Tripp Lite AVRX Series Quick Start Manual

AVRX Series UPS Systems
Agency Model Numbers:
AGOM7594 • AGOM7595 • AGOM7596 • AGOM7597
AGOM7745 • AGOM7746 • AGOM7747 • AGOM7748
This document explains the most important features of your UPS system. For additional information,
download the Owner's Manual PDF (in English, French, German or Russian) from www.tripplite.com/support/manuals
Installation
1 Plug the UPS into an outlet. After plugging the UPS into a wall outlet, push the ON/OFF/TEST button for one second to turn the UPS on.
2
Plug your equipment into the UPS. Select outlets will provide battery backup and surge protection; plug your computer, monitor and
other critical devices here.* Select outlets will provide surge protection only; plug your printer and other non-essential devices here.
* Your UPS is designed to support electronic equipment only. You will overload the UPS if the total VA ratings for all the equipment you connect to the
Battery Backup/Surge Protected outlets exceeds the UPS's Output Capacity. To find your equipment's VA ratings, look on their nameplates. If the equipment
is listed in amps, multiply the number of amps by 230 to determine VA. (Example: 1 amp × 230 = 230VA). If you are unsure if you have overloaded the
Battery Backup/Surge Protected outlets, run a self-test.
Note: UPS system will function properly upon initial startup; however, maximum runtime for the unit's battery will only be accessible after it has been
charged for 24 hours.
Basic Operation
ON/OFF/TEST ON/OFF LED
Button
Important Safety Instructions
SAVE THESE INSTRUCTIONS
This manual contains instructions and warnings that should
be followed during the installation, operation and storage of
all Tripp Lite UPS Systems. Failure to heed these warnings
may affect your warranty.
UPS Location Warnings
• Install UPS indoors, away from excess moisture or heat,
conductive contaminants, dust or direct sunlight.
• Keep the indoor temperature between 32º F and 104º F
(0º C and 40º C).
• Leave adequate space around all sides of UPS for proper
ventilation.
• Do not mount unit with its front or rear panel facing down
(at any angle). Mounting in this manner will seriously
inhibit the unit's internal cooling, eventually causing
product damage not covered under warranty.
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To
return your used device, please use the return and
collection systems or contact the retailer where the
product was purchased. They can take this product
for environmental safe recycling.
Quick Start Guide
Not suitable for mobile applications.
OVERLOAD/
CHECK
BATTERY LED
UPS Connection Warnings
• Connect UPS directly to a properly grounded AC power
outlet. Do not plug UPS into itself; this will damage the
UPS.
• Do not modify the UPS's plug, and do not use an adapter
that would eliminate the UPS's ground connection.
• Do not use extension cords to connect UPS to an AC
outlet.
• If UPS receives power from a motor-powered AC
generator, the generator must provide clean, filtered,
computer-grade output.
• The mains socket outlet that supplies the UPS should be
near the UPS and be easily accessible.
• To remove AC voltage from the UPS, pull the plug from
the outlet.
Equipment Connection Warnings
• Use of this equipment in life support applications where
failure of this equipment can reasonably be expected
to cause the failure of the life support equipment or
to significantly affect its safety or effectiveness is not
recommended.
• Do not connect another UPS, surge suppressors or
extension cords to the output of UPS. This might damage
the UPS and may affect the surge suppressor and UPS
warranties.
• Connect the UPS to an outlet that is adequately
protected against excess currents, short circuits and
earth faults, as part of the building installation. The
outlet protection for the UPS should be in series with the
mains input.
Battery Backup/ Surge-Only
Surge Protected Protected
Outlets Outlets
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2018 Tripp Lite. All rights reserved.
Tel/DSL/ Communications Port
Ethernet Line (Select models only. For use
Protection with included USB cable.)
Battery Warnings
• Your UPS does not require routine maintenance. Do
not open your UPS for any reason. There are no user-
serviceable parts inside.
• Batteries can present a risk of electrical shock and
burn from high short-circuit current. Observe proper
precautions. Do not dispose of the batteries in a fire. Do
not open the UPS or batteries. Do not short or bridge the
battery terminals with any object. Unplug and turn off the
UPS before performing battery replacement. Use tools
with insulated handles. There are no user-serviceable
parts inside the UPS. Battery replacement should be
performed only by authorized service personnel using the
same number and type of batteries (Sealed Lead-Acid).
The batteries are recyclable. Refer to your local codes
for disposal requirements or visit www.tripplite.com/
UPSbatteryrecycling for recycling information.
Tripp Lite offers a complete line of UPS System
Replacement Battery Cartridges (R.B.C.).Visit Tripp Lite
on the Web at www.tripplite.com/support/battery/index.
cfm to locate the specific replacement battery for your
UPS.
Tripp Lite has a policy of continuous improvement. Product
specifications are subject to change without notice.
