4 Button Remote Security System
with Dual Stage Shock Sensor
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need to
manually override your security system if the transmitter becomes lost, or inoperative due to
battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such situations.
In addition, the chart on the last page of this manual has a section for the particular features and
options installed in your vehicle as well as the override method selected. Valet Switch manual
override is pre-selected from the factory, however, the system can be configured for "Custom
Code" operation. Confirm the override mode selected on the last page of this manual and
familiarize yourself with the selection on it's operation.
FEATURES :
w 2 Four Button Programmable RF Transmitters (capable of accepting 4 transmitters)
w Four Channel Receiver
w Code Hopping Technology
w Selectable Manual Override Mode
w Remote Panic in all modes
w Protected Valet
w User Programmable Manual Override Code
w 7 Function LED (Light Emitting Diode) - Arm / Disarm / Zone 1, 2, 3 / Valet / Arming
w Intrusion Alert with Memory
w Audible Arm / Disarm / Defective Zone / Tamper Confirmation
w Instant Siren Activation
w Starter Disable (Optional relay required)
w Additional Engine Immobilizer Output (optional relay required)
w True Last Door Arming (hardwire only)
w Defective Zone By-Pass
w Hardwire or Voltage Sense Selectable
w Active or Passive Arming Selectable
w Programmable Auto Lock On / Off
w Programmable Auto Unlock On / Off
w Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds /1 Sec L/ Dbl. U/L
w Programmable Active or Passive Door Locks
w User Programmable Permanent Chirp Delete
w On Command RF Chirp Delete from Transmitter
w 6 Tone Multi-Tone Siren
w RF Inhibit with ignition on
w Parking Light Flasher
w Plug In Dual Stage Shock Sensor
OPTIONS :
w Starter Disable
w Remote Trunk Release (must have electronic trunk release)
w Remote Keyless Entry (must have power door locks)
w Multiple Vehicle Capable
w Remote Starter
w Remote Power Window Roll Up
w Remote Garage Door Interface
w Two Step Unlock Configurable
Model APS-410a
Owner's Manual
128-6468
1 of 10
Advertisement
Table of Contents
Related Manuals for Audiovox Prestige Platinum APS-410a
Summary of Contents for Audiovox Prestige Platinum APS-410a
- Page 1 Remote Trunk Release (must have electronic trunk release) w Remote Keyless Entry (must have power door locks) w Multiple Vehicle Capable w Remote Starter w Remote Power Window Roll Up w Remote Garage Door Interface w Two Step Unlock Configurable Model APS-410a Owner’s Manual...
-
Page 2: Arming The System - Active
YOUR “Code Hopping” TRANSMITTERS The transmitters included with your new security system use the most advanced and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your keychain transmitter, and re transmit at a later time to disarm your system. -
Page 3: Arming The System - Passive ( Automatic )
detected a open entry point after the learned delay expired. Closing the hood, trunk, or doors will correct the problem and you do not need to disarm the system to make the correction. o Doors Lock - Optional ARMING THE SYSTEM - PASSIVE ( AUTOMATIC ) 1. -
Page 4: Disarming The System
DISARMING THE SYSTEM 1. As you approach the vehicle, press and release the Unlock button on the keychain transmitter. þ Dash mounted LED turns off. If passive arming was selected during the installation, then the LED will start flashing rapidly, indicating that the system is re-arming automatically. -
Page 5: While The System Is Sounding
refer to the INTRUSION WARNING SIGNALS section of this manual to identify which zone was triggered. o Doors Unlock - Optional Note:If the optional 2 step door unlock circuit is installed, when the unlock transmitter button is activated, the drivers door only will unlock, pressing the unlock button a second time will cause all doors to unlock. - Page 6 (Light Emitting Diode) turns on. The LED will remain on as long as the system is in valet mode. 3. To return to normal operation, press and release the push button switch any time the ignition is on. NOTE: Always remember to return the system to the NON VALET mode, after servicing, to ensure that the vehicle remains protected at all times.
- Page 7 flashing the LED, first indicating the 10ths digit, pause and then the units digit. The unit will report the new code three times with a one second pause between each code, then the system will begin arming. If the LED flash pattern reports the previously stored code, the new code was not entered correctly.
-
Page 8: Eliminating The Normal Arm / Disarm Chirps
1) Enter the vehicle and turn the ignition switch to the on position. Note: The siren will sound. 2) Within 5 seconds, press and release the pushbutton switch 1 time. 3) Within 5 seconds, turn the ignition switch off then on. 4) Within 5 seconds, press and release the pushbutton switch 1 time. -
Page 9: Additional Remote Function ( Channel 3 )
While in the panic mode, anytime the DISARM button is pressed, the panic feature will continue for the allotted 30 seconds, however, the security system will be disarmed allowing the vehicle to start. ADDITIONAL REMOTE FUNCTION ( CHANNEL 3 ) This security system has an additional features that can be connected to a number of different optional accessories. - Page 10 Passive Arming o No Lock in passive mode o Hardwire doors, hood, and trunk o Custom Code Override o Valet Switch Override © 2003 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, N.Y. 11788 APS 410a PASSIVE ARMING ARMED DISARMED...
