Wall Sounder Strobe Current Draw; Tone And Candela Selection; Tamper Screw; Surface Mount Back Box Up Arrow - System Sensor L Series Installation And Maintenance Instruction

TABLE 1. WALL SOUNDER STROBE CURRENT DRAW (mA) AND SOUND OUTPUT (dBA)
Volume
Pos Tone
Setting
15cd 30cd
1 High 98 115
Temp 3
2 Low 98 102
3 High 98 108
Temp 4
4 Low 102 104
5 Contin­ High 141 158
6 uous Low 120 128
FIGURE 7. WALL MOUNT LOW-FREQUENCY SOUNDER STROBE WITH
JUNCTION BOX
FIGURE 8. WALL MOUNT LOW-FREQUENCY SOUNDER STROBE WITH
SURFACE-MOUNT BACK BOX
FIGURE 9. COMPACT WALL MOUNT LOW-FREQUENCY SOUNDER
SOUNDER WITH LED ALARM INDICATOR AND SILENCE SWITCH, IN
JUNCTION BOX
FIGURE 10. COMPACT WALL MOUNT LOW-FREQUENCY SOUNDER WITH
LED ALARM INDICATOR AND SILENCE SWITCH, IN SURFACE-MOUNT
BACK BOX
Current draw (mA)
16-33 VDC
75cd 95cd 110cd 135cd 185cd 15cd
158 173 182 212 266
141 162 173 202 255
137 151 178 202 252
122 136 163 187 237
198 216 234 264 305
179 196 215 244 285
A0583-00
A0584-00
Silence Switch/LED Indicator
A0585-00
A0586-00
16-33 FWR
30cd 75cd 95cd 110cd 135cd 185cd
136 153 188 206 228
150 150 176 194 216
200 198 169 188 212
176 174 154 173 197
190 207 249 268 289
165 182 226 244 266

TONE AND CANDELA SELECTION

Tables 1 and 2 list current draw and sound output for available settings. Fig-
ures 14 – 15 list the minimum light output requirements per ULC.
Sounder tone and volume: Turn the rotary switch on the back of the product.
Candela: Adjust the slide switch on the rear of the product to the desired can-
dela setting. Candela setting will display in the small window on the front of
the unit. All products meet the light output profiles specified in the appropri-
ate ULC Standards.
TABLE 2. LOW FREQUENCY WALL AND CEILING SOUNDER ONLY
CURRENT DRAW (mA)
Current Draw
Sound Volume
Pos
16–33 Volts
Patterns Setting
DC
1 High 108
Temp 3
2 Low 78
3 High 111
Temp 4
4 Low 80
5 High 111
Contin­
uous
6 Low 80
7* High 111
Coded
8* Low 80
*NOTE: For coded tones, temporal coding must be provided by the NAC. If the
NAC voltage is held constant, the sounder output will remain constantly on.
Coded ratings provided are for continuous voltage.

TAMPER SCREW

For tamper resistance, the standard
captive screw may be replaced with
a Torx screw, ordered separately.
To remove the captive screw, back
out the screw and apply pressure
to the back of the screw until it dis-
engages from the housing. Replace
with Torx screw. (See Figure 11.)
FIGURE 12. SURFACE MOUNT BACK BOX UP ARROW
FIGURE 13. KNOCKOUT AND V500/V700 REMOVAL FOR SURFACE
MOUNT BACK BOX
or ¾ inch
A0465-01
3
Sound Output Sound Output
(dBA)
Reverberant
16-33 V
DC FWR
258 304 80 80
242 280 76 76
242 290 80 80
227 275 76 76
321 368 80 80
297 342 76 76
Sound Output Sound Output
(mA) (dBA) Reverberant (dBA) Anechoic
16-33 V
FWR DC FWR DC
150 80 80 82
76 76 76 78
151 80 80 82
76 76 76 78
151 80 80 82
76 76 76 78
151 80 80 82
76 76 76 78
FIGURE 11. TAMPER SCREW
T15 Torx
#6-32, 5/8"
SCREW-TMPR-50
Wire Mold Removal
½ inch
(dBA)
Anechoic
16-33 V
DC FWR
82 82
78 78
82 82
78 78
82 82
78 78
16-33 V
FWR
82
78
82
78
82
78
82
78
A0478-00
A0481-00
A0466-01
