Summary of Contents for baby&child Sutton 5563-0612
- Page 1 All Restoration Hardware cribs are designed to meet the highest safety standards and comply with all U.S. and Canadian cribs and cradles regulations. Page 1 of 13...
-
Page 2: Customer Service
Assembly Instructions For Crib Model No: 5463−0612 Restoration Hardware Baby & Child ˆSutton Collection˜ 2900 North Macarthur Drive Model No: 5563−0612 Tracy, California 95376 ˆSutton Collection˜ restorationhardware.com Made in China Distributed in the U.S.A. by: Restoration Hardware Baby & Child 2900 North Macarthur Drive Tracy, California 95376 restorationhardware.com... - Page 3 IMPORTANT SAFETY INFORMATION FOR CRIBS WARNING: Infants can suffocate on soft bedding. Never add a pillow, comforter or padding. WARNING: Failure to follow these warnings and the assembly instructions could result in serious injury or death. To reduce the risk of SIDS, pediatricians recommend healthy infants be placed on their backs to sleep, unless otherwise advised by your physician.
- Page 4 IMPORTANT SAFETY INFORMATION FOR CRIBS WARNING Do not use this crib if the enclosed or attached instructions cannot be strictly adhered to. Do not use this crib if the child is able to climb out unaided or is taller than 90 cm. Do not place cords, straps or similar items that could become wound around the child’s neck in or near this crib.
-
Page 5: Item Identification
Item Identification For ease of identification, all parts are labeled to correspond to the Step number in which the part is used. Step #6 Canopy frame assembly Step #4 Stationary side assembly (Page 11 of 13) (Page 9 of 13) Step #8 Toddler rail assembly (Page 13 of 13) Step #2 Mattress support... - Page 6 Hardware needed for Step #1: STEP #1 (AA) K.D. Barrel Nuts (x 4 pieces) SIDE FRAME & (BB) 3-1/2 in. Bolts (x 4 pieces) STRETCHER BAR ASSEMBLY (CC) Dowel Pin (x 4 pieces) (DD) Allen Wrench (1 piece) Side Frame (x 2) Stretcher Bar (x 2) Insert barrel nuts into holes in stretcher bar...
- Page 7 Hardware needed for Step #2: STEP #2 (EE) Mattress nut (x 4 pieces) MATTRESS SUPPORT (FF) 1-3/8 in. Mattress bolt (x 4 pieces) HEIGHT ADJUSTMENT (GG) Mattress washer (x 4 pieces) (HH) 3/8 in. lock washer (x 4 pieces) Mattress support (x 1) (DD) Allen Wrench (1 piece) Note: Do not fully tighten at this time.
- Page 8 Hardware needed for Step #3: STEP #3 (EE) Mattress nut (x 4 pieces) MATTRESS SUPPORT (FF) 1-3/8 in. Mattress bolt (x 4 pieces) ATTACHMENT TO (GG) Mattress washer (x 4 pieces) STRETCHER BARS (HH) 3/8 in. lock washer (x 4 pieces) (DD) Allen Wrench (1 piece) Mattress support (x 1) Note: Do not fully...
- Page 9 Hardware needed for Step #4: STEP #4 (II) 2-5/8 in. Bolt (x 4 pieces) STATIONARY SIDE (DD) Allen Wrench (1 piece) ASSEMBLY Stationary Side (x 1) Note: Do not fully tighten at this time. Stationary Side (II) Detail A (DD) Hardware Step # 4 (DD) Allen Wrench (1 piece) (II) 2-5/8 inch bolt (x 4 pieces)
- Page 10 Hardware needed for Step #5: STEP #5 (KK) Upper bushing (x 2 pieces) DROP SIDE ASSEMBLY (LL) Lower guide stud (x 2 pieces) (MM) Upper bushing screw (x 2 pieces) Drop side (x 1) To attach drop side, insert top of upper track on to upper bushing on both ends. Then align lower guide stud with slot in lower track of drop side.
- Page 11 Hardware needed for Step #6: STEP #6 (NN) 2-1/4 in. Bolt (x 4 pieces) CANOPY FRAME ASSEMBLY (DD) Allen Wrench (1 piece) Canopy frame (x 1) (NN) All hardware may be Canopy frame tightened at this time. (NN) (NN) (NN) (NN) Detail A Hardware Step #6...
- Page 12 Stand at the middle of the drop side and hold the STEP #7 top rail with one hand. Raise the drop side DROP SIDE OPERATION slightly to enable you to release the latch by pushing on the drop side with your knee. The drop side will now lower.
- Page 13 Hardware needed for Step #8: STEP #8 (JJ) 1/2 in. Bolt (x 2 pieces) TODDLER RAIL ASSEMBLY (DD) Allen Wrench (1 piece) (MM) Upper bushing screw (x 2 pieces) Toddler Rail (x 2) Detail B Note: Remove (KK) top bushings & (LL) bottom studs.
