IKA RC 2 GREEN control Operating Instructions Manual page 21

3� Delete:
Deletes the selection highlighted in yellow program�
1) OK: Confirm the process�
2) Cancel: Cancels the process�
4� View:
Temperature-time overview displays for the program with
segments of the selected program�
Note: If hysteresis is set as "Ctrl�Mode +/-x�xx K" for one
or more segments in the program, the duration of the pro-
gram cannot be determined�
Press and turn the knob (R) to display the segment details�
Once the program has been started, the program no�, seg-
ment no� (active/total) and the remaining duration of the
segment or hysteresis are displayed in the graph�
OUTGAS
In the option, the user is allowed to set the outgas speed
in range of 2000 rpm to 4000 rpm and outgas interval
from 10 seconds to 240 seconds�
This function can be used when filling external devices
such as laboratory reactors�
SAFETY
1� Time out:
1) Set:
In the menu "Set", the user can determine a time limit in
the event of a communication breakdown between the
station and the WiCo� The station continues to work with
the preset target values until the preset time value has
expired� Following that, the station runs using the preset
safety temperature and safety speed�
Note: The initial time out is 30 seconds and the user can
define up to 60 minutes for this time limit�
2) Speed:
In the "Speed" menu, the user can specify a appropriate
and safe speed for specified temperature�
Note: The factory setting of the safe speed is 2000 rpm
and is activated after the time limit is set (see "Set")�
3) Temperature:
In the "Temperature" menu, the user can specify a temper-
ature that is appropriate and safe for the circulating task�
Note: The initial safe temperature is 30 ºC and is activated
after the time limit is set (see "Set")�
2� Password:
In the "Password" menu, the menu settings can be locked
by a 3-digit password�
SETTING
1� Languages:
The "Language" option allows the user to select the de-
sired language�
2� Display:
The "Display" option allows the user to change the back-
ground color and brightness of the working screen�
3� Sound:
The "Sound" option allows the user to activate/deactivate
the key tone�
4� Factory Settings:
Select the "Factory settings" option by turning and pressing
the rotary/push knob� The system requests confirmation to
restore the factory settings� Pressing the "OK" button re-
sets all the system settings to the original standard values
set at dispatch from the factory (see "Menu structure")�
5� Communication:
The "Device name" menu option allows you to edit the
device name� This can relatively identify the paired station�
The "Bluetooth " menu option allows you to activate/de-
®
activate the "Bluetooth " function� A check mark shows
®
that the option is activated�
6� Information:
The "Information" option offers the user an overview of
the most important system settings of the device�
21
