- Page 1 SkyPanel ® S30 / S60 / S120 / S360 C and RP Versions U S E R M A N U A L L5.0019845 05 / 2018...
- Page 2 © 2018 Arnold & Richter Cine Technik GmbH & Co. Betriebs KG. All rights reserved. Information subject to change without notice. ARRI and all affiliated companies disclaim liability for any injury, damage, direct or indirect loss, consequential or economic loss or any other loss occasioned by the use of, inability to use or reli- ance on the information contained in this document.
-
Page 3: Table Of Contents
Content Content ................................3 Introduction ..............................5 Features ................5 Properties . - Page 4 ARRI Lighting Service Manager ........
-
Page 5: Introduction
Introduction Thank you for selecting a SkyPanel LED soft light from ARRI. The SkyPanel is a compact, ultra-bright and high-quality LED soft light. It is much more efficient than a soft light with a conventional light source. The different models of the SkyPanel emit white light with a fixed color temperature or colored light with adjustable color temperature and adjustable green-magenta point. - Page 6 You can set up or control the SkyPanel with the options listed in the table below Option Control Configuration Information Fixture menu page 6 Please see „DMX protocol specifica- tion (free download from www.arri.com) CRMX (WDMX)* page 26 page 35 Art-Net and sACN page 11 ALSM page 27 Web Portal page 29 The model S360-C is equipped with an internal CRMX Transceiver, all other models need to be connected to the SkyLink system (accessory) to gain wireless control.
-
Page 7: Fixture Menu
Fixture Menu This section describes the fixture menu of the SkyPanel and the SkyPanel remote control. Some options, especially options for saving and loading data, are not available in the remote control fixture menu. Overview Features of the Fixture Menu POWER-LED (1) Color Indication... -
Page 8: Status-Led (3)
STATUS-LED (3) Color Indication Green No error. Normal temperature. Warning fixture over temperature (only Red flashing (0,5s rhythm)* with fan modes LOW and High Speed). Fixture over temperature. Fixture normal temperature. Change from red to green Calibration data not loaded. Red flashing (0,25s Rhythm) *Display lights up red when STATUS-LED is lit red INTENSITY/SELECTOR (I/S, 4) -
Page 9: Menu (10)
MENU (10) The MENU button opens the fixture menu. Press MENU when the fixture menu is open to close the menu and abort an action (Escape). Use I/S (4) to scroll through the menu, open sub menus and set parameters. Press MENU long to display the menus which are used most. -
Page 10: Fixture Modes
The SkyPanel offers, depending on the model, up to 31 control modes. Use the 8 bit modes with basic con- trollers like dimmer consoles. ARRI recommends the use of the 16 bit modes in combination with controllers supporting 16 bit resolution to obtain best results. The high resolution provides smooth dimming and precise color adjustments. -
Page 11: Light Effects
Light Effects The SkyPanel contains a light effect engine with 13 different light effects. Activating a light effect is very easy. Just activate a light effect via the fixture menu, DMX, Art-Net or sACN and set the parameters to get exactly the effect you need. -
Page 12: Functions
Functions To set the Lighting Parameters in CCT Mode Set the color temperature continuously with the central rotary knob (5). Set the Green-Magenta point con- tinuously with the right rotary knob (6). The current setting is displayed above the rotary knobs. To set the Color in HSI Mode Set the hue continuously with the central rotary knob (5). -
Page 13: To Use The Extended Color Control Via Dmx
The SkyPanel applies 8 additional channels to every DMX mode when the extended color control is acti- vated vie the DMX settings menu. Please find more information in the „SkyPanel DMX Protocol Specifica- tion V4.4“ which is available for free download on the ARRI web site www.arri.com. NOTICE The extended color control is not available in LE DMX control modes. -
Page 14: To Set The Brightness In All Operating Modes
With activated extended color control: • A star next to the active operation mode indicates the activated extended color control, • the parameters are stored with each preset. Presets which contain parameters of the extended color con- trol are marked with a star, •... -
Page 15: Low End Mode
Low End Mode The Low End Mode optimizes the dimmer quality at low intensity levels and enables SkyPanel to generate accurate CCTs with high color rendition and smooth dimming at very low light levels. The Low End Mode can cause flickering when used with cameras shooting at high frame rates. NOTICE The stage mode can not be used with active low end mode and vice versa. -
Page 16: Master/Slave Mode
Master/Slave Mode In Master/Slave mode the slave fixtures mimic the master fixture without delay. The master fixture gener- ates a DMX signal on the 5-pin DMX Thru connector. Connect a maximum of 32 SkyPanels and L-series fixtures to a DMX data link. Choose one SkyPanel to be the master fixture. -
Page 17: To Set The Fan Mode
To set the frequency 1.Press the MENU button (10) to open the fixture menu. 2.Turn I/S, until „Light Control“ is displayed. Press I/S to open the menu. 3.Turn I/S, until „Frequency Selection“ is displayed. Press I/S to open the menu. 4.Select a frequency. - Page 18 Candle Low flickering of a warm light, slower than fire and less energetic. The light gentle fades in CCT and bright- ness with periods of static behavior in between. It consists of „flutters“ and static periods. Parameters: • CCT range •...
- Page 19 Fluorescent Flicker Fluorescent color with static periods and then periods of the light flickering on and off. Parameters: • Speed • Frequency Light Strobe Generates a white or colored strobe effect with adjustable speed from 25 flashes / sec to 1 flash / sec. DANGER DANGER! Risk of injury or death through epileptic seizure.
-
Page 20: To Activate And Set Effect Parameters With The Fixture Menu
Pulsing A pulsing or throbbing effect where the color and speed can be set. Parameters: • CCT • Green-Magenta point • Cross fade • Color • Saturation • Frequency • Span Television Creates an on-board TV effect. Cool CCT that changes intensity every few seconds. Parameters: •... - Page 21 The table below shows the parameters you can adjust with the rotary knobs for each effect: Effect Mode Rotary Knob Parameter Central CCT range Candle Right Speed Central Offset Clouds Passing Right Speed Central Color range Club Lights Right Speed Central Offset Color Chase...
-
Page 22: To Set The Display Behavior
When changing a parameter of an active effect through the fixture menu or via DMX, the internal effect gen- erator recalculates the effect in real time. The effect can stutter, step or be unsmooth for a short period. Do not change parameters of an active effect if the effect needs to run smooth. To Set the Display Behavior You can set the intensity of the background illumination, the contrast, the behavior of the background illu- mination and the orientation of the display content. -
Page 23: To Save And Load Fixture Settings
Up to 30 preset lists can be stored in the root directory of the USB memory stick. The file name is <product serial number>-Presetxx.json. The SkyPanel is looking for „Presetxx.json“ to identify a preset list on an USB memory stick. Be sure to keep the string when renaming a preset list. Otherwise the file will not be found by the SkyPanel. -
Page 24: To Save The Error And Service Log
To Save the Error and Service Log For diagnosis purpose you might be asked to send the error and service log to the ARRI service. The log files can be downloaded to an USB memory stick. The file name contains the date, time and serial number of the fixture. -
Page 25: Dmx
DMX Mode The SkyPanel offer different DMX modes. Please find a detailed overview of all DMX modes in the docu- ment „SkyPanel DMX Protocol Specification“ which is available for free download on the ARRI website www.arri.com. To set a DMX Mode 1.Press the MENU button (10) to open the fixture menu. -
Page 26: Wireless Dmx
Wireless DMX The SkyPanel S360-C is equipped with a wireless DMX receiver supporting the LumenRadio CRMX protocol. If there is no DMX traffic received via a wired interface (DMX-512A, ArtNet or sACN) and wireless DMX is activated via the fixture menu, the SkyPanel S360-C can linked to a wireless DMX transmitter via an RDM discovery command. -
Page 27: Networking
Networking Art-Net and sACN From firmware version 2.0 the SkyPanel supports Art-Net. Art-Net is a network protocol to control devices. Here is a brief explanation of some basic terms being used by Art-Net. For more detailed information, please visit the web site of the Art-Net developers: www.artisticlicence.com. The SkyPanel is capable of processing Art-Net for up to ten universes with one sender and three universes with two senders. -
Page 28: Network Settings
Please find information about the features and the functionality of the ARRI Lighting Service Manager in the user manual for the ARRI Lighting Service Manager. You can download it with the ARRI Lighting Ser- vice Manager software-bundle from the ARRI web site www.arri.com/lightingsoftware free of charge. -
Page 29: Skypanel Web Portal
SkyPanel Web Portal The SkyPanel provides a web page accessible via http, when connected to a network. Type in the IP ad- dress of the SkyPanel in your web browser to open the web portal and change the settings listed below. The web portal can also be found by using a Bonjour service to discover the fixture and open the web portal without needing to know the IP address. -
Page 30: Overview Of The Fixture Menu
Overview of the Fixture Menu From Firmware-Version 4.0 Open and close the fixture menu the MENU button. BACK closes a sub menu and aborts an action. Turn INTENSITY / SELECTOR to scroll. Press INTENSITY / SELECTOR to select an item Level 1 Level 2 Level 3... - Page 31 Level 1 Level 2 Level 3 Level 4 Explanation (default setting = bold) Master/Slave Mode OFF Master/ Slave Mode Master/Slave Mode active The color is mixed in RGBW mode direct (opti- Direct Control RGBW Color mized brightness). Space Calibrated Color The RGBW color is calibrated (optimized hue) Default Default frequency (highest frequency)
- Page 32 Level 1 Level 2 Level 3 Level 4 Explanation (default setting = bold) Save Light Pre- Store preset list to an USB memory stick (see sets page 22) Light Presets Load preset list from an USB memory stick. Load Light Pre- [List] Select preset list with Intensity / Selector (see sets...
- Page 33 Low battery warning treshold Normal USB port powered Fixture USB port not powered. Do not change this Settings USB Mode Service setting unless being asked by ARRI ser- vice. Risk of damage! Abort action Factory Reset Load factory settings 33 33...
-
Page 34: Rdm Commands
Product Detail ID List details of a fixture. Device Model Description A text description for the model type of the fixture. Manufacturer Label Shows „ARRI Lighting“ an Boot Software Version ID PrBO Version 2.03.00 Boot Software Version Label Shows text from PrBo Bootloader... - Page 35 Command Description Display Invert Rotates the display content 180° (only MKII) Display Level Set the display contrast (only MKII) Real Time Clock Get / set time and date (only L10 and SkyPanel) Queued Message Get / set message Curve Get / set dimming curve (only SkyPanel) Curve Description Get / set curve description List Interfaces...
- Page 36 Command Description Get / set DHCP RDM IP DHCP off = 0 0x8009 on = 1 RDM IP Address Get / set IP address 0x800A RDM IP Subnet Get / set subnet mask 0x800B RDM IP Gateway Get / set Gateway address 0x800C RDM IP DNS1 Get / set DNS1 address...
-
Page 37: Error Codes
However, if the fixture menu remains dark (no E.011 detected. LED lights up) we recommend to contact the ARRI service. They can then carry out detailed analyses. Temperature sensor(s) are One or more temperature sensors are defective or the E.012... -
Page 38: Overview Of Typical Cct Values As Dmx Values
Overview of Typical CCT Values as DMX Values CCT value DMX value (8 bit) DMX value (16 bit) Sky-Panel 3.200 K 3.670 5.600 K 25.493 6.000 K 29.098 6.500 K 33.685 Equations for calculation To calculate the CCT value 8 bit –...
