WARNING:
ADULT ASSEMBLY ONLY OWING TO THE PRESENCE OF SMALL PARTS, SHARP
POINTS AND EDGES.
PART LIST
A
HEADBOARD
B
END PANEL
C
FRONT RAIL
D
LEG
E
TWIN PANEL SUPPORT
F
TWIN PANEL
G
TRUNDLE (OPTIONAL)
IMPORTANT
These bed parts can be cumbersome and heavy to some people; therefore the assistance of two or
more people is recommended in order to prevent personal injury and ensure the bed parts are not
damaged during the assembly process.
TOOLS NEEDED
-PHILLIPS HEAD SCREWDRIVER (NOT PROVIDED)
H A R D W A R E L I S T
NO.
1
2
3
4
5
6
7
8
9
Customer Service - If you are missing parts or have any questions about this product please contact
B E L L I N A D A Y B E D
F
F
A
D
C
E
B
D
D E S C R I P T I O N
THREADED ROD
CURVED WASHER
LOCK WASHER
HEX NUT
WRENCH
ALLEN HEAD BOLT
PLAIN WASHER
ALLEN WRENCH
PHILLIPS WOOD SCREW
us at 1-800-762-1751
Page 1 of 3
B
D
G
QTY.
4 PCS
4 PCS
8 PCS
4 PCS
1 PC
4 PCS
4 PCS
1 PCS
38 PCS
