INSTRUCTIONS FOR SAFE OPERATION AND MAINTENANCE
Understand manual before use. Operation of this device without understanding the manual and
WARNING
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/
serialnumber.
This equipment is intended for use by trained and qualifi ed emergency services personnel for
fi refi ghting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize fi refi ghters and maintenance personnel with the
operation, servicing, and safety procedures associated with this product. This manual should be
kept available to all operating and maintenance personnel.
AUTOMATIC
600 - 4000 gpm @ 80-120 psi
(2350 - 15,000 l/min @ 6 - 8 bar)
SELECTABLE
2000, 3000, 4000 gpm @ 100 psi
(7500, 11,000, 15,000 l/min @ 7 bar)
TASK FORCE TIPS LLC
MADE IN USA • TFT.com
©Copyright Task Force Tips LLC 2020
MANUAL: Masterstream 4000 ER
Automatic and Selectable Nozzles
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax 219-464-7155
LIM-032 February 18, 2020 Rev00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Masterstream 4000 ER AUTOMATIC and is the answer not in the manual?

Questions and answers

Related Manuals for TFT Masterstream 4000 ER AUTOMATIC

Summary of Contents for TFT Masterstream 4000 ER AUTOMATIC

  • Page 1 Understand manual before use. Operation of this device without understanding the manual and WARNING receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/ serialnumber. This equipment is intended for use by trained and qualifi ed emergency services personnel for fi...
  • Page 2 INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION AND MAINTENANCE Reach Factor (compared to 30° elevation) Understand manual before use. Operation of this device without understanding the manual and DANGER receiving proper training is a misuse of this equipment. Obtain safety information at www.tft. com/serial-number 85° 75°...

  • Page 3: Table Of Contents

    5.0 NOZZLE OPERATION 5.1 AUTOMATIC NOZZLE OPERATION 5.2 SELECTABLE NOZZLE OPERATION 5.3 FLOW SELECTION 6.0 FLOW CHARACTERISTICS 6.1 MASTERSTREAM 4000 ER AUTOMATIC 6.2 MASTERSTREAM 4000 ER SELECTABLE 6.3 DETERMINING FLOW WITH PRE-PIPED MONITORS 6.4 STREAM TRAJECTORY DATA 7.0 FLUSHING DEBRIS 8.0 DRAWINGS AND PART LISTS...

  • Page 4: Meaning Of Safety Signal Words

    1.0 MEANING OF SAFETY SIGNAL WORDS A safety related message is identifi ed by a safety alert symbol and a signal word to indicate the level of risk involved with a particular hazard. Per ANSI Z535.6, the defi nitions of the four signal words are as follows: DANGER indicates a hazardous situation which, if not avoided, will result in death or serious DANGER injury.

  • Page 5: General Information

    3.0 GENERAL INFORMATION The Task Force Tips Masterstream 4000 ER Series deluge nozzles have a clean, far reaching straight stream capability and are available with automatic pressure control or selectable gallonage. While fl owing, the stream pattern can be varied from wide fog to straight stream.

  • Page 6: Specifications

    3.4 PATTERN CONTROL TFT’s nozzles have full pattern control from straight stream to wide fog. Turning the stream shaper clockwise (as seen from the operating position behind the nozzle) moves the shaper to the straight stream position. Turning the shaper counterclockwise will result in an increasingly wider pattern.

  • Page 7: Nozzle Operation

    5.0 NOZZLE OPERATION 5.1 AUTOMATIC NOZZLE OPERATION Automatic nozzles operate by sensing the pressure at the nozzle’s inlet and adjusting the discharge opening to maintain a constant pressure throughout the fl ow range of the nozzle. For example, when the pressure at the inlet increases, the exit area is automatically increased until the inlet pressure returns to the nominal pressure of the nozzle.

  • Page 8: Flow Characteristics

    6.0 FLOW CHARACTERISTICS 6.1 MASTERSTREAM 4000 ER AUTOMATIC Within its fl ow range, the Masterstream 4000 ER automatic nozzle operates at the nominal pressure of 80-120 psi (5.5-8.3 bar, 550- 830 kPa). The following chart shows the typical performance of this nozzle.

  • Page 9: Determining Flow With Pre-Piped Monitors

    6.3 DETERMINING FLOW WITH PRE-PIPED MONITORS The simplest procedure to determine fl ow with automatic nozzles is with a fl ow meter. If a fl ow meter is unavailable, the fl ow may be estimated using pressure loss data between the nozzle and an in-line pressure gauge at the pump or considerably upstream from the nozzle.

  • Page 10: Stream Trajectory Data

    • Graphs show approximate eff ective stream trajectory at 30 degrees elevation in no wind conditions. Distance to last water drops approximately 10% farther. • To estimate trajectories at elevations other than 30 degrees, refer to document LTT-135, available at tft.com. • Trajectories shown are for water. The addition of foam is expected to decrease the reach by 10%.

  • Page 11: Flushing Debris

    7.0 FLUSHING DEBRIS Debris in the water may get caught inside the nozzle. This trapped material will cause poor stream quality, shortened reach and reduced fl ow. To remove debris trapped in the nozzle: Shut off fl ow to the nozzle Move the stream shaper to the wide fog position.

  • Page 12: Drawings And Part Lists

    8.0 DRAWINGS AND PART LISTS 8.1 MASTERSTREAM 4000 ER AUTOMATIC 18 20 25 26 29 30 31 32 42 43 44 45 46 47 34 43 49 50 51 52 56 57 61 62 INDEX DESCRIPTION PART # INDEX DESCRIPTION PART # 6"...

  • Page 13: Masterstream 4000 Er Selectable

    8.2 MASTERSTREAM 4000 ER SELECTABLE 14 15 29 30 31 32 35 36 INDEX DESCRIPTION PART # INDEX DESCRIPTION PART # 6" ANSI 150 FLANGE ADAPTER MT620 WEAR STRIP MT502 O-RING-263 VO-263 SHAFT CENTER SUPPORT MT614 1/2-20 X 3/8 SOCKET SET SCREW CUP POINT VT50-20SS375 O-RING-438 VO-438...

  • Page 14: Warranty

    46383-9327 USA, within a reasonable time after discovery of the defect. TFT will examine the equipment. If TFT determines that there is a defect attributable to it, TFT will correct the problem within a reasonable time. If the equipment is covered by this limited warranty, TFT will assume the expenses of repair.

  • Page 15: Maintenance

    Repair parts and service procedures are available for those wishing to perform their own repairs. Task Force Tips assumes no liability for damage to equipment or injury to personnel that is a result of user service. Contact the factory or visit the web site at tft.

  • Page 16: Operation And Inspection Checklist

    Operating equipment that has failed the checklist is a misuse of this equipment. TASK FORCE TIPS LLC 3701 Innovation Way, Valparaiso, IN 46383-9327 USA 800-348-2686 • 219-462-6161 • Fax 219-464-7155 MADE IN USA • TFT.com ©Copyright Task Force Tips LLC 2020 LIM-032 February 18, 2020 Rev00...
