Audiovox APS-30 Owner's Manual

KEY ACTIVATED PASSIVE ALARM
OWNER'S MANUAL
Congratulations on your purchase of the APS-30 automotive Passive Alarm System. The
APS-30 is a state - of - the - art auto security system that is designed to automatically arm and
disarm when your ignition key is turned on and off. Taking a few moments to read this manual
will help to ensure that your vehicle is protected at all times.
1. Turn the ignition key off, exit the vehicle, and close and lock all doors.
2. The dash mounted L.E.D. will begin to flash rapidly, indicating that the system is
automatically ( passively ) arming. As an added convenience, the 30 second automatic
passive arming will not begin until all doors are closed, allowing passengers to exit the
vehicle at their convenience.
3. In 30 seconds, you will hear a single short chip from the siren, and the vehicle's parking
lamps will flash one time, indicating that the system has ARMED. At this time, the red dash
mounted L.E.D. will begin to flash slowly, providing a visual indication that the system
is fully armed.
IMPORTANT ! The system will always arm, even when one of the doors has been left
opened.
When you leave the vehicle, and a door has been left opened, the system will arm after
10 minutes. If you plan to vacuum the car, or if service work is being performed, it is
recommended that the system be placed into the valet mode. If you do not do this, the
system will arm in 10 minutes, and you will probably inadvertently trip the alarm.
PROTECTION WHILE THE SYSTEM IS ARMED :
1. Opening any door will cause the alarm to sound after a 15 second delay. The alarm will
continuetosoundfor60seconds,thenstopandmaintainanarmedcondition. Ifthepotential
thief left a door opened, the alarm will sound for two more 60 second cycles, then re - arm
and ignore the opened door zone.
Model APS-30
ARMING THE SYSTEM :
