Simu Hz TIMER Instructions page 4

3.4 - "OFF" mode:
The timer acts like a basic radio transmitter (UP and DOWN time setting are disabled).
3.5 - Random mode "SEC" :
The SEC mode use the "weekly/daily" programme and offsets it randomly by +/- 15 minutes to simulate presence in your
home.
Programming the Hz-Timer on a receiver with an existing installation
4
4.1 - Open the memory of the Hz receiver using its
individual control translitter:
Press the "PROG" key of the individual control transmitter for
about 3 sec. The motor rotates by about 1/2 second in one
direction, then the other.
- To issue a group control with the timer : repeat opérations 4.1 and 4.2 for each receiver of the group.
- To issue a general control with the timer : repeat opérations 4.1 and 4.2 for each receiver of the facility.
- To remove the timer from the memory using a receiver: repeat operations 4.1 et 4.2 twice.
For programming the timer within the framework of a new facility,
Installation
7
Changing the batteries
8
WARNING : respect polarities (+/–), don't recharge, don't throw in fire nor open the used batteries, don't mix used
batteries or other kind of batteries (coulds explode, leak and cause damage).
apply the instructions in the receiver's manual.
4.2 - Validate the operation from the timer :
Press the "PROG" key of th timer for about 1 sec.The motor
rotates by about 1/2 second in one direction, then the other.
The programming is achieved.
PROG
≤ 1s
- Avoid locating the timer against or close to a metallic
part, as it could result in major lost of range.
- Do not install the timer too close to a receiver. (30cm
minimum).
- Whenever possible, install the timer at a height above
1,5m minimum from the ground.
- Before securing the timer, locate the timer at the
chosen location and press one of the keys (up or
down) for 2 sec. to check proper operation of the
installation. Repeat this operation several times to
validate the chosen location.
- The Hz-Timer is intended for indoor use only.
- A radio appliance using the same frequency (for
example : hi-fi radio headphones) may deteriorate our
product's performance.
1- Remove carefully the front cover using a flat screwdriver.
2- Unclip the timer from its basis.
3- change the batteries (2 x LR03 - AAA - 1,5V).
4- Refitting : apply the reverse sequence and set the current
time and date.
>>>
