All Restoration Hardware Bunk Beds are designed to meet the highest safety
standards and comply with all U.S. and Canadian Bunk Beds regulations.
Made in Vietnam
Distributed in the U.S.A. by:
Restoration Hardware Baby & Child
11640 Harrel St. Suite B
Mira Loma, CA 91752
www.rhbabyandchild.com
Distributed in Canada by:
Restoration Hardware Canada, Inc.
1500-1055 West Georgia Street
Vancouver, British Columbia V6E4N7
WARNING : Read all
instructions before assembling this
product. KEEP INSTRUCTIONS
FOR FUTURE USE.
If you are missing parts or have any questions about this product, contact us first. You can also order parts by writing
to the address above. Include the product model number, color, and a brief description of the part.
DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning. Dust often using a clean, soft, dry
cloth. Blot spills immediately and wipe with a clean damp cloth. If the crib is to be stored, store in a cool dry place and
NOTE : When inserting bolts, turn clockwise until tight. Then loosen
completely assembled, return to each bolt and tighten. Use wax or soap on all bolts to facilitate assembly.
CUSTOMER SERVICE
Call 1-800-762-1751.
CARE AND CLEANING
carefully package all original hardware to protect from loss.
TOOLS AND INSTALLATION
Tools Necessary: Allen Key (included)
Note: It may be easier to assemble product with two people.
1
-
2
Page 1 of 10
MODEL NO. 105014
"BELLINA TWIN OVER TWIN
BUNK BED"
3
of a turn. After bunks is
4
