GenTent 20K Manual

GenTent
THANK YOU
Your new GenTent® 20k makes a very nice fit
on your Generac GP 12000, GP 15000 or
GP17500 generator. The recommended
installation is to install two GTU adapters at
the electrical panel and then either replace
the handle bolts with quick detach pins or
reposition the handles. This is a step-by-step
guide for this process.
WHAT YOU WILL NEED
- 1/2" socket or open end wrenches
- 5/16" socket or open end wrenches
- (optional) 5/32" drill bit and 5/16" nut driver
or screwdriver)
- This guide
Optional:
Either: 5/16" x 2" Clevis Pins with Retainer or
Quick Detach Pins
Or: GenTent folding handle kit
www.gentent.com/products/mpaccflhdl
INSTALLATION OVERVIEW
The process should take about 15 minutes:
Install GTUs: Remove electrical panel top bolts
only and reinstall with GTU flush to the panel
Choose a handles strategy:
- Make the handles quick detach, OR
- Install folding handles
Email: support@gentent.com
Telephone: 781-33G-TENT (781-334-8368)
Copyright 2016, GenTent® Safety Canopies, LLC. All rights reserved. Nottingham, NH, USA. www.gentent.com V4
®
20K
Generac 15k/17.5k Addendum
WARNING
Always shut generator off before any fueling or maintenance procedures.
WARNING
Never position the refueling door on the same side of the generator as the exhaust muffler.
Spilled gasoline can result in fire.
WARNING
Never block or cover the generator exhaust muffler in any way. GenTent canopy must be
installed above generator exhaust muffler. Install GenTent electrical skirts such that they
cannot block exhaust in any way.
CAUTION
Do not over tighten clamps when installing on the frame as failure can occur. Always use the
included washers. This will assure a firm, stable connection that will stay level when the
fiberglass frame is in place.
CAUTION
Always grasp fiberglass rods firmly during installation to avoid the whipping motion that can
occur when a bent fiberglass rod is mistakenly released.
CAUTION
Avoid using GenTent in hurricane force winds (above 60mph).
NOTE
Should generator handles cause significant stretching of the elastic straps when extended, it is
advisable to release the elastics straps on the handle side of the generator before extending
generator handles.
NOTE
Should GenTent cover block pull starter, it is advisable to release the elastic straps on the pull starter
side and temporarily move GenTent canopy out of the way.
NOTE
When using GenTent during snow storms, it is recommended to periodically brush away any
accumulation that blocks the top vent.
IMPORTANT PRODUCT SAFETY
