Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual
Dahua IR Thermal Imaging Network Camera Web3.0
Operation Manual
Version 1.0.0
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DH-TPC-BF5300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dahua DH-TPC-BF5300

Summary of Contents for Dahua DH-TPC-BF5300

  • Page 1 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Version 1.0.0...

  • Page 2: Table Of Contents

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Table of Contents Network Config ..........................1 Network Connection ..................... 1 Log in ..........................1 Live ..............................6 Encode Setup ........................ 6 System Menu ......................... 7 Video Window Function Option .................. 7 Video Window Setup ....................
  • Page 3 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 5.2.2.1 Connection ......................36 5.2.3 PPPoE ........................39 5.2.4 DDNS ........................40 5.2.5 IP filter ........................41 5.2.6 SMTP （e-mail) ..................... 42 5.2.7 UPnP ........................43 5.2.8 SNMP ........................44 5.2.9 Bonjour ........................47 5.2.10 Multicast .........................
  • Page 4 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Important The following functions are for reference only. Some series products may not support all the functions listed below.

  • Page 5: Network Config

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 1 Network Config 1.1 Network Connection Network camera and PC connection mainly has two ways, see Figure 1-1 and Figure 1-2. Figure 1-1 Figure 1-2 Before you access network camera via the Internet, you need to have its IP address. User can use quick config tool to search IP of the network camera.
  • Page 6 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 1-3 If it is your first time to login in, you may see the interface shown as in Figure 1-4. Figure 1-4...
  • Page 7 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Click on “Please click here to download and install the plug-in”. The system pops up warning information to ask you whether run or save this plug-in. See Figure 1-5. Figure 1-5 You must either run or save the file to local and install it.
  • Page 8 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 1-6...
  • Page 9 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 1-7 When plug-in installation completes, the installation page closes automatically. The web-end will refresh automatically, and then you can view video captured by the camera. See Figure 1-8. Figure 1-8...

  • Page 10: Live

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 2 Live Figure 2-1 After you logged in, you can see the live monitor window. See Figure 2-1 There are four sections:  Section 1: Encode setup bar  Section 2: System menu ...

  • Page 11: System Menu

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 2-2 Please refer to the following sheet for detailed information. Parameter Function Streaming media protocol connection, under main stream config, Main stream monitor video or not. Generally for storage and monitor.

  • Page 12: Video Window Setup

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual  When the video is in the original status, click it you can Zoom in select any zone to zoom in. In the non-original status, you can drag the zoom-in zone in specified range. Right click mouse to restore previous status.

  • Page 13: Original Size

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 2-6 Click this button to display/hide image control interface. Click it to open picture setup interface. This interface is on the top right pane. Please refer to the following sheet for detailed information.

  • Page 14: Width And Height Ratio

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 2.4.4 Width and Height Ratio Click it to restore original ratio or suitable window. 2.4.5 Fluency Adjustment There are three levels of fluency for you to select (real-time, normal, fluent). The default is normal.
  • Page 15 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 2-7...

  • Page 16: Playback

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 3 Playback Web client playback supports video playback and picture playback. Note: Before playback, user shall set storage management as in Ch 5.5. 3.1 Playback The playback interface is shown as in Figure 3-1.

  • Page 17: Playback File

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 3-2 Parameter Function When you see this button, it means pause or not played record. Click on this ① Play button, switch to normal play status. ② Stop Click this button to stop playing.
  • Page 18 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 3-3 Parameter Function Select “dav”, as video playback.  File Type Select “jpg” as picture playback.  Data Source Default is SD card. Step 1. Click on data in blue, time axis displays record file progress bar in color. While, green represents normal record, yellow represents motion detect record, red represents alarm record, and blue represents manual record.
  • Page 19 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 3-5 Parameter Function It means records within searched start time and end time on the date. Search Record Download There are two formats: dav, mp4. Format...

  • Page 20: Playback Cut

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Function Record type is “dav”, click on download button to download file to local.  Record type is “mp4”, click on download button and download file to path in ...

  • Page 21: Progress Bar

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 3.1.5 Progress Bar Figure 3-8 Parameter Function Click on it, means video in past 24 hours. 24 hours Click on it, means video in past 2 hours. 2 hours Click on it, means video in past 1 hour.

  • Page 22: Play

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Snapshot type bar See Figure 3-10. Figure 3-10 3.2.1 Play Figure 3-11 Default icon is and it means pause or not played picture. Click on play button to switch to normal play status. Icon become ...
  • Page 23 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 3-12 Step 1. Click on file list , select snapshot file of the date. Step 2. Double click on file in list, to play this snapshot. Parameter Function It means all snapshot files within the start time and end time of selected date.

  • Page 24: Snapshot Type

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Function Click on download button to download snapshot file to local. Download Click on back button to return to calendar interface and re-select time. Back Figure 3-13 3.2.3 Snapshot Type...
  • Page 25 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 3-14...

  • Page 26: Report

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 4 Report Attention: Currently only some models support report function. The WEB client supports temperature data query of the spot, line and area set by users. Please refer to “5.4.1 Rule Setup” of the settings for spot, line and area.
  • Page 27 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 4-2...

  • Page 28: Setup

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 5 Setup Web client setup support camera, network, event, storage, system and system info view. 5.1 Camera 5.1.1 Conditions Here you can view device property information. Slight differences may be found due to different network camera series.
  • Page 29 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Function Brightness It is to adjust monitor window brightness. You can adjust this value if the video is too dark or too bright. The larger the number, the bright the video is. When you input the value here, the bright section and the dark section of the video will be adjusted accordingly.
  • Page 30 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Colorization Able to add color to the IR image, there are 4 colors to select: White Hot: In grayscale image, the place is brighter with higher temperature. Black Hot： In grayscale image, the place is brighter with lower temperature.

  • Page 31: Video

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Gain Mode There are three modes to select: low temperature, high temperature and auto, it is low temperature by default. Under auto mode, it can set the threshold of switching low...
  • Page 32 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-2 Note: Different stream may be corresponding to different default value, please refer to the actual interface for details. Please refer to the following sheet for detailed information. Parameter Function ACF means using different fps to record.
  • Page 33 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Function Resolution There are multiple resolutions. You can select from the dropdown list. For each resolution, the recommended bit stream value is different. Note: When video is under rotating status, you cannot set resolution higher than 1080P (excluding 1080P).
  • Page 34 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-3 Please refer to the following sheet for detailed information. Parameter Function There are two modes: General (schedule) and Event Snapshot type (activation).  General: to snapshot in the area set by the schedule.
  • Page 35 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-5 Figure 5- 6...
  • Page 36 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-7 Figure 5-8 Please refer to the following sheet for detailed information. Parameter Function  Here you can privacy mask the specified video in the Privacy mask monitor video. ...
  • Page 37 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual  You can enable this function so that system overlays time Time Title information in video window.  You can use the mouse to drag the time tile position.  You can enable this function so that system overlays Channel Title channel information in video window.

  • Page 38: Audio

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-9 5.1.3 Audio Please note some series devices do not support audio function. 5.1.3.1 Audio The audio interface is shown as below. See Figure 5-10. Figure 5-10 Please refer to the following sheet for detailed information.

  • Page 39: Network

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 5.2 Network 5.2.1 TCP/IP The TCP/IP interface is shown as in Figure 5-11. It supports IPv4 and IPv6. IPv4 supports static IP and DHCP. IPv6 supports static IP only. When users manually modify IP address, WEB will automatically jump to the new IP address.

  • Page 40: Connection

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual IP Version It is to select IP version. IPV4 or IPV6. You can access the IP address of these two version. IP Address Please use the keyboard to input the corresponding number to modify the IP address and then set the corresponding subnet mask and the default gateway.
  • Page 41 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-12 Please refer to the following sheet for detailed information. Parameter Function It is the max Web connection for the same device. The value ranges from 1 connection to 20. Default connection amount is 10.
  • Page 42 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual  RTSP port The default value is 554. Please leave blank if use default. User uses QuickTime or VLC can play the following formats. BlackBerry can play too.  Real-time monitoring URL format, please require real-time RTSP media server, require channel no., bit stream type in URL.

  • Page 43: Pppoe

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-13 5.2.3 PPPoE The PPPoE interface is shown as in Figure 5-14. Input the PPPoE user name and password you get from the IPS (internet service provider) and enable PPPoE function. Please save current setup and then reboot the device to get the setup activated.

  • Page 44: Ddns

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 5.2.4 DDNS The DDNS interface is shown as in Figure 5-15. The DDNS is to set to connect the various servers so that you can access the system via the server.

  • Page 45: Ip Filter

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Function Both auto and manual are “MAC addresss.dahuaddns.com”by Domain Name default, able to set prefix manually. Username The user name you input to log in the server, optional. The CN99 DDNS interface is shown as in Figure 5-16.

  • Page 46: Smtp （E-Mail)

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual If you do not check the box here, it means there is on access limit. Here you can add IP address and MAC address. You must add these addresses before enabling the trusted sites.

  • Page 47: Upnp

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-18 Please refer to the following sheet for detailed information. Parameter Function Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary.

  • Page 48: Snmp

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual In the Windows OS, From Start->Control Panel->Add or remove programs. Click the “Add/Remove Windows Components” and then select the “Network Services” from the Windows Components Wizard. Click the Details button and then check the “Internet Gateway Device Discovery and Control client” and “UPnP User Interface”.
  • Page 49 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-20 Please refer to the following sheet for detailed information. Parameter Function  SNMP Version Check SNMP v1, device only process v1 info.  Check SNMP v2, device only process v2 info.
  • Page 50 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Function Port which send Trap message, default is 162, range Trap Port 1~65535. Figure 5-21 Check SNMP v3 version and SNMP port, read community, write community, Trap address, Trap port are same with SNMP v1 and SNMP v2 versions.

  • Page 51: Bonjour

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Function Encryption Default is CBC-DES. Encryption Password not less than 8 characters. Password 5.2.9 Bonjour The Bonjour interface is shown as below. See Figure 5-22. Bonjour is based on the multicast DNS service from the Apple. The Bonjour device can automatically broadcast its service information and listen to the service information from other device.
  • Page 52 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual  Open preview, streaming media protocol, select multicast, and monitor via multicast format.  Here you can set multicast address and port. You also need to go to Live interface to set the protocol as Multicast.

  • Page 53: Qos

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-24 Please refer to the following sheet for detailed information. Parameter Function Authentication PEAP (protected EAP protocol). Username It needs the username to login, which is authenticated by the server.

  • Page 54: Event

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-25 Please refer to the following sheet for detailed information. Parameter Function Real-time The value ranges from 0 to 63. The router or the switcher can monitor provide different service for various data packets.
  • Page 55 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-26 Figure 5-27...
  • Page 56 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Here you can set arm/disarm period. Click on set button to open period Working setup menu.
  • Page 57 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-28 Different colors represent different areas. Each area can set different detection zones. Detection zone can be irregular and discontinuous. If device monitoring zone is large, user can sub-divide the area into several zones for better motion detect.

  • Page 58: Ivs Analyse

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Delete all Clear all areas. Delete Delete selected area. 5.3.2 IVS Analyse Note: Some models don’t support IVS Analyse function. See Figure 5-29. 5.3.2.1 Tripwire Figure 5-29...
  • Page 59 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-30 Parameter Note Enable Check it to enable tripwire rule. Add/Clear Click to add rule. Click to clear rule. Draw Rule Click it to draw corresponding rule in the image.
  • Page 60 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Note  It is to set the alarm period, it can enable alarm event only in the set time range.  There are six periods every day for setup and you must check box in front of each period to enable it.
  • Page 61 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 5.3.2.2 Intrusion Figure 5-31...
  • Page 62 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-32 Parameter Note Enable Check it to enable intrusion. Add/Clear Click to add rule. Click to clear rule. Draw Rule Click it to draw corresponding rule in the image. Clear Click it to clear the drawn rules.
  • Page 63 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Note  It is to set the alarm period, it can enable alarm event only in the set time range.  There are six periods every day for setup and you must check box in front of each period to enable it.
  • Page 64 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-34 Parameter Note Enable Check it to enable scene change function.  It is to set the alarm period, it can enable alarm event only in the set time range.

  • Page 65: Temperature Alarm

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Note Check it to enable alarm activation output port, the system can activate Relay out corresponding alarm output device when alarm occurs. System can delay the alarm output for specified time after alarm ended. The value Alarm Delay ranges from 10s to 300s.

  • Page 66: Fire Alarm

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Note  It is to set the alarm period, it can enable alarm event only in the set time range.  There are six periods every day for setup and you must check box in front of each period to enable it.
  • Page 67 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-36 Parameter Note Enable You need to check the box to enable local config function. It is to the minimum target which can be recognized by fire alarm, it will generate Target Size alarm when exceeding target pixel.
  • Page 68 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Note  It is to set the alarm period, it can enable alarm event only in the set time range.  There are six periods every day for setup and you must check box in front of each period to enable it.

  • Page 69: Alarm

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 5.3.5 Alarm Please note some series products do not support this function. 5.3.5.1 Alarm Figure 5-37 Parameter Note Enable Check the box to enable relay activation.  It is to set the alarm period, it can enable alarm event only in the set time range.

  • Page 70: Abnormity

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Note Enable alarm activation function. You need to select alarm output port so that Relay-out system can activate corresponding alarm device when alarm occurs. System can delay the alarm output for specified time after alarm ended. The value Alarm Delay ranges from 10s to 300s.
  • Page 71 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-39 Figure 5-40 Please refer to the following sheet for detailed information. Parameter Function Three event types to cause SD card abnormity: No SD card, SD card Event capacity warning, and SD card error.
  • Page 72 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Function SD Card User can set SD card capacity that is left free. When SD card space left Capacity is smaller than this limit, alarm occurs. Limit When device is offline or IP conflicts, the abnormal alarm is similar with case of SD card error.

  • Page 73: Temperature

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-43 5.4 Temperature Note: Some models don’t support temperature measurement function. 5.4.1 Rule Setup 5.4.1.1 Parameter Config Figure 5-44...
  • Page 74 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Note Measurement Click to add new spot, line and area, click corresponding to delete the Items measurement item. Open Local Check it to enable local config function. Config Target Radiation It is to set the target emissivity, 0~1 optional.
  • Page 75 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-45 5.4.1.2 Temperature Contrast Note: The function is only supported by some models.
  • Page 76 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-46 Temperature contrast function means comparing the temperature of selected spot, line or area and display the result on the preview interface, the steps are shown as follows: Step 1 Click to add contrast record.

  • Page 77: Global

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 5.4.2 Global Figure 5-49 Parameter Note Temperature Check it to enable temperature switch function. Switch It is to set the displayed temperature unit, ℃ and F optional. Temperature Unit Relative Humidity It is to set the environment relative humidity, 0～100% RH optional.
  • Page 78 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Note CTMaker It is to set the display temperature of low temperature. Color Isotherm It is to select if enable isotherm function. It is to set min temperature.  When gain mode is under low temperature mode, it is -40 ℃ ～ 160 ℃...
  • Page 79 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-50 5.4.2.2 Hot Spot Follow After enabling hot spot follow function, it will display max temperature spot and min temperature spot in the preview interface, and set the corresponding color via “High CTMaker Color” and “Low CTMaker Color”...
  • Page 80 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-51 Figure 5-52 5.4.2.3 Isotherm Isotherm function is mainly used for the highlighted object in the high brightness image, take medium temperature as the basis, max temperature and min temperature are the floating range, display the area between max temperature and min temperature with bright color, and other areas will be displayed as black, gray and white, see Figure 4-93.
  • Page 81 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-54 5.4.2.4 Color Code After checking color code, it will display corresponding color code on the right of the preview interface, which can be used to present the color change between min temperature and max temperature. See Figure 5-55.

  • Page 82: Heatmap

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 5.4.3 Heatmap Figure 5-56 Parameter Note Export Click it to export heatmap. Heatmap 5.5 Storage Management 5.5.1 Schedule Before schedule setup, user must set record mode is auto or manual. Note: If record mode in record control is off, then device will not snapshot according to schedule.
  • Page 83 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-57 Step 2. From Monday to Sunday select record time, click on setup on the right, see Figure 5-58.  Set period according to actual need. There are six periods available each day.
  • Page 84 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Step 4. In record schedule interface, click on OK. System prompts it is successfully saved. 5.5.1.2 Snapshot Schedule Snapshot setup as: Step 1. Click on Snapshot Schedule tab, see Figure .
  • Page 85 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Step 3. Click on OK, return to snapshot schedule interface. See Figure 5-62.  Green color stands for the general record/snapshot.  Yellow color stands for the motion detect record/snapshot. ...

  • Page 86: Destination

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Step 2. Select date to set as holiday. The selected date will be highlighted in yellow. Step 3. Check Record/Snapshot, click on Save. System prompts it is successfully saved. Step 4. Check Record Schedule/Snapshot Schedule interface, click on setup next to Holiday, refer to setup of Monday to Sunday.
  • Page 87 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-65 5.5.2.3 FTP The FTP interface is shown as in Figure 5-66. You need to check the box to enable the FTP function. When network disconnect occurred or there is malfunction.

  • Page 88: Record Control

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Figure 5-67 Parameter Function Server Address Set IP address of NAS server. Remote Set storage directory, videos and pictures can be stored in to corresponding server Directory directory. 5.5.3 Record control The record control interface is shown as in Figure 5-68.

  • Page 89: System

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Pre-record Please input pre-record value here. For example, system can record the four seconds video in the buffer. The record begins from the fifth second. Note: Configure pre-record time, when alarm or motion detection occurs, if there is no record, system will record the preceding n seconds record.
  • Page 90 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Video This is to display video standard such as PAL. Standard Language You can select the language from the dropdown list. The date and time interface is shown as in Figure 5-70.

  • Page 91: Account

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual You can set the time server address. NTP server It is to set the time server port. Port It is to set the sync periods between the device and the time server.
  • Page 92 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Enable anonymity login: Enable anonymity login, and input IP. No username or password is required, you can log in by anonymity (with limited rights). You can click logout to end your session.
  • Page 93 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Please note, the password ranges from 0-digit to 32-digit. It shall include the number and letter only. For the user who has the account rights, he can modify the password of other users.
  • Page 94 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Add group: It is to add group and set its corresponding rights. See Figure 5-74. Please input the group name and then check the box to select the corresponding rights. It includes: preview, playback, record control, PTZ control and etc.

  • Page 95: Default

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 5.6.3 Default The default setup interface is shown as in Figure 5-76. Please note system cannot restore some information such as network IP address. Figure 5-76 5.6.4 Import/Export The interface is shown as in Figure 5-77.

  • Page 96: Upgrade

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period.

  • Page 97: Information

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 5.7 Information 5.7.1 Version The version interface is shown as in Figure 5-80. Here you can view system hardware features, software version, release date and etc. Please note the following information is for reference only.

  • Page 98: Online User

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Parameter Function Set the start time of the requested log. (The earliest time is 2000/1/1) Start time Set the end time of the requested log. (The latest time is 2037/12/31) End time Log type.

  • Page 99: Alarm

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 6 Alarm Please note some series product does not support this function. Click alarm function, you can see an interface is shown as in Figure 6-1. Here you can set device alarm type and alarm sound setup.
  • Page 100 Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual Type Parameter Function Operation Prompt When alarm is triggered, there will be s inmain menu of alarm interface and system automatically records alarm info. The icon disappears when user click on alarm menu bar.

  • Page 101: Log Out

    Dahua IR Thermal Imaging Network Camera Web3.0 Operation Manual 7 Log out Click log out button, system goes back to log in interface. See Figure 7-1. Figure 7-1 Note:  This manual is for reference only. Slight difference may be found in user interface.
