Installation Job Aid for Avaya Virtual
Services Platform 8200
Support
Go to the Avaya Support website at
documentation, product notices, and knowledge articles. You can also search for release notes,
downloads, and resolutions to issues. Use the online service request system to create a service
request. Chat with live agents to get answers to questions, or request an agent to connect you to a
support team if an issue requires additional expertise.
Safety messages
Caution:
To protect the switch against ESD damage, take the following measures before you connect
data cables to the device:
• Always use antistatic wrist straps. Make sure you adjust the strap to provide good skin
contact.
• Ensure that you properly ground work surfaces and equipment racks for protection against
electrostatic discharge. You must connect the common point to the building ground wire. In
a properly wired building, the nearest reliable ground is typically at the electrical outlet.
• Avoid contact between equipment and clothing. The wrist or ankle strap protects only the
equipment from ESD voltages on the body; ESD voltages on clothing can still cause
damage.
• Avoid touching any connector pins.
• Do not remove the wrist or ankle strap until the installation is complete.
Caution:
When you mount this device in a rack, do not stack units directly on top of one another. You
must secure each unit to the rack with appropriate mounting brackets. Mounting brackets
cannot support multiple units.
©
2015 Avaya Inc.
http://support.avaya.com
Installation Job Aid for Avaya Virtual Services Platform 8200
for the most up-to-date
Release 4.0.50.0
NN47227-304
Issue 01.03
June 2015
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avaya Virtual Services Platform 8200
Summary of Contents for Avaya Virtual Services Platform 8200
- Page 1 When you mount this device in a rack, do not stack units directly on top of one another. You must secure each unit to the rack with appropriate mounting brackets. Mounting brackets cannot support multiple units. © 2015 Avaya Inc. Installation Job Aid for Avaya Virtual Services Platform 8200...
-
Page 2: Technical Specifications
Warning: The lithium battery is not field replaceable. It should be removed and replaced by authorized personnel only. Contact Avaya Technical Support for assistance if the battery requires replacement. Warning: Fiber optic equipment can emit laser or infrared light that can injure your eyes. Never look into an optical fiber or connector port. -
Page 3: Installing A Power Supply
• If you only have one power supply, you can install it in either PSU1 or PSU2. • If you install a second power supply, neither one acts as a primary power supply. The two power supplies load share equally. June 2015 Installation Job Aid for Avaya Virtual Services Platform 8200... -
Page 4: Installing An Ac Power Supply
Important: Avaya does not support installing a combination of AC-input and DC-input power supplies in the same chassis. To install an AC power supply, see Installing an AC power supply. To install a DC power supply, see Installing a DC power supply. -
Page 5: Ac Power Supply Specifications
You must have either a power supply or a power supply cover in each bay to ensure proper ventilation. Leaving a power supply bay unpopulated or uncovered impairs the ability of the fans to cool the chassis. Figure 1: AC power supply June 2015 Installation Job Aid for Avaya Virtual Services Platform 8200... -
Page 6: Ac Power Cord Specifications
• CEE7 standard VII male plug • 50 Hz • Harmonized cord (HAR marking on the outside of the cord • Single phase jacket to comply with the CENELEC Harmonized Document HD-21) Table continues… June 2015 Installation Job Aid for Avaya Virtual Services Platform 8200... -
Page 7: Installing A Dc Power Supply
Installing a DC power supply Important: Avaya does not support installing a combination of AC-input and DC-input power supplies in the same chassis. The VSP 8284XSQ supports two field-replaceable 800 W power supplies. One comes with the switch and you can install a second power supply to provide redundancy and load sharing. - Page 8 4. Once you install a power supply, use the following steps to connect the dongle: a. Avaya supplies a universal dongle to connect the DC power supply to the DC input power source. However, Avaya does not supply the cables for connecting the DC power supply to the DC input power source.
- Page 9 If it is green, the power supply is operating normally. The following table describes all the LED states. Table 6: DC power supply LED states Color and Status Description There is no DC power to either power supply. Table continues… June 2015 Installation Job Aid for Avaya Virtual Services Platform 8200...
-
Page 10: Dc Power Supply Specifications
Note that regulatory power specifications are based on the maximum rated capacity of the power supplies and are not based on typical power consumption, which is typically lower. June 2015 Installation Job Aid for Avaya Virtual Services Platform 8200... -
Page 11: Installing The Switch In An Equipment Rack
Procedure 1. Disconnect the power cord from the switch. 2. Attach a bracket to each side of the switch using a #2 Phillips screwdriver as illustrated below. June 2015 Installation Job Aid for Avaya Virtual Services Platform 8200... - Page 12 2–post rack, attach the bracket in the location recessed 150 mm from the front of the chassis. 3. Slide the switch onto a shelf or tray in the rack. June 2015 Installation Job Aid for Avaya Virtual Services Platform 8200...
- Page 13 4. Insert and tighten the rack-mount screws. 5. Verify that the switch is securely fastened to the rack. 6. Connect power and network connections to the switch. June 2015 Installation Job Aid for Avaya Virtual Services Platform 8200...
