JLG 600AJ Service And Maintenance Manual page 104

2
1J
1A. Output Shaft
1B. Lip Seal
1C. Bearing
1E. Bearing
31215031
1I
1H
1E
13
1G
1C
1A
1G. Housing 2. Internal Gear
1H. Thrust Washer 3. Carrier Assembly
1I. Retaining Ring 4. Ring Gear
1J. Pipe Plug 5. O-Ring
Figure 3-54. Swing Drive Assembly
SECTION 3 - CHASSIS & TURNTABLE
20
12
11
11
44
8
5A. O-Ring 12. Bolt
6. Brake Housing 13. Dowel Pin
8. Sun Gear 20. Pipe Plug
11. Thrust Washer 44. Internal Retaining Ring
6
5A
4
5
3
3-51
