Manitowoc
SERVICE/MAINTENANCE MANUAL
This manual has been prepared for and is considered part of -
The serial number of the crane is the only method Manitowoc has of providing you with
correct parts and service information.
Always furnish serial number of crane and its attachments when ordering parts
or discussing service problems with your Manitowoc distributor or the factory.
©2013 Manitowoc
Published 08-16-13, Control # 208-03
8500-1/8500E-1
Model Number
8500Ref
Serial Number
This Manual is Divided into the following Sections:
SAFETY SECTION
SECTION 1
REFERENCE MATERIALS
SECTION 2
TEST PROCEDURES
SECTION 3
GENERAL
SECTION 4
POWER TRAIN
SECTION 5
HYDRAULIC SYSTEM
SECTION 6
HOIST SYSTEM
SECTION 7
BOOM HOIST SYSTEM
SECTION 8
SWING SYSTEM
SECTION 9
PROPEL SYSTEM
SECTION 10
ELECTRICAL SYSTEM
SECTION 11
AIR CONDITIONER
SECTION 12
TROUBLESHOOTING
NOTICE
To prevent death or serious injury:
Avoid unsafe operation and maintenance.
Crane and attachments must be operated and maintained by trained
and experienced personnel. Manitowoc is not responsible for qualifying
these personnel.
Do not operate or work on crane or attachments without first reading
and understanding instructions contained in Operator Information
Manual and Service Manual supplied with crane and applicable
attachments.
Store Operator Information Manual and Service Manual in operator's
cab.
If Operator Information Manual or Service Manual is missing from cab,
contact your Manitowoc distributor for a new one.
