Premier XL
®
Electric Projection Screen
Overview - Components
1
Mounting holes
2
Junction Box cover
3
Dowel
4
Front Cover
Read and understand all warnings
Contents
Components .....................................................................................1
Please Read Warnings and Safety Information ..................................................2
Please Read Field Adjustments, Cleaning and Maintenance ............................2
Section 1
Electrical Connections ...................................................................2
Section 2
Hanging Screen ...............................................................................3
Section 3
Operation ..........................................................................................3
Section 4
Tab Tension Adjustment Procedure ...............................................3
/ Targa XL
220V
®
1
2
3
(Page 2 of this document)
4
(Targa Pictured)
CAUTION
Section 5
Section 6
Limit Adjustments
Section 7
Wiring Diagrams...............................................................................5
Section 8
Section 9
Dimensions and Methods of Installation .......................................7
Section 10
© 2019 All Rights Reserved
INSTRUCTIONS
INSTALLATION & OPERATION
before beginning installation.
.............................................4
..........................................................6
If you have any difficulties installing or servicing your
Premier XL / Targa XL, call your dealer or Draper, Inc.
Draper, Inc. | 411 S. Pearl St. Spiceland, IN 47385
draperinc.com | 765.987.7999 | 800.238.7999
|
FORM: PremierXL_TargaXL_220V_Inst19
TOOLS
REQUIRED
PENCIL
POWER DRILL
LEVEL
TAPE MEASURE
HARDWARE
(by others)
..............................4
.................6
