- Page 1 ARRI - ORBITER Short Manual WARNING- FULLY READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE OPERATING THE ARRI ORBITER. IMPROPER HANDLING CAN RESULT IN SERIOUS HARM OR DAMAGE. IF YOU HAVE ANY QUESTION PLEASE CALL 416.869.3330.
- Page 2 Do no open the housing of the Orbiter. For safe operation, the housing must be completely closed at all times. Take appropriate precautions when lighting glass, windows and decorative surfaces.
- Page 3 ARRI - ORBITER Short Manual 1 – Sensor for Display Illumination 2 – Encoder 3 – Display 4 – Menu Buttons 5 – Quick Buttons 6 – Thread for D-Ring 7 – 4 Pin Lemo Connector 8 – Connectors to Luminaire 9 –...
- Page 4 2 – Repeat for other side !!! YOKE MUST BE MOUNTED HANGING OR STANDING VERTICALLY. LATERAL LOAD CAN BREAK THE SPIGOT !!! Lamphead must not be exposed to vibrations ARRI ORBITER FULL MANUAL: WWW.ARRI.COM...
- Page 5 WHEN NOT IN USE!!! ORBITER CONTROL By applying power to the mains power, the Orbiter will start lighting after a short start-up time with the previous settings programmed. Orbiter can either be controlled by: DMX (Input/Throughput), Ethernet (Daisy Chain), or the Removable Control Panel WHITE LIGHT –...
- Page 6 IF YOU HAVE ANY QUESTIONS OR CONCERNS, PLEASE CONTACT AFFILIATED EQUIPMENT 416.869.3330...
