INSTALLATION AND MAINTENANCE INSTRUCTIONS
MA12/24D* Electronic Sounder,
SS12LO, SS24LO*, SS24M*
Electronic Strobe, MASS12LO,
MASS12M, MASS24LO*, MASS24M*
Sounder/Strobe Combined
*ULC models add suffix "A"; strobes and sounder/strobes available in 24VDC only
Table 1. SS12/24 electrical and light ratings:
Model Supply
Voltage
(VDC)
SS12LO 12-17
SS24LOA 22.5-30
SS24MA 22.5-30
SS24LO 22.5-30
SS24M 22.5-30
General Description
The National Fire Protection Association has published standards
and recommended practices for the installation and use of the
listed appliances. It is recommended that the installer be familiar
with these requirements, with local codes, and any special re-
quirements of the authority having jurisdiction.
The electronic Multi-Alert sounder and the signaling strobe are in-
tended to be connected to the alarm indicating circuit of a listed
fire alarm control panel. Both are compatible with DC line super-
vision. The model MA12/24D is suitable for connection to either a
12 or 24 volt panel. Models SS24LO, SS24M, MASS24LO and
MASS24M require 24 volt panels; models SS12LO, MASS12LO and
MASS12M require 12 volt panels. Horn, strobe, or combination
strobe models may be used with panels that have full wave recti-
Table 2. Sound output and current ratings for the MA12/24D:
Sound (Hz)
Slow Whoop
800 Continuous
800/1000 Alternating
2400 Interrupted
2400 Continuous
1200 Interrupted
Swept Frequency
Fast Warble
Note 1: Total current for horn/strobe combinations = horn current +
strobe current; refer to tables 1 and 2.
Note 2: Sound output measured in anechoic room at 10 feet.
Note 3: Sound output measured in UL reverberant room.
D900-05-00
Technical Manuals Online! - http://www.tech-man.com
Operating Operating Current
Current from from Rectified
Regulated Supply Unfiltered Supply
(mA) (mA, RMS)
50 80
25 45
75 125
Clips on Tabs
( Note 4)
ABC
BC
AC
AB
C
B
A
NONE
Peak Minimum Output
Current @ 100% Viewing
Angle (see Fig. 3)
(mA) (Candela)
550 1.5
(.22@-35
(5.9 @-35
225 1.5
(.22@-35
450 15
(5.9 @-35
fied, unfiltered supplies. The MA12/24D sounder and MASS12/24
sounder/strobes are suitable for outdoor applications (–35° C to
66°C) when used with a Weatherproof Back Box (Model WBB) as
tested by UL. In Canada, rigid steel conduit must be used when
installing the Weatherproof Back Box. The light output of the
SS12LO, SS24LO, MASS12LO and MASS24LO is 1.5 cd min
@100% viewing angle. The light output of the SS24M, MASS12M,
and MASS24M is 15 cd min @100% viewing angle (See Figure 3).
There are eight different sounds which can be selected on the
electronic sounder by adding or removing tab clips (see Figure 4).
The sound selected will determine the maximum current and
sound power output per device. See Table 2 for these values.
Current (mA) ( Note 1) Output (dBA) UL (dBA) Ratings
DC Regulated/
FWR Unfiltered
12V 24V 30V 12V
21/40 38/56 46/72
15/24 28/45 35/55
17/32 34/46 43/58
19/23 35/56 43/64
21/31 38/59 46/73
13/19 23/33 27/41
17/24 34/47 43/60
15/27 30/47 38/59
Note 4: See Figure 4 for tab clip removal & storage.
Note 5: All horn or combination strobe models can be powered using
full wave rectified unfiltered supplies.
1
A Division of Pittway
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
Under no circumstances can
the SS24 or MASS24 input volt-
age exceed 33 VDC or be less
than 18 VDC. Under no cir-
cumstances can the SS12 or
MASS12 input voltage exceed
o
C)
18.7 VDC or be less than 9.6
VDC. Under no circumstances
o C)
can the MA12/24D input volt-
age exceed 33 VDC or be less
o C)
than 9.6 VDC.
o C)
(Note 2) (Note 3)
24V 12V 24V
85 92 79 85
87 93 79 85
85 92 79 85
89 90 79 85
85 94 79 85
85 91 75 82
85 92 79 85
85 92 79 85
I56-496-16
