Sytronix SvP 7020 IMC Speed Variable Pump Drives
Compatibility
Recommended cable type
100Base-TX according to IEEE 802.3u
● According to CAT5e; type of shield ITP (Industrial Twisted Pair)
● Ready-made cables which can be ordered:
– RKB0011
Long cables (100 m at maximum) to connect the drive system to the high‐
er-level control unit or remote communication nodes.
Minimum bending radius:
– 48.75 mm if laid flexibly
– 32.50 mm if laid permanently
Order code for a 30 m long cable: RKB0011/030,0
– RKB0013
Short cables to connect devices arranged side by side in the control cabi‐
net.
4 lengths available: 0.19 m; 0.25 m; 0.35 m; 0.55 m
Order code for a 0.55 m long cable: RKB0013/00,55
Minimum bending radius: 30.75 mm
Tab. 7-23: Function, Pin Assignment, Properties
Bosch Rexroth AG 51/73
Installation
