- Page 1 STD6.2SS/STD6.2W Cooker Hoods...
- Page 2 User Manual for your Baumatic STD6.2SS/STD6.2W Cooker Hood NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference.
-
Page 3: Table Of Contents
CONTENTS YOUR COOKER HOOD’S SPECIFICATIONS ….……………..………….3 IMPORTANT SAFETY INFORMATION……………………………….…4-5 ENVIRONMENTAL NOTE ………….…………………………………………6 USING YOUR COOKER HOOD……………………………...……………..7 MAINTAINING AND CLEANING YOUR COOKER HOOD ……….8-10 INSTALLATION INSTRUCTIONS ……………………….……...….11-14 CARBON FILTER ………….……..11 ELECTRICAL CONNECTION………….………12 INSTALLING THE COOKER HOOD………….…13-14 TROUBLESHOOTING ……………………………………………15 CONTACT DETAILS…………………………………………………………..16 DD 14/05/08... -
Page 4: Your Cooker Hood's Specifications
Specifications of your STD6.2W Cooker Hood Congratulations on purchasing a Baumatic Cooker Hood! To fully enjoy using your appliance long into the future, please firstly familiarise yourself with its specifications, safety advice and operational instructions included in this manual. You will also need this manual to ensure that your Cooker Hood has been installed properly. -
Page 5: Important Safety Information
Important Safety Information: Any installation work must be carried out by a qualified electrician or competent person. The hood must be installed in accordance with the installation instructions and all measurements followed. If the cooker hood is installed for use above a gas appliance then the provision for ventilation must be in accordance with the Gas Safety Codes of Practice BS.6172,... - Page 6 Important Safety Information: o Ensure the ducting for the extractor function has the same diameter as the outlet hole all the way through. Keep young children from using, playing with or tampering with the cooker hood. Older children and infirm persons should be supervised if they are using the cooker hood.
-
Page 7: Environmental Note
Environmental Note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. CONFORMITY TO W.E.E.E. -
Page 8: Using Your Baumatic Cooker Hood
LIGHT ON/OFF switch - Pressing the ‘ cooker hood’s light on and off. PLEASE NOTE THAT YOUR BAUMATIC COOKER HOOD CAN BE USED EITHER IN RECIRCULATION MODE OR IN EXTRACTION MODE. TO USE IN RE-CIRCULATION MODE, YOU WILL NEED TO FIT THE CARBON FOAM. -
Page 9: Maintaining And Cleaning Your Cooker Hood
Cleaning your Baumatic Cooker Hood: Before cleaning, always ensure that you * IMPORTANT: have switched your cooker hood OFF at the omni-polar switch, set at the wall from the cable: Cleaning Clean the external parts with mild liquid detergents on a damp cloth. - Page 10 Maintenance - Cleaning the Anti-grease Filters First remove the anti- grease filter by sliding the securing nibs at the sides of the grille on the underside of the hood. You can now clean the anti-grease grille: • NOTE - After carefully rinsing and drying the anti- grease grille, put it back in place.
- Page 11 Maintenance – Changing the Light Bulb and Carbon Foam Changing the light bulb Before changing the light bulb, ensure that the appliance is not live (i.e., ensure that you have switched it off at the omni-polar switch on the wall switch plate.). Open the grease filter support grille (see previous page).
-
Page 12: Installation Instructions
Installing / Changing the Carbon Filter Your Baumatic Cooker Hood uses a CARBON and GREASE Filter to purify the air when set for air recirculation mode. You will find that one filter will attach over the front of the fan motor (please see figure at bottom of page). -
Page 13: Electrical Connection
INSTALLATION INSTRUCTIONS - Electrical Before installation and usage, read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the identification plate (found inside your Cooker Hood) and all the data inside the appliance are exactly the same as the voltage and frequency in your home. -
Page 14: Installation Instructions
INSTRUCTIONS FOR EXTRACTION FAN MODE WILL BE MARKED ‘(E)’ BELOW Your Baumatic Cooker Hood should only be fitted on a wall on the underside of a cabinet unit. Do NOT position it any less than 700 mm (70 cm) above the hob. - Page 15 IMPORTANT: Please note that if you are going to connect external ducting, the vent hose can ONLY be connected to the top of the cooker hood. There is no rear venting position.
-
Page 16: Troubleshooting
If something has gone wrong with your Cooker Hood, checking against this chart might keep you from having to call for service. Symptom The cooker hood will not start! The cooker hood is not working effectively! The cooker hood has switched off during operation! Troubleshooting •... -
Page 17: Contact Details
Technical Advice Telephone (0118) 933 6933 E-mail: sales@baumatic.co.uk technical@baumatic.co.uk Website: www.baumatic.co.uk Republic of Ireland 01- 6266 798 Baumatic CR spol s.r.o. Amperova 495 46215, Librec Czech Republic +420 800 185 263 www.baumatic.cz Slovak Republic Baumatic Slovakia, s.r.o. Skultetyho 1 831 04 Bratislava 3...
