MS-4413
Accelerated Graphic Port
VERSION 1.0
1997/10/01 ROC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-4413 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MSI MS-4413

Summary of Contents for MSI MS-4413

  • Page 1 MS-4413 Accelerated Graphic Port VERSION 1.0 1997/10/01 ROC...
  • Page 2 Shielded interface cables and A.C. power cord, if any, must be used in order to comply with the emission limits. VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU RESEAU. MS-4413 MICRO-STAR Tested to Comply with FCC Standard FOR HOME OR OFFICE USE...
  • Page 3 MS-4413 Accelerated Graphic Port Copyright Notice The material in this document is the intellectual property of MICRO- STAR INTERNATIONAL. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents.

  • Page 4: Table Of Contents

    User’s Guide Table of Contents Chapter 1 MS-4413 3DLABs Permedia 2 AGP True 3D VGA Card 1. Overview ............... 1-1 2. Features ..............1-1 Chip List................1-1 Full support for Intel’s Accelerated Graphics Port (AGP) .....................1-1 Enhanced 3D graphics features and performance ..1-1 Integrated 100MFlop Glint Delta Geometry pipeline setup ..
  • Page 5 MS-4413 Accelerated Graphic Port Chapter 2 Installation of MS-4413 VGA Drivers 1. Driver ..............2-1 ® 1.1 Install Enhance Drivers for Windows 95 ....2-1 ® 1.2 Install Enhance Drivers for Windows NT ....2-8 ® 1.3 Install Enhance Drivers for Windows 98 (Memphis) ...................

  • Page 6: Chapter 1 Ms-4413 3Dlabs Permedia 2 Agp True 3D Vga Card

    MS-4413 3DLABs Permedia 2 AGP True 3D VGA Card 1. Overview The MS-4413 3DLABs Permedia 2 AGP True 3D VGA card is a high performance graphics card that integrates high quality 3D polygon and textured graphics acceleration, windows acceleration and state-of-the-art MPEG1/MPEG2 playback with fast integrated SVGA core, integrated RAMDAC and video ports.

  • Page 7: Integrated 100Mflop Glint Delta Geometry Pipeline Setup

    MS-4413 Accelerated Graphic Port 83M perspective correct, bilinear-filtered, texture-mapped pixel/sec 42M perspective correct, bilinear-filtered, texture-mapped, depth buffered pixel/sec Integrated 100MFlop GLINT Delta Geometry pipeline setup processor Integrated true-color 230 MHz RAMDAC DPMS, DDC1 and DDC2AB+ Clock synthesizer and Hardware cursor...

  • Page 8: Resolutions Supported

    User’s Guide Resolutions Supported 640x480x32bpp 800x600x32bpp 1024x768x32bpp 1152x870x32bpp 1280x1024x32bpp 1600x1200x16bpp...

  • Page 9: System Requirements

    MS-4413 Accelerated Graphic Port 3. System Requirements To install MS-4413 VGA card, your computer system needs to meet the following requirements: ® Computer Intel Pentium II processor or compatible system Expansion Slot AGP slot Monitor VGA Support, minimum 640x480 resolution ®...

  • Page 10: Card Layout

    User’s Guide 5. Card Layout 1. J1 VGA Connector 2. U1 3DLABs Permedia 2 3. Y1 Crystal 14.31818MHz 4. U5~U12 256kx32SGRAM 5. U2 VGA BIOS Jumper Setting: JP2 Short 1-2 VGA Enable Short 2-3 VGA Disable...

  • Page 11: Db 15 Pin Connector

    MS-4413 Accelerated Graphic Port 6. DB 15 Pin Connector Analog Video Display Connector(DB15-S) Signal Description Green Blue Not used Ground Ground Ground Ground Not used Ground Not used Horizontal Sync Vertical Sync...

  • Page 12: Vertical Refresh Rate

    User’s Guide 7. Vertical Refresh Rate Resolution Color Vertical Refresh 640x480 8bit, 16bit, 32bit 60, 72, 75 800x600 8bit, 16bit, 32bit 60, 72, 75 1024x768 8bit, 16bit, 32bit 60, 72, 75 1280x1024 8bit, 16bit, 32bit 60, 70 1600x1200 16bit...

  • Page 13: Chapter 2 Installation Of Ms-4413 Vga Drivers

    Standard VGA Driver. To get a higher resolution and perform- ance, you need to install the MS-4413 Driver. To install MS-4413 Enhance Drivers, follow the steps below: Step 1: Insert the 4413_DRV CD into your CD-ROM drive. ®...
  • Page 14 User’s Guide Step 4: Double click on Display Icon. Step 5: Choose Settings. Then, click on the Advanced Properties.
  • Page 15 MS-4413 Accelerated Graphic Port Step 6: Look for Adapter Type, then click on Change. Step 7: Click on Have Disk.
  • Page 16 User’s Guide Step 8: Click Browse. Step 9: Look for the CD-ROM drive and search for E:\Win95 Directory. Then, click OK.
  • Page 17 MS-4413 Accelerated Graphic Port Step 10: Choose OK. Step 11: Select PERMEDIA 2 3D , then click OK. This will start copying the necessary files.
  • Page 18 User’s Guide Step 12: Click on the Apply button, then OK. Step 13: Click on the Apply button.
  • Page 19 MS-4413 Accelerated Graphic Port ® It will then prompt you to restart Windows Step 14: Click on the Yes button.

  • Page 20: Install Enhance Drivers For Windows Nt

    User’s Guide ® 1.2 Install Enhance Drivers For Windows ® After installing MS-4413 Card, Windows NT will default to Standard VGA mode 640x480x16 colors. Follow the steps below to install the VGA driver. Step 1: Insert the 4413_DRV CD into your CD-ROM.
  • Page 21 MS-4413 Accelerated Graphic Port Step 3: Double Click the Display Icon. Step 4: Choose Settings, then click on the Display Type.
  • Page 22 User’s Guide Step 5: Click on the Change button. Step 6: Click on the Have Disk button. 2-10...
  • Page 23 MS-4413 Accelerated Graphic Port Step 7: Click on the Browse button. Step 8: Go to the CD-ROM drive, then look for the NT4.0 folder. Choose 3dlabs, then click the Open Button. 2-11...
  • Page 24 User’s Guide Step 9: Click the OK button. Step 10: Choose PERMEDIA P2, then click OK. 2-12...
  • Page 25 MS-4413 Accelerated Graphic Port This will prompt you about a Third Party Driver. Step 11: Click the Yes button. Step 12: Click the OK button. Step 13: Click the Close button. 2-13...
  • Page 26 User’s Guide Step 13: Click the Close button. ® It will then prompt you to restart Windows Step 14: Click on the Yes button. 2-14...

  • Page 27: Install Enhance Drivers For Windows 98 (Memphis)

    Standard VGA Driver. To get a higher resolution and performance, you need to install the MS-4413 Driver. To install MS-4413 Enhance Drivers, follow the steps below: Step 1: Insert the 4413_DRV CD into your CD-ROM.
  • Page 28 User’s Guide Step 5: Choose Settings and then click on the Advanced Properties. Step 6: Choose Change. 2-16...
  • Page 29 MS-4413 Accelerated Graphic Port Step 7: Choose Have Disk. Step 8: Choose Browse. 2-17...
  • Page 30 User’s Guide Step 9: Look for CD-ROM drive and search for E:\Win95. Then, click OK. Step 10: Choose OK. 2-18...
  • Page 31 MS-4413 Accelerated Graphic Port Step 11: Select PERMEDIA 2 3D Accelerator, then click OK. It will start copying the necessary files. Step 12: Click on the Apply button, then OK. 2-19...
  • Page 32 User’s Guide Step 13: Click on the Apply button. It will then prompt you to restart Windows Step 14: Click on the Yes button. 2-20...
  • Page 33 MS-4413 Accelerated Graphic Port ® 1.4 Install Enhance Drivers For IBM OS/2 Follow the procedure listed below to install the OS/2 display driver. If you are installing OS/2 for the first time, install the OS/2 for VGA first and reconfigure the driver later.
  • Page 34 User’s Guide Configuring the OS/2 Driver: To configure your OS/2 driver once it is installed, follow the procedure listed below. Step 1: Click on the System icon in the System Setup folder. Step 2: Select the Screen tab to display resolutions and screen refresh rates on page one of the System Settings dialog box.
  • Page 35 No. 69, Li-De St., Jung-He City, Taipei Hsien, Taiwan Tel: 886-2-3234-5599 Fax: 886-2-3234-5488 http:// www.msi.com.tw BRANCH OFFICES ACHME COMPUTER INC. MSI COMPUTER SARL (USA) (FRANCE) 4059 Clipper Court, Fremont 19 Boulevard Georges Bidault CA 94538, U.S.A. 77183 Croissy-Beaubourg, France Tel: 1-510-623-8818...
