DOK-SYTROX-SVP7020-I*C-IT01-EN-P
Sytronix SvP 7020 IMC Speed Variable Pump Drives
Diagnostic displays
1)
Terminating resistor is off
2)
Cable shield must have direct contact to metal
Fig. 7-15:
Bus connection for all other slaves, without 9-pin D-sub female con‐
nector, INS0540
Connect the drive controller to a control unit using a shielded two-wire line in
accordance with DIN 19245/Part 1.
For the significance of the diagnostic displays, see firmware documentation.
Bosch Rexroth AG
49/73
Installation
