ARC MYCR-250 Manual

Wireless mini dimmer socket switch plug
Hide thumbs

Advertisement

Quick Links

Download this manual
Issue Date: 05/02/2020
WIRELESS MINI DIMMER
SOCKET SWITCH PLUG
CONTENTS
MYCR-250
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MYCR-250 and is the answer not in the manual?

Questions and answers

Related Manuals for ARC MYCR-250

Summary of Contents for ARC MYCR-250

  • Page 1: Table Of Contents

    Issue Date: 05/02/2020 WIRELESS MINI DIMMER SOCKET SWITCH PLUG MYCR-250 CONTENTS 1. Overview and features Page 2. 2. Diagrams Page 3. 3. Pairing / Un-pairing device Page 4. 4. Trailing & Leading Edge setup Page 8. 5. Minimum Brightness setup Page 9.

  • Page 2: Overview And Features

    • 32 memories, first in first out storage maintain. • Memory of last brightness level. • Scene status memory, create your desired atmosphere. • Built-in manual On & Off button with LED indication. Not compatible to: ARC Code switch system product range OVERVIEW AND FEATURES...

  • Page 3: Diagrams

    Issue Date: 05/02/2020 2. Diagrams Notes for the diagrams: DIAGRAMS...

  • Page 4: Pairing / Un-Pairing Device

    Issue Date: 05/02/2020 3. Pairing / Un-pairing Device AIRING Pairing using LEARNING MODE: 1. Plug in lamp / electronic device into socket switch. 2. Plug the socket switch into an electrical outlet. PAIRING / UN-PARING DEVICE...
  • Page 5 Issue Date: 05/02/2020 3. Within 6 seconds, on the remote control press the ‘ON’ button intend to be paired; LED on socket switch will quick flash and load will flash twice to confirm that the remote control is now paired. NOTE: If no signal is received from a remote control within 6 seconds then the socket switch will automatically exit learning mode without pairing the device.
  • Page 6 Issue Date: 05/02/2020 AIRING Removing single Device: 1. Unplug socket switch from the electrical outlet for at least 6 seconds. 2. Plug socket switch back into electrical outlet. 3. Within 6 seconds, on the remote control press the ‘OFF’ button intend to be un-paired;...
  • Page 7 Issue Date: 05/02/2020 LEARING EMORY Removing all memory stored in the socket switch. 1. Unplug socket switch from the electrical outlet for at least 6 seconds. 2. Plug socket switch back into electrical outlet. 3. Within 6 seconds, on the remote control press the ‘ALL OFF / GROUP ALL’ button;...

  • Page 8: Trailing & Leading Edge Setup

    Issue Date: 05/02/2020 4. Trailing & Leading Edge Setup Initial factory pre-set is at ‘Leading Edge’. Depending on the load you are using, please use the appropriate setting. To change between Leading edge and Trailing edge, please follow below setup. Leading Edge to Trailing Edge 1.

  • Page 9: Minimum Brightness Setup

    Issue Date: 05/02/2020 5. Minimum Brightness Level Setup Socket switch has the ability to setup minimum brightness level for both Leading or Trailing Edge. There are total 4 level brightness to choose from. To adjust the brightness level, please follow below setup. With a remote control (LYCT-505) 1.

  • Page 10: Operation

    Issue Date: 05/02/2020 6. Operation Socket switch is compatible to “Self Learning” system and M series remote control. Please refer to the relevant user guide for detailed operation. Manual ON & Manual OFF Operation under Leading Edge Turn the load ON: Press the ‘ON/OFF’...

  • Page 11: Specifications

    Issue Date: 05/02/2020 7. Specifications Input Rating: 230V~50Hz Output Rating: Supported Load Wattage “Trailing edge” for resistive loads (R) • 20-250W / 230V~ Conventional incandescent and halogen light source “Trailing edge” for resistive-capacitive loads (RC) • Electronic transformers 20-250W / 230V~ •...
  • Page 12 Issue Date: 05/02/2020 NOTE ⚫ Please leave minimum of 1.5 meters in-between 2 or more socket switch. ⚫ During standby mode, LED on module will not illuminate. SPECIFICATION...
