Start-up and operation

Teach-in

WARNING
Risk of crushing due to unintentional start-up of the RollerDrive!
Changes in this menu have direct influence on the connected RollerDrive!
¾
Before starting motors make sure, ensure that no persons are present in the hazardous areas surrounding
¾
the conveyor system!
Teach-in Feature
Please read the manual before trigger any of the options below!
Init
Start
Finish
Abort
Submit Reset
Plug&Play
Plug and Play Feature
Enabled Submit

The "Teach-in" and "Plug&Play" functions are described in the "MultiControl / RollerDrive - Start-up and
Programming" supplement.

CAN Gateway

CAN Bus Terminal
Mode Node ID SDO Idx
Read dec num hex num
Write
Send
Node 0>> Response: Unknown, Error: 0
Only used for service purposes.
