Audiovox UltraGuard UG-OE3 Programming Manual

TRANSMITTER PROGRAMMING GUIDE

The transmitters included with the security system have been pre-
programmed at the factory, with each button pre-assigned to control a specific
function of the security system. Although the security system in the vehicle has
either a 3 or 4 channel receiver, depending on the model, the transmitters
included with the system are capable of transmitting 7 distinct signals. This
allows you to program each transmitter to more than one vehicle in two car
families, and also allows you to change which button(s) control certain functions
of the system.
( Example: Transmitter channel 5 can be programmed to activate Receiver
channel 2.) Refer to the chart below for access to each of the transmitter
channels, and for the standard factory button assignments.
TRANSMITTER
CHANNEL BUTTONS CHANNEL
1 1
2 2
3 3
4
4
5
6
7
Model UG-OE3
SYSTEM RECEIVER
FUNCTION
**Remote Arm & Disarm
**Remote Emergency Panic
Remote Door Lock & Unlock
* Pulsed Output for Accessories
* Switched Output for Accessories
* Switched Output for Accessories
