AT&T PARTNER Plus Programming Quick Reference Manual page 4

Place the Programming Overlay on the dial pad of the system display phone at extension 10 or 11
P+ > R 3.0, PII > R1.0
TO START SYSTEM PROGRAMMING TO END SYSTEM PROGRAMMING
PRESS [ ] [ ] [ ]
Feature 0 0
PRESS [ ]
System Program
PRESS [ ]
System Program
System
SYSTEM DATE
P+ > R1.0
PII > R1.0
DIAL #101
DIAL the date in MMDDYY form
SYSTEM DAY
P+ > R1.0
PII > R1.0
DIAL #102
DIAL 1 = Sunday
2 = Monday
3 = Tuesday
4 = Wednesday
SYSTEM TIME
P+ > R1.0
PII > R1.0
DIAL #103
DIAL the time in HHMM 24-hour
military format
NUMBER OF LINES
*See IMPORTANT on facing page
P+ > R1.0
PII > R1.0
DIAL #104
DIAL two digits (01–12 P+, 01–24 PII)
for the number of outside lines to
be assigned to every extension
2 per 206 or 200 module
4 per 400 module
TRANSFER RETURN RINGS
P+ > R1.0
PII > R1.0
DIAL #105
DIAL one digit (0–9) for the number
of rings before the call returns
=4 rings
0 rings = no return
RECALL TIMER DURATION
P+ > R1.0
PII > R1.0
DIAL #107
DIAL two digits (01–80) to set the
length of a switchhook flash
=18 (450 msec)
4
System Programming Quick Reference
PRESS [ ] [ ] [ ]
Feature 0 0
TO USE A SPECIFIC PROCEDURE
DIAL [ ] and three-digit procedure code
#
Example: [ ] [ ] [ ] [ ] for System
# 1 0 1
Date
ROTARY DIALING TIMEOUT
P+ > R1.0
(p. 5-135)
PII > R1.0
(p. 5-178)
DIAL #108
DIAL 1 = 4 sec
2 = 8 sec
OUTSIDE CONFERENCE DENIAL
(p. 5-136)
(p. 5-179) P+ > R1.0
PII > R1.0 ≠ R2.0
DIAL #109
5 = Thursday
6 = Friday
DIAL 1 = Allowed
7 = Saturday
2 = Disallowed
AUTOMATIC SYSTEM ANSWER
DELAY
PII > R3.0
(p. 5-142)
(p. 5-185)
DIAL #110
DIAL a ring delay number (0–9)
AUTOMATIC SYSTEM ANSWER
BUTTON
PII > R3.0
(p. 5-108)
DIAL #111
(p. 5-143)
DIAL 1 = Assigned
2 = Not Assigned
3 = Select Button then press
DIRECT EXTENSION DIAL DELAY
PII > R3.0
DIAL #112
DIAL a ring delay number (0–9)
(p. 5-150)
(p. 5-194)
DIRECT EXTENSION DIAL BUTTON
PII > R3.0
DIAL #113
DIAL 1 = Assigned
(p. 5-120)
(p. 5-162)
ASA & DXD RECORD/PLAYBACK
ASA = I891
DXD = I892
TO CYCLE THROUGH SYSTEM
PROGRAMMING PROCEDURES
PRESS [
Next Procedure
NOTES:
Procedures #399, #609,
and #728—shown below in dashed
boxes—are skipped when cycling.
(p. 5-122)
(p. 5-164)
3 = 12 sec
(p. 5-113)
(p. 5-148)
(p. 5-24)
= 2 rings
(p. 5-21)
a programmable button
(p. 5-62)
= 2 rings
(p. 5-59)
2 = Not Assigned
3 = Select Button then press
a programmable button
2 = Play
1 = Record
# = Stop
TO CYCLE THROUGH AVAILABLE
SETTINGS
] PRESS [
] or [
Next Data
Prev Procedure
TO RETURN TO FACTORY
SETTING
PRESS [
Remove
OUTGOING CALL RESTRICTION
BUTTON
P+ > R3.1
PII > R3.1
DIAL #114
DIAL 1 = Assigned
2 = Not Assigned
3 = Select Button then press
a programmable button
WAKE UP SERVICE BUTTON
P+ > R3.1
PII > R3.1
DIAL #115
DIAL 1 = Assigned
2 = Not Assigned
3 = Select Button then press
a programmable button
CALL COVERAGE RINGS
PII > R4.0
DIAL #116
DIAL one digit (1–9) for the number
of rings before the call is sent to
the covering extension
= 2 rings
VMS COVER RINGS
P+ > R4.0
PII > R4.0
DIAL #117
DIAL one digit (1–9) for the number
of rings before the call is sent
to the voice messaging system
= 3 rings
RING ON TRANSFER
P+ > R4.1
PII > R4.1
DIAL #119
DIAL 1 = Active
2 = Not Active
AUTOMATIC SYSTEM ANSWER
MODE
PII > R4.1
DIAL #121
DIAL 1 = Hold
2 = Disconnect
3 = Ring
] or [ ]
Prev Data
]
(p. 5-111)
(p. 5-146)
(p. 5-160)
(p. 5-204)
(p. 5-40)
(p. 5-153)
(p. 5-197)
(p. 5-121)
(p. 5-163)
(p. 5-27)
