Summary of Contents for Bristan EV KIT-EFB C
- Page 1 Installation Instructions and User Guide Evo Riser Rails and Kits Models Covered: EV KIT-EFB C, EV KIT-EEFB C H, EV KIT-EEFB C, EV KIT-EEVK C Please keep this booklet for future reference. Installer, when you have read these instructions please ensure you leave...
-
Page 2: Table Of Contents
Contents Thank you for choosing Bristan, the UK’s leading taps and showers expert. We have designed these products with your enjoyment in mind. To ensure that they work to their full potential, they need to be fitted correctly. These fitting instructions have been created to... -
Page 3: Important Safety Information
Important Safety Information Please read these instructions thoroughly and retain for future use. All products manufactured and supplied by Bristan are safe provided they are installed, used correctly and receive regular maintenance in accordance with these instructions. If you are in any doubt about your ability to install this product safely you must employ the services of an experienced qualified plumber. -
Page 4: Dimensions (Mm)
Dimensions (mm) EV KIT -EFB C EV KIT -EEFB C Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors. - Page 5 Dimensions (mm) EV KIT -EEFB C H EV KIT -EEVK C Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
-
Page 6: Pack Contents
Pack Contents Wall Brackets x2 2. Riser Rail x1 3. Slider x1 4. Handset x1 5. Fixings x4 6. Hose x1 7. Shelf *not shown x1 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors. -
Page 7: Installation
Installation Mark the position Attach wall bracket fixings Position the assembled riser rail Remove the wall brackets from onto the wall, bearing in mind the rail and then remove the the highest maximum position fixings from the wall brackets. required for the handset. With the Position the fixing bracket in the riser rail vertical, mark the position marked positions against the wall,... - Page 8 Installation Insert riser rail Component Order Ensure the rail clamps are in position and push the riser rail up through the bottom wall bracket. Rail Clamps Push the shelf and slider down onto the riser. Ensure the slider it is the Bottom Bracket correct way up, as shown opposite.
-
Page 9: Operation
Installation Connect shower hose Adjusting the Slider Screw the shower hose (ribbed Press the button on the underside end) onto the shower valve outlet of the slider to move higher or (not supplied), ensuring the rubber lower for user height. washer is fitted. -
Page 10: Maintenance
Your Bristan shower head has rub-clean nozzles for easy cleaning. Simply rub your fingers across the rubber spray jets regularly and before you turn the shower on to remove any scale or debris. -
Page 11: Troubleshooting
Troubleshooting Symptom Cause Remedy Partially closed isolation valve. Open isolation valve. Instantaneous water heater Increase water flow rate or cycles on and off as flow rate pressure through system. or pressure is too low. Head of water is below the Refer to the shower valve’s minimum distance required. - Page 12 Email: enquire@bristan.com A Masco Company At Bristan, we want to make things as easy as possible for our customers. That’s why we offer solid guarantees on all our products, effective from the date of purchase, to give you peace of mind.
