- Page 1 Installation and commissioning guide for temperature measurement for human body of Dahua thermal camera (BF Series) Zhejiang Dahua Technology Co., Ltd...
-
Page 2: Preface
(Short NO: 693802), Fang Lu (Short NO: 685718), Li Fuxiang (Short NO: 638137), Fang Shengdong (short: 669126). This manual is only for internal use of Dahua employees. Please do not directly provide it to customers or publish it to public platforms such as the Internet. ... - Page 3 Change record Revision date Version number Creater Reviser 房圣东 2020.01.27 V1.0 许芳荣/房圣东 房圣东 2020.01.28 V1.1 房圣东 李静 2020.01.31 V1.2 方璐 房圣东 2020.02.03 V1.3 Preface II...
-
Page 4: Table Of Contents
Content Preface ..................................I 1 Equipment installation ............................2 1.1 Installation Preparation ....................错误!未定义书签。 1.2 Installation distance ............................. 2 1.3 Installation diagram ...................... 错误!未定义书签。 1.4 Real scene diagram ....................... 错误!未定义书签。 1.5 Installation precautions ....................错误!未定义书签。 2 General settings ..............................7 2.1 Device upgrade ...................... -
Page 5: Equipment Installation
BF3221： BF5401 Blackbody： Note: the recorded installation guidance video "Dahua indoor human body temperature measurement product installation video (bf3221)", which adopts tripod mode, is applicable to portable indoor installation guidance reference, and other fixed installation needs to be installed in strict accordance with the specified height, distance and other requirements. -
Page 6: Installation Diagram
distance between the front of forehead and camera), the best test width at 3M is about 1.3m (about one gate), the forward temperature at 3M will be higher, and the backward temperature will be lower. The ideal situation is to place footprints at the 3M position to guide the thermometer to measure temperature one by one at the designated position. -
Page 7: Real Scene Diagram
BF5401(13mm) installation diagram Side view Thermal camera Distance between (focal length Blac two objects: 3m 13mm) kbod Height 2m Height of Blackbody 1.8m Top view Blac kbod Thermal camera (focal length 13mm) Sidewalk width 1.5m Real scene diagram BF3221(7mm) as an example Distance between Height of Blackbody... -
Page 8: Installation Precautions
Thermal camera Height:2m 1. When the artificial diversion channel is lengthened as far as possible, multiple "bow shaped" can be used. When indoor outdoor Height of Blackbody temperature difference is large, the 1.8m longer the person is indoors, the more stable the forehead temperature is;... - Page 9 The moving direction of the flow of people is toward the camera. During the test, the forehead of the target person is facing the camera. It is better to stay and face the camera for temperature measurement. Temporary measures can be adopted on site to plan the walking route of personnel and guide the person to the camera position;...
- Page 10 General settings Equipment upgrade The new factory version of the program already supports human body temperature detection and does not need to be upgraded. (if the bf3221 site version is 20200128 and above, the 20200131 version can be upgraded, item No.: 2.6.01.05.18388).
-
Page 11: Blackbody Parameter Setting
Debugging of human body temperature detection function 2.2.1 Selection of human body temperature measurement intelligent scheme 2.2.2 Blackbody parameter setting Blackbody calibration. Note: the blackbody parameter setting steps are ignored for the scheme without blackbody. The actual setting of blackbody is 35 ℃ After fixing the camera and blackbody position, make sure that the blackbody is in the upper right or left corner of the image:... -
Page 12: Drawing Of Human Body Temperature Detection Area
The blackbody temperature is 35 (the default value). When drawing the area, double-click the image to enlarge to the full screen (double-click again to restore the original picture size after drawing). The green box in the figure below for the rule box should be drawn in the middle of the blackbody radiation surface, and the rule box should be as small as possible (the smaller the box, the higher the measurement accuracy, refer to the green box in the upper right corner of the image below). - Page 13 the head temperature of the subject exceeds 37.3 ℃ (Note: BF5401 has no audible and visual alarm) 2.2.4 Alarm temperature correction Due to the difference of environment, there may be errors in the temperature of the measured person. If more than 5 person samples stand at the best temperature measurement distance and the measured temperature is generally high or low, they can be compensated by temperature correction.
-
Page 15: Announcements
Calibration In order to ensure the accuracy of blackbody temperature measurement, it is recommended to send blackbody to Dahua Co., Ltd. for paid calibration on a regular basis. The calibration cycle is usually one year. Daily maintenance ... -
Page 16: Faq
1. What is blackbody? What is the role? Do you need a physical connection to the camera? Blackbody can be simply understood as a constant temperature reference source (constant temperature can be maintained after power on). When testing human body temperature, blackbody is generally set at 35 ℃, which is used for temperature correction of thermal imaging acquisition, so as to meet the accuracy requirements of ±... - Page 17 Dav video with two channels on site. Send Xu Fangrong and Fang Shengdong through Dahua interactive platform (select intranet Download for outgoing type). After receiving the video, the R & D will optimize and iterate according to the scene.
