d) Installing the Propeller
Push the plastic hexagon tappet (1) onto the shaping of the motor shaft. Install the propeller (2) on the plastic
hexagon tappet of the motor shaft and attach it with the spinner (3).
Attention!
Work carefully when attaching the spinner. The spinner must be tightened well for a tight fit. Use a tool
suitable for this (e.g. a screwdriver).
If the spinner is tightened too much, the plastic hexagon tappet is destroyed; loss of warranty/guarantee!
Figure 7
