- Page 1 INSTRUCTION MANUAL Modular air curtain THIS DOCUMENT MUST BE READ BEFORE STARTING THE INSTALLATION. INSTRUCT USER AND LEAVE THIS DOCUMENT WITH APPLIANCE FOR REFERENCE BI_ACM_GB_02...
-
Page 2: Table Of Contents
Contents: Page. 1. GENERAL 1.1 Description 1.2 Function 1.3 Warranty 2 TECHNICAL DATA 2.1 Table with data 2.2 Pre-Check 3 INSTALLATION 3.1 Suspension 3.2 Calculating numbers of modules 3.3 Positioning 4 ELECTRICAL CONNECTION 4.1 230Vac supply 4.1.2 Isolation switch or power plug 4.2 Connection options 4.2.1 Connection without speed control... -
Page 3: General
This user’s guide is meant for the installer and for the end user. It’s a reference to operation and installation of an ACM air curtain. For safety sake and to guarantee correct operation, it is essential that you read this manual thoroughly before starting the installation, including all tips and warnings. -
Page 4: Technical Data
Technical data Table with data Because the ACM air curtain consist of multiple modular sections, a variation of different widths or heights (vertical installation) can be constructed. Theoretical there isn’t a limit to the amount of coupled modules, but every 10 connected modules must be succoured/supported at each end. -
Page 5: Installation
Installation Suspension Every unit has 4 popnuts at each corner, in the illustration on page 4 the dimensions are depicted with the notification H-H. By using these popnuts one can mount the air curtain to the wall or ceiling with our consoles or M10 studs. -
Page 6: Electrical Connection
Electrical connection Warning: Before starting installation make sure that that electrical group you are working on, has been shut off. The appliance should have earth! 230Vac supply The installation must comply with all applicable local and/or national standards i.e. NEN 1010. There should be a suitable electrical group with a main fuse. -
Page 7: Setting, Operation And Maintenance
Setting, operation and maintenance Warning: Before starting maintenance make sure that the power group you are working on has been shut off! The appliance should have earth! Operation With the 5-step switch one can adjust the airspeed on ground level, as explained in §4.2. The airspeed on ground level may not be too low because the air curtain can’t withstand any wind load. -
Page 8: Maintenance
Meters Step Throw in meter 1,5/2 1,75/2,75 2,5/3,5 3,25/4,25 4/4,5 Step Maintenance In spaces with heavy dust it might be necessary to clean the fan guard with compressed air once a year. If the fan guard is covered with severe dust the fan will have diminished suction capabilities. -
Page 9: Assembly And Electrical Instructions
Assembly and electrical instructions Assembly GVACM+GA8700 The ACM modules and assembly set have to be assembled as depicted with use of included parkers (key size 7). Article no. 1. GVACM 2. GA8700 Spare parts: -IX4200 Fan Ø350 -IW5903 Internal wiring... -
Page 10: Electrical Connections With And Without Speed Controller
Electrical connections with and without speed controller... -
Page 11: Electrical Connections Door Switch With And Without Speed Controller
Electrical connections door switch with and without speed controller... -
Page 12: Attachments
7 Attachment 7.1 Installation vertical mounting set Article no. 1. GVACM 4. GA8585 0. Not Included 0-300mm... - Page 13 7.1 Installation vertical mounting set Max. 10 modules...
