Solax X3 Series User Manual
  1. Manuals
  2. Brands
  3. Solax Manuals
  4. Inverter
  5. X3 series
  6. User manual

Solax X3 Series User Manual

Hide thumbs Also See for X3 Series:
Table of Contents

Advertisement

Quick Links

X3 Series
User Manual
8.0kW - 15.0kW
Solax Power Network Technology(Zhe jiang) Co,. Ltd.
Copyright Declaration
The copyright of this manual belongs to Solax Power Network Technology(Zhe jiang) Co,. Ltd.. Any
corporation or individual should not plagiarize, partially or fully copy (including software,etc.), and
no reproduction or distribution of it in any form or by any means. All rights reserved. SolaX Power
Network Technology (Zhe jiang) Co.,Ltd.. reserves the right of final interpretation.
614.00336.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X3 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Solax X3 Series

Summary of Contents for Solax X3 Series

  • Page 1 (including software,etc.), and no reproduction or distribution of it in any form or by any means. All rights reserved. SolaX Power Network Technology (Zhe jiang) Co.,Ltd.. reserves the right of final interpretation.

  • Page 2: Table Of Contents

    Contents Contents 1 Note on this Manual 1.1 Scope of Validity 1.2 Target Group 1.3 Symbols Used 2 Safety 2.1 Appropriate Usage 2.2 Important Safety Instructions 2.3 Explanation of Symbols 2.4 EC Directives 3 Introduction 3.1 Basic Features 3.2 Terminals of Inverter 3.3 Dimension 4 Technical Data 4.1 DC Input...

  • Page 3: Target Group

    1 Notes on this Manual 7.1 Trouble Shooting 7.2 Routine Maintenance 1.1 Scope of Validity This manual is an integral part of X3 Series, It describes the assembly, installation, commissioning, maintenance and failure of the product. Please 8 Decommissioning read it carefully before operating.

  • Page 4: Safety

    2.1 Appropriate Usage impulse D1) for signal line according to EN 61632-1. The X3 Series are PV inverters which can convert the DC current of the PV All DC cables should be installed to provide as short a run as possible, positive generator into AC current and feed it into the public grid.

  • Page 5: Important Safety Instructions

    It contains no user-serviceable parts. See Warranty for If necessary, touch the lower temperature enclosure lid during instructions on obtaining service. Attempting to service the X3 Series operation. inverter yourself may result in a risk of electric shock or fire and will void your warranty.

  • Page 6: Explanation Of Symbols

    Safety Safety PE Connection and Leakage Current Symbols on the Inverter • All inverters incorporate a certified internal Residual Current Device(RCD) in Symbol Explanation order to protect against possible electrocution and fire hazard in case of a malfunction in the PV array, cables or inverter.There are 2 trip thresholds for Operating Display.

  • Page 7: Introduction

    Thanks for your purchasing with SolaX X3 Serial inverter. The X3 Series servicing the unit. If ignored, physical injury or death may follow, or damage inverter is one of the finest inverters on the market today, incorporating may occur to the unit.

  • Page 8: Dimension

    Introduction Technical Data 4. Technical Data Object Description DC Switch (optional) 4.1 DC input Smart plug (optional) USB for Upgrade X3-8.0P-T-D X3-12.0P-T-D X3-15.0P-T-D X3-10.0P-T-D AC Connector Model X3-12.0P-T-N X3-15.0P-T-N X3-8.0P-T-N X3-10.0P-T-N Waterproof plug Max. recommended DC power [W] A:3200/B:6400 A:4000/B:8000 A:4800/B:9600 A:6000/B:12000 Pocket WiFi/Lan/GPRS (all optional)

  • Page 9: Efficiency, Safety And Protection

    X3-12.0P-T-D X3-15.0P-T-D Model X3-12.0P-T-N X3-15.0P-T-N X3-8.0P-T-N X3-10.0P-T-N Dimension [W/H/D](mm) 534*419*201 Dimension of packing [W/H/D](mm) 600*540*300 X3 Series 8.0KW-15.0KW Net weight [kg] Gross weight [kg] Installation Wall-mounted Object Quantity Description Operating temperature range[℃] -25~+60 (derating at 45) X3 series inverter Storage temperature [℃]...

  • Page 10: Installation Precaution

    Installation Installation 5.3 Installation Precaution 5.4 Installation Steps Preparation X3 Series inverter is designed for outdoor installation (IP 65). Ø Make sure the installation site meets the following conditions: Below tools are needed before installation. Not in direct sunlight. Not in areas where highly flammable materials are stored.

  • Page 11: Connection Of The Inverter

    Ø 12AWG X3 series inverter have three couples PV connectors which can be connected in series into 3-strings PV modules. Please select PV modules with excellent function and reliable quality. Open circuit voltage of module array connected should be ＜...
  • Page 12 - Hold the middle part of the male insert, rotate the back shell to loose it, and datach it from male inset. X3 series inverter are designed for three phase grid. Rated grid voltage is 230V, - Remove the cable nut (with rubber insert) from the back shell.
  • Page 13 Installation Installation Selection of Fuses and Cables Earth Connection Ø Main cable(AC line cable)shall be short circuit protected and thermal overload Screw the ground screw with screwdriver shown as follow. (φ4 protected. hexagon wrench.torque:1.5±0.2Nm) Always fit the input cable with fuse. Normal gG(US:CC or T)fuses will protect the input cable in short circuit situation.
  • Page 14 5. Insert the cable into the RS 485/Meter port of the inverter, and tighten the waterproof connector. A meter can communicate with the X3 series inverter through this interface, then you can: 1.Monitor the energy to grid and from grid throughout the whole day.
  • Page 15 Installation Installation Upgrade 3) then insert U-disk into the USB port on the bottom of the inverter. Then turn on DC switch or connect the PV connector, the LCD will show User can update the inverter system through an U-disk. picture as below.

  • Page 16: Run The Inverter

    Installation Operation Method 6. Operation Method 5.6 Run the inverter Start inverter after checking all below steps: a) Check that device is fixed well on the wall. 6.1 Control panel b) Make sure all the DC breakers and AC breakers are disconnected. c) AC cable is connected to grid correctly.

  • Page 17: Lcd Function

    Operation Method Operation Method 6.2 LCD Function 6.3 LCD Operation Menu structure ● LCD Digital Display The main interface is the default interface, the inverter will automatically jump to this interface when the system started up successfully or not Grid Safety operated for a period of time.
  • Page 18 Operation Method Operation Method Password The default password is “0000”for end user, which only allows the user to review the current setting and some easy setting. If professional change is ﹦﹦﹦﹦ Grid ﹦﹦﹦﹦ needed, please contact with the distributor or factory for installer password. 0.0 V We need to increase or decrease the word by pressing up or down button.
  • Page 19 Operation Method Operation Method b) Date time e) RF Control This interface is for user to set the system date and time. Increase or decrease RF Control is an optional function which can control designated load the word by pressing up or down button. Press OK to confirm and alternate intelligently by consuming the surplus energy when feed in power reaches certain value.
  • Page 20 Operation Method Operation Method 4-2. ﹦﹦﹦﹦ P(freq) ﹦﹦﹦﹦ Reactive power control, Reactive standard curve cos φ = f(P) If need to reset, any changes Enable/Disable should according to the For VDE ARN 4105, curve cos φ = f(P) should refer to curve A. default values of setting are >Disable <...
  • Page 21 User can reset the meter. Press up or down button to select and press “ok” to User can check the load consumption if the device is plugged in a smart plug. confirm. (User can Select “Yes” to reset meter if user purchase SolaX meter) ﹦﹦﹦﹦ Load consume ﹦﹦﹦﹦...

  • Page 22: Troubleshooting

    -System will reconnect if the utility is back to normal. problems with X3 series inverters, and provides you with troubleshooting -Or seek help from us. tips to identify and solve most problems that could occur with the X3 series inverters. Bus Voltage Out of Normal Range This section will help you narrow down the source of any problems you may -Disconnect PV+,PV-,reconnect them.

  • Page 23: Routine Maintenance

    -Check the connection of the inverter. connected and undamaged? -Or seek help from us. Contact SolaX Customer Service for further assistance. Please be prepared to Isolation Fault Isolation Fault describe details of your system installation and provide model and serial number -Check the connection of the inverter.

  • Page 24: Decommissioning

    Decommissioning 8. Decommissioning 8.1 Dismantling the Inverter Disconnect the inverter from DC Input and AC output. Wait for 5 minutes for de-energizing. Disconnect communication and optional connection wirings. Remove the inverter from the bracket. Remove the bracket if necessary. 8.2 Packaging If possible, please pack the inverter with the original packaging.
