Kaivac 2100 Series Operator's & Parts Manual

Hide thumbs Also See for 2100 Series:
Table of Contents

Advertisement

Quick Links

Operator & Parts
Manual
®
KaiVac
2100 Series
2150 Serial Number 2150-2247 to Current
© 2006-2013 Kaivac, Inc. All Rights Reserved
T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kaivac 2100 Series

Summary of Contents for Kaivac 2100 Series

  • Page 1 Operator & Parts Manual ® KaiVac 2100 Series 2150 Serial Number 2150-2247 to Current © 2006-2013 Kaivac, Inc. All Rights Reserved T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...
  • Page 2 Modified the Rotomold Warranty to 5 years. NOTE: Specifications and parts are subject to change without notice Kaivac, Inc. 401 S. Third Street Hamilton, OH 45011 © 2006-2013 Kaivac, Inc. All Rights Reserved Page i T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...

  • Page 3: Table Of Contents

    OPERATION ........................2-1 Preparing Your Kaivac For Use ................2-1 Kaivac Tool Arrangement ..................2-2 Vac Tank & Hose Cleanout Instructions ..............2-3 Operating your Kaivac using S-I-M-P-L-E Process ..........2-4 MAINTENANCE ......................3-1 Machine Maintenance..................... 3-1 Troubleshooting ...................... 3-2 Machine Diagrams ....................

  • Page 4: Getting Started

    This warranty does not apply to return freight costs, damage or defect caused by accident, negligence, misuse, fire or repair done by anyone other than a Kaivac authorized repair center. In no event shall Kaivac, Inc. be liable for incidental or consequential damages, or any damages to persons or property.

  • Page 5: Warranty Registration Form

    Thank you for registering for our warranty program. Please return completed forms to: Kaivac, Inc. 401 S. Third Street Hamilton, OH 45011 Or Fax to: (513) 887-4601 © 2006-2013 Kaivac, Inc. All Rights Reserved Page 1-2 T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...

  • Page 6: Safety Precautions

    Improper connection of the equipment grounding cord can result in the risk of electrical shock. Ask a qualified electri- cian or service person to check the outlet grounding if you are unsure. Do not modify the plug provided with the Kaivac.

  • Page 7: Operation

    6. Plug in machine and test GFCI (Ground Fault Circuit Interrupter) to ensure it is working properly. You are now ready. Page 2-1 © 2006-2013 Kaivac, Inc. All Rights Reserved T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...

  • Page 8: Kaivac Tool Arrangement

    Dry Vac Complete DRYVACRK Overhead View Bottom View HEPA Cover HCOVER KaiDrain CVS14 Left Right Right Left Spray Gun Metering Tip SUBGAKW Pack MTIPSNEW © 2006-2013 Kaivac, Inc. All Rights Reserved Page 2-2 T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...

  • Page 9: Vac Tank & Hose Cleanout Instructions

    Tank and Hose Cleaning © 2006-2013 Kaivac, Inc. All Rights Reserved Page 2-3 T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...
  • Page 10 LOW Pressure Mode Manually brush anual heavily soiled areas Brush Fresh Water ressure wash and Fan Spray rinse HIGH Pressure Mode xtract Page 2-4 © 2006-2013 Kaivac, Inc. All Rights Reserved T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...

  • Page 11: Maintenance

    Apply grease when done.  HEPA Filter Replace every 3-6 months depending on use © 2006-2013 Kaivac, Inc. All Rights Reserved Page 3-1 T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...

  • Page 12: Troubleshooting

    Dry blow line Blow Dry System Suction, not blow action Vacuum hose connected Reconnect to vac motor exhaust hose to vac tank © 2006-2013 Kaivac, Inc. All Rights Reserved Page 3-2 T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...
  • Page 13 Remove and rein- stall Kink in Chemical line Replace Chemical line © 2006-2013 Kaivac, Inc. All Rights Reserved Page 3-3 T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...
  • Page 14 Squeegee wheels worn Check wheels for wear / replace Sucks to the floor too Squeegee wheels worn Check wheels for wear / tightly replace Page 3-4 © 2006-2013 Kaivac, Inc. All Rights Reserved T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...
  • Page 15 3.0 MAINTENANCE PUMP & ELECTRICAL DIAGRAM © 2006-2013 Kaivac, Inc. All Rights Reserved Page 3-5 T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...
  • Page 16 3.0 MAINTENANCE 3.3 MACHINE DIAGRAMS © 2006-2013 Kaivac, Inc. All Rights Reserved Page 3-6 T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...
  • Page 17 3.0 MAINTENANCE 3.3 MACHINE DIAGRAMS Page 3-7 © 2006-2013 Kaivac, Inc. All Rights Reserved T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...
  • Page 18 3.0 MAINTENANCE 3.3 MACHINE DIAGRAMS © 2006-2013 Kaivac, Inc. All Rights Reserved Page 3-8 T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...
  • Page 19 3.0 MAINTENANCE 3.3 MACHINE DIAGRAMS Page 3-9 © 2006-2013 Kaivac, Inc. All Rights Reserved T: 0121 351 4444 E: sales@rawlins.co.uk W: www. rawlins.co.uk...

  • Page 20: Machine Diagrams

    3.0 MAINTENANCE 3.3 MACHINE DIAGRAMS Page 3-10 www.kaivac.com © 2006-2013 Kaivac, Inc. All Rights Reserved Phone: 1-800-287-1136...
  • Page 21 3.0 MAINTENANCE 3.3 MACHINE DIAGRAMS Page 3-11 © 2006-2013 Kaivac, Inc. All Rights Reserved...
  • Page 22 3.0 MAINTENANCE 3.3 MACHINE DIAGRAMS HEPA HOUSING ASSEMBLY (HEPAHA2) PART NO. PART DESCRIPTION HCOVER HEPA COVER FKEEP2 HEPA FILTER KEEPER HEPA HEPA FILTER HEPAH2 HEPA FILTER HOUSING Page 3-12 © 2006-2013 Kaivac, Inc. All Rights Reserved...
  • Page 23 3.0 MAINTENANCE 3.3 MACHINE DIAGRAMS Page 3-13 © 2006-2013 Kaivac, Inc. All Rights Reserved...
  • Page 24 CVS31 - #54 SPINWELD FITTING FOR FLOAT CVS28 - FILTER BAG CSS63 - TIE WRAP FOR FLOAT CVS26 - 2 IN DIA PLASTIC BALL CVS35 - AS568A-219 BUNA N O RING © 2006-2013 Kaivac, Inc. All Rights Reserved Page 3-14...
  • Page 25 SUBWHKV - WATER LINE FOR KV2150 RL2150 - RETURN LINE FOR 2150 CSS08 - 5/16-18 U-NUT JWW - JUMPER WIRE WHITE 12 IN CSS127 - QUICK DISCONNECT TERMINAL CSS64 - TIE WRAP FOR FILTERS Page 3-15 © 2006-2013 Kaivac, Inc. All Rights Reserved...
  • Page 26 CSS138 - 12-10 3-WAY INSULATED SPLICE V CSS139 - 12-10 BUTT SLICE CSS140 - 1/2 INCH HEAT SHRINK TUBING 0.167 CSS29 - PERMATEX 14D THREAD SEALANT 0.01 CPS25 - TEFLON TAPE © 2006-2013 Kaivac, Inc. All Rights Reserved Page 3-16...

  • Page 27: Parts List

    VLJH - VAC LID , JUG HOLDER HGAS - HEPA BLOW COVER GASKET HEPA HOUSING ASSEMBLY (HEPAHA2) HEPAH2 - HEPA FILTER HOUSING HEPA - HEPA FILTER FKEEP2 - HEPA FILTER KEEPER HCOVER - HEPA COVER © 2006-2013 Kaivac, Inc. All Rights Reserved Page 3-17...
  • Page 28 CSS17A - 8 SST SCREW 3/4 SUBGAKW - PRESSURE GUN GREEN DOT MTIPSNEW - METERING TIP PACK CHCAPA - CHEM CAP W/SAFETY CHECK VALVE AND SCREEN UFH - UNIVERSAL FILL HOSE 2150ACC - KV2150 ACCESSORY KIT © 2006-2013 Kaivac, Inc. All Rights Reserved Page 3-18...
  • Page 29 VHKVJRST - BLACK STRETCH VAC HOSE W/ BLACK CUFFS HC5 - HOSE CONNECTOR VH40 - VAC HOSE 40 FT PLCRD - PLACARD FOR 1200 1700 2100 SERIES UNITS TBAG - TOTE BAG MANUAL2150 - MANUAL FOR KV2150 KTDVD - KAITUTOR TRAINING DVD DISK...
