrange for warranty service, please contact the retailer from whom the equipment was purchased. Should your BEHRINGER dealer not be located in your vicinity, you may directly contact one of our subsidiaries. Corresponding contact information is included in the original equipment packaging (Global Contact Information/European Contact Information). -
Page 5: Control Elements
ULTRALINK ULM2000 Registering your purchase and equipment with us helps us process your repair claims quicker and more efficiently. Thank you for your cooperation! 2. CONTROL ELEMENTS In this chapter, different control elements of your ULM2000 will be described, explained in detail, and you will get useful information on how to use them. -
Page 6: Channel Setting
ULTRALINK ULM2000 3.2 Channel setting You can comfortably select a channel within a preset by using the selection switch . In doing so, it is irrelevant whether the microphone is on or off. Changing the channel when the transmitter is already powered on During this procedure, the transmitter may not be set to mute! Turn the selection switch to one of the positions 1 - 8, corresponding to the desired channel number. -
Page 7: Preset
ULTRALINK ULM2000 Confirm your selection by briefly pressing the POWER button. When a valid value is selected, the LED blinks briefly again. When an invalid value is selected, the LED blinks quickly 5 times and the unit is no longer in the programming mode. In this case, start a new with step 2. -
Page 8: Mic Gain
ULTRALINK ULM2000 Selecting 5 or 6 changes the Mic Gain setting (ch. 3.5). Selecting 7 or 8 changes the Auto Mute settings (ch. 3.6). Values 9 and 0 are invalid. Confirm your selection by briefly pressing the POWER button. If the selection you made is valid, the LED blinks quickly once again. An invalid selection is indicated with 5 quick blinks, and the unit is immediately no longer in the programming mode. -
Page 9: Auto Mute
ULTRALINK ULM2000 3.6 Auto Mute If the transmitter is turned on, off or switched to another channel without first muting the receiver, or if the transmission fails due to weak batteries, audible noise will result. Even if the squelch circuit is turned on at the receiver end, it still requires some time to react, and such noise can not be suppressed safely. -
Page 10: Status Query
ULTRALINK ULM2000 4. STATUS QUERY While you are using your microphone, you may want to check the “transmission channel,” “battery condition,” “transmission frequency,” “preset,” “Mic Gain” and “Auto Mute” parameters. The status of these parameters can be checked without having to turn the microphone off and back on. -
Page 11: Ulm2000 Level Setting
ULTRALINK ULM2000 5. ULM2000 LEVEL SETTING To optimally set the level on your ULM2000, the High Gain or Low Gain setting has to be set to the level of the signal being transmitted (ch. 3.5). Adjust the gain control in the microphone channel of your mixing console so that the peak LED lights up only occasionally or never at all. -
Page 12: Audio Connections
0.5 lbs (250 g) BEHRINGER makes every effort to ensure the highest standards of quality. Necessary modifications are carried out without notice. Thus, the specifications and design of the device may differ from the information given in this manual. -
Page 13: Federal Communications Commission Compliance Information
Their use neither constitutes a claim of the trademarks by BEHRINGER nor affiliation of the trademark owners with BEHRINGER. BEHRINGER accepts no liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. -
Page 14: Microphone Quick Start Guide
ULTRALINK ULM2000 MICROPHONE QUICK START GUIDE MICROPHONE QUICK START GUIDE...
