- Page 1 08 jan 2019, 11:01 Loke Made in Sweden...
- Page 2 Thank you for choosing a Euroscreen to be part of your AV ® installation. We hope it will bring you many hours of entertainment and/or education depending on your preference. Please read through the manual completely before installation and usage. Tack för att ni valt en Euroscreen som en del i er AV-installation.
- Page 3 Overview / Översikt Case / Kassett Fabric width + 110 Fabric width Fabric width + 68 fig 1...
- Page 4 Overview / Översikt Ceiling bracket / Takkonsol fig 2 44,5 DRAWN niclas.bexelius 2018-12-10 CHECKED TITLE APPROVED SIZE DWG NO 711067 DS127 Ceili SCALE 1 : 1 SHEET Wall bracket / Väggkonsol fig 3 37,5 DRAWN MTJTOHO1 2018-11-14 DraperEurope CHECKED TITLE I:\Ritning\DraperEurope\Väggfäs APPROVED SIZE...
- Page 5 Loke Bracket / Loke Konsol EN: USE FASTENERS INTENDED FOR THE ACTUAL SURFACE. Try to level them up as good as possible, using spirit level or laser guide (fig 4). Sideways spacing isn’t crucial as they can slide sideways but recommended maximum distance from...
- Page 6 Tensioning / Trådspänning (TabTension only) (endast TabTension) EN: To keep the surface flat you may need to fig 8 adjust the tensioning as the surface will change with time and temperature. This is done with the tensioning screw marked in fig 8. It is adjustable with 1/6 turn increments.
- Page 7 How to open case / Öppna kassetten fig 9 EN: The front lid can be removed while the screen remains installed on the wall. To open the case remove the screws shown in fig 9 on both ends. Lift and remove the lid (fig 10).
- Page 8 Conformity of regulations Draper Europe AB manufactures AV equipment within the brand Euroscreen ® . These products are controlled and certified by the below listed regulations. REACH REACH Registration, evaluation, authorisation and limitation of chemicals. Regulation (EC) No 1907/2006 of the...
