MSI Micro-Star MS-4419 User Manual

MSI Micro-Star MS-4419 User Manual

Intel740 agp graphics accelerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MS-4419 Intel740
TM
Accelerated Graphic Port
M S - 4 4 1 9
TM
Intel740
A G P G R A P H I C S A C C E L E R A T O R
VERSION 1.0
1998/06/30 ROC

Advertisement

Table of Contents
loading

Related Manuals for MSI Micro-Star MS-4419

Summary of Contents for MSI Micro-Star MS-4419

  • Page 1 MS-4419 Intel740 Accelerated Graphic Port M S - 4 4 1 9 Intel740 A G P G R A P H I C S A C C E L E R A T O R VERSION 1.0 1998/06/30 ROC...
  • Page 2 User’s Guide FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 3 MS-4419 Intel740 Accelerated Graphic Port Copyright Notice The material in this document is the intellectual property of MICRO- STAR INTERNATIONAL. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents.

  • Page 4: Table Of Contents

    User’s Guide Table of Contents Chapter 1 MS-4419 Intel740 Graphics Accelerator 1. Overview ............... 1-1 2. Features ..............1-2 Chip List................1-2 Breakthrough 3D...............1-2 Highest perf. AGP ............1-2 Advanced Memory Interface ......... 1-2 64-bit 2D Accelerator ............ 1-2 Video Acceleration ............1-2 Video Capture Port ............

  • Page 5: Chapter 1 Ms-4419 Intel740

    MS-4419 Intel740 Accelerated Graphic Port Chapter 2 Installation of MS-4419 VGA Drivers 1. Driver ..............2-1 ® 1.1 Install Enhance Drivers for Windows 95 ....2-1 ® 1.2 Install Enhance Drivers for Windows NT ..... 2-15...

  • Page 6: Graphics Accelerator

    User’s Guide Chapter 1 MS-4419 Intel740 AGP Graphics Accelerator 1. Overview The MS-4419 Intel740 AGP VGA card is a highly integrated graphics solution which provide high-performance 3D, 2D and video, and full support for multimedia applications, (VBI), TV Out and video capture. The Intel740 graphics accelerator uses a breakthrough 3D architecture that enables maximum memory bandwidth for...

  • Page 7: Features

    MS-4419 Intel740 Accelerated Graphic Port 2. Features Chip List: Intel740 : 2D & 3D accelerator processor. Breakthrough 3D 844K + poly/sec 45-55 Mpixels/s, 425-500K poly/s (sustained) 14K polygons/frame (sustained) Bilinear mip-mapping Gouraud, Specular shading 16-bit z-buffer Alpha blend, edge smoothing Highest perf.

  • Page 8: Full Software Solution

    User’s Guide Power Management Supports VESA Display Power Management Signaling (DPMS) compliant VGA monitor for power management Multimedia Application Supports DDC1 and DDC2B specification Full Software Solution ISV kit, install & config utilities ® ® Windows 95 & Windows NT 4.0 ®...

  • Page 9: System Requirements

    MS-4419 Intel740 Accelerated Graphic Port 3. System Requirements To install MS-4419 VGA card, your computer system needs to meet the following requirements: ® ® Computer Intel Pentium processor, Intel Pentium processor or compatible system Expansion Slot AGP slot Monitor VGA Support, minimum 640x480 resolution ®...

  • Page 10: Card Layout

    User’s Guide 5. Card Layout JP1/JP2/JP3/J2 Jumpers RCA jack (optional) VGA connector S-Video connector (optional) VMI connector (optional) Feature connector 66.6667MHz Bt829 Video in (optional) Bt868/Bt869 TV-Out (optional) VGA BIOS Intel740 AGP chip U16/U17/U18/U19 1Mx16 SDRAM 35.4689MHz (optional) 28.63636MHz (optional) 13.50MHz (optional)

  • Page 11: Db 15 Pin Connector

    MS-4419 Intel740 Accelerated Graphic Port 6. DB 15 Pin Connector Analog Video Display Connector(DB15-S) Signal Description Green Blue Not used Ground Ground Ground Ground Not used Ground Not used Horizontal Sync Vertical Sync...

  • Page 12: Vertical Refresh Rate

    User’s Guide 7. Vertical Refresh Rate If you set the monitor to “Plug and Play”, you can only use 75Hz vertical refresh rate. But if you set the monitor type correctly, then you can set the vertical refresh rate up to 85Hz. Resolution Color Vertical Refresh...
  • Page 13 MS-4419 Intel740 Accelerated Graphic Port Chapter 2 Installation of MS-4419 VGA Drivers 1. Driver ® 1.1 Install Enhance Drivers for Windows ® After installing MS-4419 card in the mainboard, Windows 95 will auto-detect the changes in your hardware configuration, and will install the Standard VGA Driver.
  • Page 14 User’s Guide Step 4: Click on Yes button. Step 5: Click on Yes button.
  • Page 15 MS-4419 Intel740 Accelerated Graphic Port This will first scan the C: drive, then copy the necessary file needed. Step 4: Click on Ok button. Step 5: Click on the OK button. This will restart your system.
  • Page 16 User’s Guide To install MS-4419 enhanced driver, follow the steps below: Step 1: Insert the CD provided into your CD-ROM drive. After inserting the CD, this will autorun showing this window. Step 2: Click on Intel i740 Display Drivers button. Step 3: Click on the OK button.
  • Page 17 MS-4419 Intel740 Accelerated Graphic Port Step 4: This will be the new Display Properties.
  • Page 18 User’s Guide Using Display Properties new function: This function is used to show the Display Driver version and memory size.
  • Page 19 MS-4419 Intel740 Accelerated Graphic Port This function is used to adjust the Gamma Ramp, Gamma, Brightness, Contrast, and color.
  • Page 20 User’s Guide Another way to install MS-4419 Enhance Drivers, follow the steps below: Step 1: Insert the CD provided into your CD-ROM drive. ® Step 2: In Windows 95, click on the Start Menu. Step 3: Choose Settings, then open Control Panel.
  • Page 21 MS-4419 Intel740 Accelerated Graphic Port Step 4: Double click on Display Icon. Step 5: Choose Settings. Then, click on the Advanced Properties.
  • Page 22 User’s Guide Step 6: Look for Adapter Type, then click on Change. Step 7: Click on Have Disk. 2-10...
  • Page 23 MS-4419 Intel740 Accelerated Graphic Port Step 8: Click Browse. Step 9: Look for the CD-ROM drive and search for Win95 Directory. Then, click OK. 2-11...
  • Page 24 User’s Guide Step 10: Select Intel 740-854 Win9x , then click OK. This will start copying the necessary files. Step 11: Click on the Apply button. 2-12...
  • Page 25 MS-4419 Intel740 Accelerated Graphic Port Step 12: Click on the OK button. Step 13: Click on the Apply button. 2-13...
  • Page 26 User’s Guide ® It will then prompt you to restart Windows Step 14: Click on the Yes button. This will be the new Display Properties. 2-14...
  • Page 27 MS-4419 Intel740 Accelerated Graphic Port ® 1.2 Install Enhance Drivers For Windows ® You need to install the Windows NT “Service Pack 3”, before installing the driver. ® After installing MS-4419 Card, Windows NT will default to Standard VGA mode 640x480x16 colors. Follow the steps below to install the VGA driver.
  • Page 28 User’s Guide Step 3: Double Click on the Display Icon. Step 4: Choose Settings, then click on the Display Type. 2-16...
  • Page 29 MS-4419 Intel740 Accelerated Graphic Port Step 5: Click on the Change button. Step 6: Click on the Have Disk button. 2-17...
  • Page 30 User’s Guide Step 7: Click on the Browse button. Step 8: Look for the CD-ROM drive. Open the Intel folder. 2-18...
  • Page 31 MS-4419 Intel740 Accelerated Graphic Port Step 9: Open the i740 folder. Step 10: Open the NT40 folder. 2-19...
  • Page 32 User’s Guide Step 11: Choose oemsetup. Step 12: Click on the OK button. 2-20...
  • Page 33 MS-4419 Intel740 Accelerated Graphic Port Step 13: Choose Intel 740 Video Accelerator, then click OK. This will prompt you about a Third Party Driver. Step 14: Click the Yes button. 2-21...
  • Page 34 User’s Guide Step 15: Click the OK button. Step 16: Click the Close button. 2-22...
  • Page 35 MS-4419 Intel740 Accelerated Graphic Port Step 17: Click the Close button. ® It will then prompt you to restart Windows Step 18: Click on the Yes button. 2-23...
  • Page 36 User’s Guide Using Display Properties new function: This function is used to show the Display Driver version and memory size. 2-24...
  • Page 37 MS-4419 Intel740 Accelerated Graphic Port This function is used to adjust the Gamma Ramp, Gamma, Brightness, Contrast, and color. 2-25...
  • Page 38 User’s Guide MS-4419 Bug Notes: 1. TV-out Bug List - If your VGA card contains a TV-out function. You need to connect the TV-Cable before turning the power on. - During boot up, the TV and monitor will be blank for 3 seconds.
