This is the Sea Acceptance Test for the Simrad SC90 Fish finding sonar.
The purpose of this Sea Acceptance Test is to verify the operational
functionality of the SC90 that can only be fully tested with the vessel
at sea. The test assumes that the Harbour Acceptance Test has been
previously done on the same SC90 system. When all the tasks have
been done, the report form must be signed by the relevant parties. The
completed document then becomes the official report.
Vessel/Customer
Serial numbers (if applicable)
Processor Unit
Operating Panel
Transceiver Unit
Power Supply Unit
Hull Unit
Transducer
Simrad SC90
Fish finding sonar
Sea Acceptance Test
May 2018 © Kongsberg Maritime AS
428860/A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simrad SC90

Summary of Contents for Simrad SC90

  • Page 1 Fish finding sonar Sea Acceptance Test This is the Sea Acceptance Test for the Simrad SC90 Fish finding sonar. The purpose of this Sea Acceptance Test is to verify the operational functionality of the SC90 that can only be fully tested with the vessel at sea.
  • Page 2 If you require maintenance or repair, contact your local dealer. You can also contact us using the following address: simrad.support@simrad.com. If you need information about our other products, visit https: //www.simrad.com. On this website you will also find a list of our dealers and distributors. Kongsberg Maritime AS www.kongsberg.com...

  • Page 3: Table Of Contents

    Hull Unit.........................15 Transducer ......................15 TESTING THE SC90 OPERATIONAL FUNCTIONALITY ..... 16 Turning on the SC90 to start the functional test..............16 Testing the Operating Panel to verify basic functionality..........17 Testing the user interface to verify basic functionality ............21 Verifying that the Transceiver Unit is transmitting on all channels.........23 Verifying SC90 operation by means of the BITE functionality........24...
  • Page 4 Verifying the physical dimensions of the ship ..............52 Adjusting the offset angle between the motion sensor and the direction of the transducer ........................53 CREATING A BACKUP WITH THE SC90 CONFIGURATION AND SOFTWARE INSTALLATION......... 56 About SC90 software backup and restore................56 Creating a Processor Unit image on a USB flash drive using the Acronis True Image program ........................57...

  • Page 5: Introduction

    Introduction Introduction Topics Purpose, page 6 Personnel and location, page 6 Referenced documents, page 6 Tools and test equipment, page 7 428860/A...

  • Page 6: Purpose

    The purpose of this Sea Acceptance Test is to verify the operational functionality of the SC90 that can only be fully tested with the vessel at sea. The test assumes that the Harbour Acceptance Test has been previously done on the same SC90 system. When all the tasks have been done, the report form must be signed by the relevant parties.

  • Page 7: Tools And Test Equipment

    EC Declaration of Conformity Tools and test equipment Specific tools and test equipment are required for this Simrad SC90 Sea Acceptance Test. The required tools and equipment must be made available before the test can start. Specific test equipment is not required for this test. The following tools are required.

  • Page 8: Acceptance Test Summary

    The purpose of this Sea Acceptance Test is to verify the operational functionality of the SC90 that can only be fully tested with the vessel at sea. This acceptance test summary is provided to offer an overview of the functions and items that need to be tested.

  • Page 9: Hardware And Software Registration

    Hardware and software registration Hardware and software registration Topics Verification of previously tested items, page 10 Software items, page 11 Hardware items, page 12 428860/A...

  • Page 10: Verification Of Previously Tested Items

    Verification of previously tested items Neither user interface software nor hardware units have been changed on this SC90 system since the Harbour Acceptance Test. For this reason, the registration tables have not been filled out. Date and signature...

  • Page 11: Software Items

    Every software program that is provided as a part of the SC90 delivery must be registered. Part number and software version must be registered. When software media (USB flash drive, CD, DVD etc) is provided, the part number of the media and the SC90 software version provided on the media must be registered.

  • Page 12: Hardware Items

    Serial number Revision Fill in the make, model and serial number for each unit that is provided with the SC90 delivery. If applicable, add the order number. The unit contains neither circuit boards nor modules that need to be identified separately.

  • Page 13: Transceiver Unit

    The unit contains neither circuit boards nor modules that need to be identified separately. Transceiver Unit The Transceiver Unit provided with the SC90 delivery must be uniquely identified. Make, model, part number and serial number must be registered. The Transceiver Unit contains circuit boards and modules that must be recorded separately.

  • Page 14: Power Supply Unit

    The unit contains neither circuit boards nor modules that need to be identified separately. Power Supply Unit The Power Supply Unit provided with the SC90 delivery must be uniquely identified. Make, model, part number and serial number must be registered.

  • Page 15: Hull Unit

    The hull unit provided with the SC90 delivery must be uniquely identified. Type, part number and serial number must be registered. Several different hull units are available for the SC90, each with different characteristics. Only one hull unit is supplied with the delivery.

  • Page 16: Testing The Sc90 Operational Functionality

    The SC90 program starts automatically when the Processor Unit is turned on. TX Power is by default set to Off. Caution You must never start SC90 transmissions ("pinging") when the ship is in dry dock. The transducer may be damaged if it transmits in open air. 428860/A...

  • Page 17: Testing The Operating Panel To Verify Basic Functionality

    Testing the Operating Panel to verify basic functionality The Operating Panel contains all necessary control functions for normal operation of the SC90. A test is required to verify that the Operating Panel is fully functional, and that the communication with Processor Unit is operational. Prerequisites The SC90 is installed as specified in the SC90 Installation manual.
  • Page 18 The Operating Panel contains all necessary control functions for normal operation of the SC90. The controls provided by the Operating Panel are arranged in logical functional groups. This offers you clear and easy operation with fast access to key functionality.
  • Page 19 Testing the SC90 operational functionality Use the trackball on the Operating Panel, and move the cursor to the echo area. Press . Verify that a numbered triangle Target Marker appears in the current position of the cursor. Press . Verify that a square symbol Own Ship Marker appears at the ship’s symbol.
  • Page 20 Simrad SC90 Sea Acceptance Test Select to open the menu. Horizontal Press repeatedly. Verify that the range read-out on the Range H- Range H+ menu and on the top of the tilt indicator changes accordingly. Horizontal Click to open the menu.

  • Page 21: Testing The User Interface To Verify Basic Functionality

    Date and signature: Testing the user interface to verify basic functionality A functional test is done with the SC90 system assembled as a complete product. Prerequisites The SC90 is installed as specified in the SC90 Installation manual. • The SC90 is turned on, and it is working normally.
  • Page 22 Simrad SC90 Sea Acceptance Test Caution You must never set the SC90 to "ping" unless the transducer is submerged in water. The transducer may be damaged if it transmits in open air. Procedure Make sure that the SC90 user interface is fully operational.

  • Page 23: Verifying That The Transceiver Unit Is Transmitting On All Channels

    Testing the SC90 operational functionality Verifying that the Transceiver Unit is transmitting on all channels The SC90 offers 480 transceiver channels. It is important to verify that the SC90 is transmitting on all the channels. Prerequisites The SC90 is installed as specified in the SC90 Installation manual.

  • Page 24: Verifying Sc90 Operation By Means Of The Bite Functionality

    The page allows you to monitor the time series of data that is received from each B-Scan of the elements in the SC90 transducer. The start sample and the number of samples to be displayed are adjustable. Prerequisites The SC90 is installed as specified in the SC90 Installation manual.
  • Page 25 B-Scan each of the elements in the SC90 transducer. The start sample and the number of samples to be displayed are adjustable. When you move the cursor over the B-Scan presentation of the SC90 transceiver channels, each element in the transducer is clearly identified as a long coloured vertical rectangle.
  • Page 26 Sample range These settings allow you to test the receiver performance. The sample frequency in the SC90 is 5 kHz. Since the sound travels approximately 750 meter back and forth every second, each sample will cover 750 m divided by 5000 Hz, which is approximately 15 cm.
  • Page 27 Testing the SC90 operational functionality Related topics Opening the BITE (Built-In Test Equipment) dialog box, page 62 428860/A...

  • Page 28: Testing The Noise Conditions

    Low noise is a key factor for high quality and reliable measurements. The performance of the SC90 will always be limited by different noise sources. A high noise level will mask the echoes and make them difficult to read and interpret. The noise is measured while the SC90 operates in Passive mode with the transmit pulses disabled.
  • Page 29 Echo Level System Test Adjust the until the echoes on the images on the SC90 presentation are Gain dynamic, and you can distinguish between the individual echoes. Read the current echo level displayed by the "button".

  • Page 30: Making A Noise/Speed Curve To Determine Vessel Noise

    Prerequisites The SC90 is turned on, and it is working normally. The vessel is at sea. Recommended minimum depth is 100 metres. If the SC90 is operated from any other compartment than the bridge, an open two-way oral communication channel with the bridge is required.
  • Page 31 Repeat the following cycle for each vessel speed: Ask the bridge to set the speed. Observe the parameter dialog box in the bottom right corner of the SC90 Status presentation. Make sure that the dialog box presents the requested speed.
  • Page 32 Simrad SC90 Sea Acceptance Test Result Speed/Noise Speed Bearing –120° –60° 0° +60° +120° +180° Sea state: Water depth: Use this table to record the noise values, or write them straight into a spreadsheet. 428860/A...
  • Page 33 Testing the noise conditions Use the following plot to record the noise values for 0° bearing. Make additional copies if required, or use the functionality of the spreadsheet program. 428860/A...
  • Page 34 Simrad SC90 Sea Acceptance Test Results Requirements A noise/speed curve is created. Date and signature: 428860/A...

  • Page 35: Testing The Interfaces With Peripheral Devices

    Prerequisites This procedure assumes that: • The sensor is connected to the SC90. It is switched on and in normal operation. • The interface port is set up with the correct communication parameters. • You are familiar with NMEA and other relevant datagram formats.
  • Page 36 Simrad SC90 Sea Acceptance Test • The SC90 is turned on, and it is working normally. Neither tools nor instruments are required. Context Most global positioning system (GPS) receivers provide NMEA 0183 datagrams containing geographical latitude and longitude information, as well as current speed and sailed distance.

  • Page 37: Verifying The Communication With Speed Log

    The relevant communication parameters are recorded. Date and signature: Verifying the communication with speed log In order to operate correctly, the SC90 requires input from a speed log. The current speed is shown in the parameter dialog box. The communication with the sensor is tested.
  • Page 38 Simrad SC90 Sea Acceptance Test prevent the SC90 from providing correct echo information. In most cases a suitable sensor is already installed on the vessel. A global positioning system (GPS) with a fitting output format can also be used. The communication parameters defined for...

  • Page 39: Verifying The Communication With The Course Gyro

    • The SC90 is turned on, and it is working normally. Neither tools nor instruments are required. Context The input from a course gyro is essential for SC90 operation. Without the input from a course gyro, the SC90 will not be able to present correct navigational information. In 428860/A...
  • Page 40 The test is therefore repeated using more realistic sensor data. Procedure Observe the parameter dialog box in the bottom right corner of the SC90 Status presentation. Make sure that the dialog box presents the current information from the navigation sensors: Position, Heading and Speed.

  • Page 41: Verifying The Communication With The Motion Reference Unit (Mru)

    Prerequisites This procedure assumes that: • The sensor is connected to the SC90. It is switched on and in normal operation. • The interface port is set up with the correct communication parameters. • You are familiar with NMEA and other relevant datagram formats.
  • Page 42 Test Setup System Test Select to open the menu. Installation menu Observe that the menu opens across the top of the SC90 Installation presentation. → → On the menu, select Installation Installation I/O Setup...
  • Page 43 Testing the interfaces with peripheral devices Result Motion Reference Unit Talker ID Port Baud rate Source system Timeout Requirements Results Motion compensation is operational. The compensated values are shown. Date and signature: 428860/A...

  • Page 44: Verifying The Installation Parameters

    Simrad SC90 Sea Acceptance Test Verifying the installation parameters Topics Verifying the alignment of the SC90 presentation (SC90), page 45 Verifying the alignment of the SC90 presentation (SC94), page 47 Verifying the installation parameters for the global positioning system (GPS) antenna, page 49...

  • Page 45: Verifying The Alignment Of The Sc90 Presentation (Sc90)

    When the hull unit is placed on the trunk, the "forward" mark on the transducer shaft sleeve - and thus also the transducer - are both misaligned. To obtain accurate SC90 presentations, this must be adjusted. Note that this task is only relevant for the SC90 Hull Unit.
  • Page 46 Make sure that the estimated alignment angle is correct, adjust the angle if required. Select to save the settings and close each parameter dialog box. Result Requirements Results The SC90 presentation is aligned to the direction of the transducer. The alignment value is recorded. Alignment value: Date and signature: 428860/A...

  • Page 47: Verifying The Alignment Of The Sc90 Presentation (Sc94)

    When the hull unit is placed on the trunk, the "forward" mark on the transducer shaft sleeve - and thus also the transducer - are both misaligned. To obtain accurate SC90 presentations, this must be adjusted. Note that this task is only relevant for the SC94 Hull Unit.
  • Page 48 Make sure that the estimated alignment angle is correct, adjust the angle if required. Select to save the settings and close each parameter dialog box. Result Requirements Results The SC90 presentation is aligned to the direction of the transducer. The alignment value is recorded. Alignment value: Date and signature: 428860/A...

  • Page 49: Verifying The Installation Parameters For The Global Positioning System (Gps) Antenna

    Verifying the installation parameters for the global positioning system (GPS) antenna Information from a few key sensors are vital for the SC90 accuracy. In order to achieve maximum accuracy, the physical locations of these sensors - normally referred to the Ship Origin - must be recorded in the SC90 setup.

  • Page 50: Verifying The Installation Parameters For The Transducer

    Verifying the installation parameters for the transducer Information from a few key sensors are vital for the SC90 accuracy. In order to achieve maximum accuracy, the physical locations of these sensors - normally referred to the Ship Origin - must be recorded in the SC90 setup.
  • Page 51 Test Setup System Test Select to open the menu. Installation menu Observe that the menu opens across the top of the SC90 Installation presentation. → → Select to open the OwnShip Instrument Position Offsets Transducer Transducer parameter dialog box.

  • Page 52: Verifying The Physical Dimensions Of The Ship

    SC90 software. Prerequisites For the accurate locations of the ship dimensions, you need the detailed vessel drawings. Neither tools nor instruments are required. The SC90 is turned on, and it is working normally. Procedure Open the menu.

  • Page 53: Adjusting The Offset Angle Between The Motion Sensor And The Direction Of The Transducer

    The information from a motion reference unit (MRU) (normally heave, roll and pitch information) is imported into the SC90 to increase the accuracy of the echo data. The SC90 is provided with a built-in motion sensor. It is placed inside the Motor Control Unit.
  • Page 54 Test Setup System Test Select to open the menu. Installation menu Observe that the menu opens across the top of the SC90 Installation presentation. → Select Installation Alignment Select Offset Insert the estimated alignment offset angle.
  • Page 55 Verifying the installation parameters Result Requirements Results The offset angle between the motion sensor and the direction of the transducer is defined. The offset value is recorded. Offset value: Date and signature: 428860/A...

  • Page 56: Creating A Backup With The Sc90 Configuration And Software Installation

    Creating a bootable USB flash drive using the Acronis True Image program, page 60 About SC90 software backup and restore Once all SC90 configuration and testing have been finalized, it is good practice to back up the configuration data and software installation. Software backup is provided using dedicated software applications and commercial storage devices.

  • Page 57: Creating A Processor Unit Image On A Usb Flash Drive Using The Acronis True Image Program

    Prerequisites To create the backup image, you need the bootable USB flash drive provided with the SC90. You can also use any commercial USB flash drive, but it must be bootable, and it must have the necessary storage capacity. Context The software in use is created by Acronis.

  • Page 58: Restoring A Processor Unit Image From A Usb Flash Drive Using The Acronis True Image Program

    If you restore your Processor Unit from a generic image, you must change the Windows license and then activate it before you can use the SC90. You must also reinstall the SC90 software. We recommend that you use the image you made after the SC90 installation was completed.
  • Page 59 Creating a backup with the SC90 configuration and software installation The software in use is created by Acronis. For more information about this company and their products, see their website: • http://www.acronis.com Procedure Boot the Processor Unit from the USB flash drive.

  • Page 60: Creating A Bootable Usb Flash Drive Using The Acronis True Image Program

    Creating a bootable USB flash drive using the Acronis True Image program A bootable USB flash drive is required for SC90 backup purposes. The software used is Acronis True Image. The software is installed on the Processor Unit. It is also copied onto the USB flash drive that is provided with the SC90.

  • Page 61: Customer Acceptance Form

    When this test procedure has been completed with all relevant signatures and applicable forms filled in, the document must be sent to the Simrad Support Department at Strandpromenaden 50, P.O.Box 111, 3191 Horten, Norway. Alternatively, scan all the pages to PDF using minimum 200 DPI resolution, and send the file to simrad.support@simrad.com.

  • Page 62: Secondary Procedures

    • B-Scan page allows you to monitor the time series of data that is received from B-Scan each of the elements in the SC90 transducer. The start sample and the number of samples to be displayed are adjustable. 428860/A...
  • Page 63 Observe the main menu in the dialog box. → Select File Object Inspector In the dialog box, double-click Object Inspector BiteActivator Observe that the (Built In Test Equipment) dialog box opens. BITE Related topics Verifying SC90 operation by means of the BITE functionality, page 24 428860/A...
