Audiovox PRO-9342FT3WOS2 Installation Manual page 2

Sixth Press and release the valet switch
Press transmitter Lock button to change
Seventh Press and release the valet switch
Press transmitter Lock button to change
Press transmitter lock button to change
Eighth Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
Ninth Press and release the valet switch
Press transmitter Lock button to change
Tenth Press and release the valet switch
Press transmitter Lock button to change
Press and release the valet switch
Turn ignition key off
Note: Once you enter the feature programming mode, do not allow more than 15 seconds to pass be-
tween steps or the programming will be terminated.
Control Module:
Select a mounting location inside the passenger compartment ( up behind the dash ), and secure using
the two screws provided. The control module can also be secured in place using cable ties.
Do not mount the control module in the engine compartment, as it is not waterproof. You should also avoid
mounting the unit directly onto factory installed electronic components. These components may cause RF
interference, which can result in poor transmitter range or intermittent operation.
Siren:
Select a mounting location in the engine compartment that is well protected from access below the
vehicle. Avoid areas near high heat components or moving parts within the engine compartment. To
prevent water retention, the flared end of the siren must be pointed downward when mounted. Mount the
siren to the selected location using the screws and bracket provided.
Hood or Trunk Pin Switch:
A pin switch is included for use in protecting the hood or trunk ( or hatchback ) of the vehicle. The switch
must always be mounted to a grounded, metal surface of the vehicle. It is important to select a location
where water cannot flow or collect and to avoid all drip gutters on hood and trunk fender walls. Choose
locations that are protected by rubber gaskets when the hood or trunk lid is closed.
The pin switch can be mounted using the bracket provided, or direct mounted by drilling a ¼ " diameter
mounting hole. Keep in mind that when properly mounted, the plunger of the pin switch should depress at
least ¼ " when the hood or trunk lid is closed.
or
or
or
or
or
INSTALLATION OF MAJOR COMPONENTS
2 chirps = hardwire
1 chirp = voltage sense
1 chirp = siren and horn output
2 chirps = siren output only
3 chirps = horn output only
2 chirps = horn chirp output 16mS
3 chirps = horn chirp output 30mS
1 chirp = horn chirp output 10 mS
2 chirps = valet switch override operation
1 chirp = custom code override operation
2 chirps = chirp delete from transmitter inactive
1 chirp = chirp delete from transmitter active
Exit program mode
Exit program mode
