Radio control model / Flugmodell
Instruction manual / Montageanleitung
Wingspan:.........................1800mm (70.8in.)
Length:..............................1200mm (47.2in.)
Electric Motor:.....................x2
Equipment Used).
Radio:....................6 Channel / 4..8 Servos
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstätzung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
Spannweite:...................................1800mm
Lange:............................................1200mm
Elektroantrieb.............(siehe nächste Seite)
Brushless Motor:.............x 2
Fluggewicht:.......................................3.2Kg
Fernsteuerung................6 Kanal / 4..8 Servos

Advertisement

loading
Need help?

Need help?

Do you have a question about the Douglas DC-3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pichler Douglas DC-3

Summary of Contents for Pichler Douglas DC-3

  • Page 1 Radio control model / Flugmodell Instruction manual / Montageanleitung Wingspan:......1800mm (70.8in.) Spannweite:........1800mm Length:......1200mm (47.2in.) Lange:..........1200mm Electric Motor:.....x2 Elektroantrieb.....(siehe nächste Seite) Brushless Motor:.....x 2 Equipment Used). Fluggewicht:........3.2Kg Radio:....6 Channel / 4..8 Servos Fernsteuerung....6 Kanal / 4..8 Servos cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough. Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
  • Page 2 #C9218 Elektrisches Einziehfahrwerk Fernsteuerung GigaProp 6 Electric Retracts Radio Set GigaProp 6 Alle Infos zu diesem Zubehör unter: More infos about these Accessories: www.pichler-modellbau.de X3598-120 Klebestoffe (nicht mitgeliefert) (Purchase separately) 5-Min Epoxy Cyanoacrylate Glue (thin type) Hex Wrench Phillip screw driver...
  • Page 3 1- CENTER WING:ELECTRIC RETRACT INSTALLATION (OPTION) Tragflächenmittelstück CENTER WING - BOTTOM VIEW Ansicht von unten Cut away the leading edge as show. Note: Cut away the leading edge in case of the electric retract use only. Cut away the leading edge as show.
  • Page 4 2- CENTER WING: ELECTRIC RETRACT INSTALLATION (OPTION) Tragflächenmittelstück CENTER WING - BOTTOM VIEW Ansicht von unten Step 2A Note: Connect the electric retract to the receiver, with the retract switch on your radio in ON position, the electric retract will be in extended position. (Option) #C9218 Step 2B 3x12mm...
  • Page 5 3- CENTER WING: ELECTRIC RETRACT INSTALLATION (OPTION) Tragflächenmittelstück 3x12mm screw ..4 3mm collar CENTER WING - BOTTOM VIEW ..2 Ansicht von unten ..2 Step 3A Fahrwerksabstützung Landing gear brace STEP 3B: FIXED GEAR INSTALLATION Note: In case of fixed gear using, do not cut the leading edge 3x12mm Fahrwerksträger Landing gear mount...
  • Page 6 4- CENTER WING Plastic control horn Tragflächenmittelstück .....1 Ansicht von unten Step 4A 3x12mm screw 3x12mm screw ..4 Bend the steel wire for the adjusting. Adjuster screw Fahrwerksabstützung Step 4B 2x8mm Korrekt ausrichten Ensuring that they are accurately aligned. 2X8mm screw ..8...
  • Page 7 5- CENTER WING Ansicht von oben Step 5A Ansicht von oben Step 5B Motorträger Seitenansicht -Using a aluminum motor mounting as a template, mark the firewall where the four holes are to be drilled. -Remove the motor and drill a 1/8”(3mm) hole through the plywood at each of the four marks marked .
  • Page 8 6- CENTER WING Tragflächenmittelstück Ansicht von oben Step 6A Step 6B...
  • Page 9 7- CENTER WING Tragflächenmittelstück 2x8mm Ansicht von unten Step 7A 1.5mm 2x8mm 2X8mm screw ..6 1.5mm Step 7B...
  • Page 10 8- CENTER WING 2x8mm Ansicht von oben Step 8A 2x8mm 1.5mm 2x8mm 1.5mm 2x8mm 1.5mm 1.5mm 2X8mm screw ..14 9- RIGHT (LEFT) WING Step 9A Die Löcher für die Ruderhörner und Servos Plastic control horn sind werksseitig vorgesehen und können unter der Folie ertastet werden.
  • Page 11 10- RIGHT (LEFT) WING Rechte Flächenhälfte von oben Rechte und linke Flächenhälfte Step 10A Connector 2 mm ...2 1.2x175mm rod ..2 11- CENTER WING Tragflächenmittelstück Aluminium Flächensteckungsrohr 19x749mm aluminum tube...

  • Page 12: Joining The Wing

    12- JOINING THE WING Flächenteile langsam und spaltfrei zusammenschieben...
  • Page 13 13- JOINING THE WING...

  • Page 14: Horizontal Stabilizer

    14- HORIZONTAL STABILIZER Bitte korrekt ausrichten Trial fit the horizontal stabilizer in place on the fuselage. Check the alignment of the horizontal stabilizer by measuring from a fixed point along the center line of the fuselage to the leading edge on each side of the horizontal stabilizer. The distance must be equal on both sides.
  • Page 15 15- HORIZONTAL STABILIZER AND TAIL WHEEL Remove the horizontal stabilizer from the fuselage. Using a straight edge and a sharp hobby knife, carefully cut away the covering inside the lines which were marked. Be cautious not to cut into the wood - this will weaken the structure.

  • Page 16: Vertical Stabilizer

    16- TAIL WHEEL COVER 1.5mm 2x8mm 2x8mm 17- VERTICAL STABILIZER Cut away only the covering Remove the horizontal stabilizer from the fuselage. Using a straight edge and a sharp hobby knife, carefully cut away the covering inside the lines which were marked. Be cautious not to cut into the wood - this will weaken the structure.
  • Page 17 18- VERTICAL STABILIZER continued Slide the rudder push-rod through the plastic cover and the plastic push-rod tube into the fuselage.
  • Page 18 19- LINKAGES Belt Tail wheel push-rod Left elevator push-rod Rudder push-rod Right elevator push-rod...
  • Page 19 20- BALANCE AND CONTROL SURFACE Schwerpunkt und Ruderausschläge (100 ~ 110mm) Wing center section Höhenruder 15mm 12mm 15mm 12mm Querruder 20mm 20mm 20-25mm Landeklappen Seitenruder...
