READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THIS APPLIANCE
Revision 1.0
MODEL NUMBER: BGBS26
Contents
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
3
4
5
6-8
9-10
11-12
Advertisement
Related Manuals for Memphis Beale Street BGBS26
Summary of Contents for Memphis Beale Street BGBS26
- Page 1 MODEL NUMBER: BGBS26 Contents Grill Clearance to Combustible Materials Grill Island Dimensions Hardware Kit Installation Recommendations Installation Step 1-5 9-10 WiFi Setup 11-12 Wiring Diagram READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THIS APPLIANCE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE Revision 1.0...
- Page 2 Clearance To Combustible Materials WARNING: The structure and surrounding objects MUST maintain the specified minimum clearance to combustible materials. Built-in structures constructed of wood or other combustible materials may require the use of the OPTIONAL Built- In Heat Shield Kit to maintain the required clearance to combustible materials.
- Page 3 Built-In Grill Island Dimensions WARNING: See clearance to combustible materials, when designing and constructing a built-in island. Built-In islands must be built to the specifications listed below. The owner and/or builder are responsible for consulting local, county and state building codes for securing any necessary building permits before construction.
- Page 4 HARDWARE COMPONENTS CONT. HARDWARE COMPONENTS DESCRIPTION/PART QTY: QTY: DESCRIPTION/PART PICTURE PICTURE 8) Left Mounting Bracket 1) Grate Kit BG8002 VG4409 2) Savorizer BG2700 3) Bracket Bolt 9) Right Mounting Bracket BG8003 DS2311 4) Antenna VG9025 10) Rear Mounting Bracket BG8001 OPTIONAL 11) HEAT SHIELD 5) #10 Screw (SS)
- Page 5 31 1/2" X 22 1/4". DEDICATED ELECTRICAL CIRCUIT WITH GFCI PROTECTED OUTLET A dedicated GFCI protected electrical circuit is required for all Memphis Wood Fire Grills and controller systems. This circuit should be installed by a Certified Electrician. Although the Memphis Grill only uses about 4 amps of current during startup, any other equipment (refrigerator, pool pump, fountains, ect.) that...
- Page 6 INSTALLATION STEP 1: UNPACKING Grill requires (2) two people for safe assembly Please note that during shipping some movement may have taken place, so a complete visual inspection is required. Be sure to inspect entire grill after removing the protective shipping carton. Report any damage to your local dealer immediately.
- Page 7 INSTALLATION STEP 3: BRACKETS Follow the assembly steps listed below, prior to installation of the unit. The unit is mounted by the support brackets (items 8, 9 & 10). Refer to page 4 for item part numbers, descriptions and quantities. 4) Remove the ash/grease drawers from the unit.
- Page 8 INSTALLATION STEP 5: FINAL ASSEMBLY Refer to page 4 for item part numbers, descriptions and quantities 14) Insert the ash/grease drawer back into the unit. 15) Place Savorizer (item 2) onto the left and right lower brackets found inside the unit. 16) Place the four lower cook grates (item 1) onto the front and rear supports.
- Page 9 MEMPHIS WI-FI SET UP GUIDE ON YOUR GRILL CONTROLLER: 1) A Wi-Fi connection can be set up in minutes on your Memphis Wood Fire Grill. First power the grill on pressing the upper left button on the controller, and from the home screen press the lower left button “MENU”, then the bottom right button “DOWN ARROW”, and then the...
- Page 10 Nickname is not case sensitive. Nickname is not case sensitive. If this is the first time adding the grill and the nickname shows Memphis on the grill If this is the first time adding the grill and the nickname shows Memphis on the grill it will ask for a new grill nickname.
- Page 12 Load and Neutral wires. Fuse holder MOV + Fuse Holder black shrink wrap. Fuse holder is that accepts cylindrical and white plastic. CONTACT YOUR DEALER OR MEMPHIS GRILLS TECHNICAL SERVICE WITH ANY QUESTIONS. TECHNICAL SERVICE NUMBER: 1-888-883-2260...
